SAMBA 55/56
Figure 12: Connect USB connector of SAMBA to the USB serial port of PC.
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
CAUTION - Use caution when inserting the SAMBA into
the USB slot. Forcing the SAMBA may damage the
connector pins. If you feel resistance while inserting the
SAMBA into the USB slot of your computer, remove it
immediately and check for any damage of its connector or
bend pins.
Additionally, the Status LED labelled "ERR" will flash during
the internal initialization. This effect will happen after the user
has installed the corresponding driver. See next item (install the
driver). After internal initialization is implemented (approx. 3-5
sec.) the Status LED labelled "ERR" will be turned off. After a
few seconds and after the user has entered the PIN number (if
needed) the GSM LED will start flashing slowly (which means,
the registration into the network is successfully), refer also to
the Table 7 for more details.
Click on EXIT button to complete the driver installation.
VERSION 1.07
Page 28
