1. What is the CAT5 Smart KVM Extender system?

The CAT5 Smart KVM Extender system from Minicom is an advanced KVM
switch that performs the following functions:
•
Extends KVM control over a computer* up to a distance of 110m / 360ft
•
Gives 2 users at 2 workstations control of 1 computer*
•
A 2-port KVM Switch for 1 or 2 users
* Wherever the word 'computer' appears in this guide it can equally refer to a
KVM switch.

2. The system components

The Smart KVM Extender system consists of the following:
•
Transmitter
•
Receiver
•
3 in 1 CPU cable
•
1 Power adapter for the Receiver
A Shielded CAT5 FTP (Foil Shielded Twisted Pair) Solid Wire 2x4x24 AWG
cable terminated with RJ-45M connectors connects the Smart KVM Extender
system. The Receiver can be up to 110m/360ft away from the Transmitter.
This Guide illustrates the Smart KVM Extender system and explains how to
install and operate it.
