12. Operating the Smart KVM Extender

Once the system is connected there are 2 ways to switch between the 2 computers /
KVM workstations.
•
On the Receiver press the Select button
Or
•
On the keyboard press Shift followed by + or -.
The Receiver Control LED
Status
Off
On
Blinking
The Transmitter Control LED
Status
Blinking
Off

Adjusting the picture

When the Receiver has control of the Transmitter's computer, adjust the picture
quality where necessary using a small flat screwdriver to turn the Picture adjuster
located on the Receiver's rear panel. See Figure 6.
Meaning
User at Receiver working on Receiver computer
User at Receiver working on Transmitter computer
User at Transmitter working on Transmitter computer
Meaning
User at Receiver working on Transmitter computer
Any other situation
12
