- Page 1 XTZ 99.26 P High-End Monitor speaker User manual © 2008 XTZ AB , www.xtz.se Page: 1...
-
Page 2: Table Of Contents
Table of contents Page: Contents About XTZ Technical presentation Preparations Practice of sound / Installation and placement tips Mounting /Area of usage Sound adjustment Technical specifications Service & Support Page: 2... -
Page 3: Contents
Contents Contents Congratulations of your purchase the XTZ 99.26 P When combined with surround audio/video electronics, you will experience sound of motion pictures or music records much deeply and naturally. Now when you watch your favourite movie or listen to your reference music CDs, you... -
Page 4: Technical Presentation
Technical presentation The pyramid shape is not only an aesthetically neat Cabinet design shape, but also has some advantages in terms of acoustics, since nonparallel walls muffles internal resonances of the cabinet. The cabinet is made in 25mm MDF board, which has good sonic qualities. -
Page 5: Preparations
Large windows in the basket both above and below the spider reduces sound reflection, air flow noise and cavity resonances. Crossover / For the 99.26 P, we have chosen to have an external cross over box. Having the cross over outside the Binding post box has some benefits. -
Page 6: Practice Of Sound / Installation And Placement Tips
Practice of sound / Installation and placement tips This chapter contains common information on loudspeaker placement and installation. This is general rules, so there are exceptions of some rules In which room do No matter how good the equipment is, in the wrong listening environment it will inevitably sound bad. - Page 7 Cables Try to keep them as short as possible. By its electrical parameters, a long conductor will have a bigger influence on the sound than a short one. It may also work as an antenna and thus receive various signals that may become a constant noise in an active subwoofer.
- Page 8 Mounting and Connecting tips Mounting Normally the XTZ 99.26 P is placed standing by a wall. The wall behind and the wall beside the alternatives loudspeaker have influence on both the bass level and the bass characteristics, so please be patient and try different distances to the rear and side walls.
- Page 9 Mechanical taste, so please has patience when trying on the XTZ 99.26 P adjustment of the out your preferred setting. boundary frequency Also the treble level may be adjusted, which allows you to perfectly alter the sonic to fit the room, equipment and your own taste.
- Page 10 Technical specifications Construction type 2-way, Bass reflex cabinet that may be set as a closed box. The treble level is adjustable in four different levels. (with front cover) Dimensions 234 x 375 x 350 mm (W x H x D) Weight 9 kg/pcs Magnetically...
- Page 11 Service & support "Do-It-Yourself"- We apply "do-it-yourself" service on all XTZ service, products constructed and produced using common products. service technology, so that basically most people are able to "unscrew" the loudspeaker If you by yourself are able to find out what part of using common tools.
