9. Using the Smart KVM Extender as a 2-port KVM Switch

Figure 10 illustrates the system connected to 2 computers and 2 workstations. User
1 can access his local computer or the remote computer. User 2 can only access his
local computer. The connections are the same as in Figure 9, with the addition of
the 3 in 1 CPU cable that connects a 2
SD
P110
User 2
CAT5
S M A R T
Extender
TRANSMITTER
Transmitter
DESKPRO
The option in Figure 10 can also work with only 1 user workstation connected at
the Receiver.
CAT5 FTP cable
Up to 110m / 360ft
MINICOM
www.minicom.com
SD
Ω
Computer
Figure 10 As a 2-port KVM Switch
nd
computer to the Receiver.
User 1
Computer
DESKPRO
To
Keyboard
port
To Mouse port
9
S D
P1 10
To Computer
Monitor port
To Computer
Mouse port
To Computer
Keyboard port
CAT5
S M A R T
Extender
MINICOM
RECEIVER
www.minicom.com
Receiver
SD
Ω
To Video card
3 in 1
CPU
cable
