The SAMBA status LED labelled "ERR" will be turned off.
Close all opened windows.
Click on Start button, point to Settings, and then click Control
Panel.
Double-click the System icon.
Select the Hardware register and click on Device Manager
button, open the item Modems and select the SAMBA USB
Modem Driver, click to the properties button by using the
right-mouse click. The SAMBA allocated COM port and
settings can also be found. The baud rate can be changed upto
115200 bps.
On the next opened window screen select the Diagnosis tab, to
test if the modem works properly, then just click the Query
modem button. If the modem responds then the modem is ready
for use. Click OK buttons to close the opened windows. Now
you can start HyperTerminal program (see figure below) or
another terminal program, to communicate with the SAMBA
phone by using the AT-Commands. The AT-Command Set is
also included in the delivery CD. See related documents [3].
Setup HyperTerminal program:
START – PROGRAMS
COMMUNICATION – HYPERTERMINAL, then start the
software HYPERTRM, assign the name of your choice, click on
the icon of your choice, then click on OK, then choose:
Connect using: e.g. COM1 (allocated COM port, readed from
SAMBA modem properties)
Properties: choose up to 115200 bps – 8 bits data – no
parity – 1 stop bit – hardware flow control
Click on OK.
Once HyperTerminal is opened and configured, it can be used
to send AT commands to the SAMBA phone.
