EPSON Stylus CX3100/3200

1.1 Overview

This section describes the specifications for the SPC (Scanner, Printer, Copier)
machine "Stylus CX3100/3200".

1.1.1 Basic Functions

The functions of Stylus CX3100/3200 are as described below:
Printer function
The Printer function produces photo quality output on the Epson special coated
papers with BorderFree feature.
Print head
Bk: 48 nozzles in each of 3 rows (144 nozzles in total)
YMC: 48 nozzles for each
Scanner function
The image can easily be acquired on the PC by means of the "Scan" button.
The maximum optical resolution of scanning is 600 dpi x 1200 dpi and pixel
depth is 48-bit at the ADC output, 24-bit when passing to a PC.
Standalone Copier function
The Product has the Standalone Copier function that reproduces photo quality
copies on the Epson special coated papers without PCs. The use of the latest print
technology mounted on the Product achieves the highest standalone copy speed
among the same class of the products.
Standard Copy mode
This mode is used for the standard copier function. The bottom margin is 14
mm.
BorderFree Copy mode
Photograph copy
Small Margin Copy mode
The minimum copy margin is 1.5 mm.
PRODUCT DESCRIPTION
Reduced (Minimize) Margin Copy mode
This mode is basically the same as the standard copy mode, but the bottom
margin is 3 mm.
Repeat Copy mode
Mini photo stickers can be produced.
2-up Copy mode
Two pages of the original is shrunk and printed on one page. Consumption of
copy paper can be saved.
Mirror Copy mode
The original can be flipped from left to right and copied onto the Iron-on Cool
Peel Transfer Paper.

1.1.2 Common

The specifications described below are common to the scanner and printer.

1.1.2.1 Electrical Specifications

Rated voltage (VAC)
Input voltage (VAC)
Rated current (A)
Rated frequency range (Hz)
Input frequency range (Hz)
Power consumption (W)
Overview
Table 1-1. AC Input
100 V Model 120 V Model
100 120
90-110 108-132
0.6 0.6
50-60
49.5-60.5
Approx. 22 W (Standalone copying, ISO10561 Letter
Patter, Plain Paper - Normal)
Approx. 6.5 W (Standby)
Revision A
220-240 V Model
220-240
198-264
0.3
9
