INSTALLATION AND
SERVICE INSTRUCTIONS
The ECONOMITE F400B-33 conversion burner with intermittent spark ignited pilot is adaptable to most gas utilization equipment,
including gravity and forced circulation furnaces and boilers. It is particularly recommended for firing horizontal or downdraft equipment
since it needs no draft to maintain a pilot. Power burner design makes it perfectly suited for oil burner replacement, including rooftop
and industrial applications.
In the United States, installation must conform with local codes
or, in the absence of local codes, with Installation of Domestic
Gas Conversion Burners, ANSI Z21.8b-1993, and National
Fuel Gas Code, ANSI Z223.1-1992, or latest edition(s) available
from American National Standard Institute. Further reference
should be made to the recommendation of your fuel supplier.
NOTE: Any additions, changes, or conversions required in order
for the appliance to satisfactorily meet the application needs
must be made by a MIDCO distributor (or other qualified agency)
using factory specified approved parts.
In Canada, installation must conform with local codes or, in the
absence of local codes, with Installation Codes for Gas
Burning Appliances
CAN/CGA1-B149.1 or 2. When the conversion burner is used
on a Forced air Central Furnace, the two yellow and black
warning labels in the literature envelope shall be attached in
accordance with Installation Code, CGa Standard CAN/CGA
1-B149, Clause 5.4.4.4. Further reference should be made to
the recommendation of your fuel supplier.
INSTALLER: Inform and demonstrate to the user
the correct operation and maintenance of this
appliance. Inform the user of the hazards of
storing flammable liquids and vapors in the
vicinity of this appliance and remove such
hazards. Affix this manual adjacent to the
conversion burner.
CODE COMPLIANCE IS THE SOLE
RESPONSIBILITY OF THE INSTALLER.
USER: Retain this manual for future reference. If
other than routine service or maintenance as
described in this manual is required, contact
a qualified service
ATTEMPT REPAIRS. An inadvertent service
error could result in a dangerous condition.
S S A A F F E E T T Y Y I I N N F F O O R R M M A A T T I I O O N N T T E E R R M M S S : :
have standard meanings throughout this manual. When you see the safety alert symbol and one of the safety information terms, as
shown below, be aware of the hazard potential.
DANGER: Identifies the most serious hazards which will result in severe personal injury or death.
WARNING: Signifies hazards that could result in personal injury or death.
CAUTION: Identifies unsafe practices which would result in minor personal injury or product and property damage.
MIDCO International Inc.
4140 WEST VICTORIA STREET, CHICAGO, ILLINOIS 60646 / (773) 604-8700 FAX: (773) 604-4070
PRINTED IN U.S.A.
ECONOMITE MODEL F400B-33
Gas Conversion Burner
and Equipment, CGA Standard
agency. DO
The following terms are used to identify hazards, safety precautions or special notations and
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or death.
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your building.
• Immediately phone your gas supplier
from another building. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
NOT
1296
8470-73
