- Page 1 XTZ 99.38 High-End floor speaker User manual © 2008 XTZ AB , www.xtz.se Page: 1...
-
Page 2: Table Of Contents
Table of contents Page: Contents About XTZ Technical presentation Preparations Practice of sound / Installation and placement tips Mounting /Area of usage Sound adjustment Technical specifications Service & Support Page: 2... -
Page 3: Contents
Contents Contents Congratulations of your purchase the XTZ 99.38 When combined with surround audio/video electronics, you will experience sound of motion pictures or music records much deeply and naturally. Now when you watch your favourite movie or listen to your reference music CDs, you... -
Page 4: Technical Presentation
Technical presentation Cabinet design The box design with a narrow baffle and curved side - is not only an aesthetically neat shape, but also has some advantages in terms of acoustics, since nonparallel walls muffles internal resonances of the cabinet. Internally the cabinet is physically separated in two parts, one for the midrange and tweeter, and one for the woofer. - Page 5 makes sure that the basket is very stable and efficiently reduces resonances. The basket is absolutely none magnetically, which contributes to a higher efficiency of the driver. A strong magnet combined with the light cone yields a high efficiency and a good transient response.
-
Page 6: Preparations
For the midrange and tweeter we have chosen a -12 dB crossover that has a fast transient response and a minimum of phase shiftings. For the woofer we have chosen a 24dB crossover. The connectors are gold-plated and of bi-wiring type so that you can connect to the amplifier with double cables (tri-wiring), or connect to two amplifiers (tri-amping) for further improving the... -
Page 7: Practice Of Sound / Installation And Placement Tips
Practice of sound / Installation and placement tips This chapter contains common information on loudspeaker placement and installation. This is general rules, so there are exceptions of some rules No matter how good the equipment is, in the wrong In which room do listening environment it will inevitably sound bad. - Page 8 Cables Try to keep them as short as possible. By its electrical parameters, a long conductor will have a bigger influence on the sound than a short one. It may also work as an antenna and thus receive various signals that may become a constant noise in an active subwoofer.
-
Page 9: Mounting /Area Of Usage
Mounting and Connecting tips Mounting Normally the XTZ 99.38 is placed standing by a wall. The wall behind and besides the loudspeaker alternatives have influence both on the bass level and the bass characteristics, so please be patient and try different distances to the rear and side walls. -
Page 10: Sound Adjustment
Mechanical taste, so please has patience when trying on the XTZ 99.38 adjustment of the out your preferred setting. boundary frequency The level can be adjusted in 6 different levels in the bass range. - Page 11 Basic setting for Since the acoustics is determined by a wide range of external factors there exists no single neutral neutral bass setting that will work properly for all cases. reproduction External factors that have influence on the sound include the room, the placing, output levels etc. One basic neutral setting for an average room of Two bass plugs in two of the two lowermost gates and one plug in the gate for midrange.
-
Page 12: Technical Specifications
Technical specifications Construction type 3-way with separates boxes for woofer and Woofer/midrange. Bass reflex cabinet that may be set as a closed box, and a total of two distinct bass modes (Room Tuning). The treble and bass levels are adjustable. (with front cover) Dimensions 220 x 1070 x 400 mm (W x H x) -
Page 13: Service & Support
Service & support "Do-It-Yourself"- We apply "do-it-yourself" service on all XTZ service, products constructed and produced using common products. service technology, so that basically most people are able to "unscrew" the loudspeaker If you by yourself are able to find out what part of using common tools.
