- Page 1 This document is available at HTTP://WWW.FALCOM.DE/ SAMBA 75 User’s manual Version 1.01, 18/10/2005...
-
Page 2: Table Of Contents
5.1.1.4 GPRS/EDGE DATA ........................18 5.1.2 Power down ........................18 5.1.3 Alarm mode ........................19 ................19 OWER OWER CENARIOS This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 1... - Page 3 PIN & PUK ......................... 26 6.2.4 Text messages ......................... 26 6.2.5 Data and fax communication ..................27 RF EXPOSURES...............28 APPENDIX................29 ....................... 29 ROUBLESHOOTING This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 2...
- Page 4 Version number Author Changes 29/09/2005 1.00 Fadil Beqiri Initial version 18/10/2005 1.01 Fadil Beqiri Chapter 7, “RF Exposures” added This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 3...
- Page 5 FALCOM GmbH. FALCOM GmbH. No patent liability is assumed with respect to the use of the information contained herein. This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 4...
-
Page 6: Introduction
Internet access and large file downloads. This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 5... -
Page 7: Scope Of Delivery
Receive Protocol RXQUAL Received Signal Quality Subscriber Identity Module Short Message Service SMS/PP Short Message Service/Point-to-Point Terminal Adapter Terminal Equipment This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 6... -
Page 8: Related Documents
2. ETSI GSM 07.07: “AT command set for GSM Mobile Equipment” 3. AT-Command SET 4. PhoneTool installation guide 5. GPRS Startup User's Guide This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 7... -
Page 9: Security
Replace a damaged antenna immediately. Consult your manual to see if you may change the antenna yourself. If This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 8... -
Page 10: Driving
(by poking themselves or others in the eye with the antenna, for example). Children could damage the modem or make calls that increase your modem bills. This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 9... -
Page 11: Blasting Areas
It is also recommended to use the equipment not close to medical devices as for example hearing aids and pacemakers. This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 10... -
Page 12: Safety Standards
European Community, Directorate General V in matters of radio frequency electromagnetic energy. This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 11... -
Page 13: Technical Data
Modulation and Coding Scheme MCS 1 – 4. SAMBA 75 supports two protocols PAP (Password Authentication Protocol) and CHAP (Challenge This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 12... - Page 14 Bi-directional bus for AT commands and data Baud rate: 1.2 bps ... 460 kbps USB 2.0 Full Speed (12 Mbit/s) slave interface This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 13...
-
Page 15: Power Consumption
GSM 900/850 (3 Rx, 2 Tx), Tested (Upload 2 x TX) GSM 1800/1900 Table 3: Power consumption of GSM/GPRS parts This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 14... -
Page 16: Interfaces In Overview
600 – 700 mA) when the GPRS/EDGE data transfer is in progress. Figure 2: Mini-USB pin-out (interface A) This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 15... -
Page 17: Interface B (Optical Interface)
The SIM interface controls a 3V SIM card. This interface is fully compliant with GSM 11.11 recommendations concerning SIM functions. Figure 4: SIM Card interface This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 16... -
Page 18: Functional Description
USB device initialization or USB device error. DATA (LED) flashes Indicates incoming/outgoing Modem Data Traffic Table 8: Modes of the LED’s and associated functions This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 17... -
Page 19: Gsm/Gprs Application Interface
(PSU-ASIC) disconnects the supply voltage from the base band part of the circuit. Only a voltage regulator in the PSU-ASIC is active for powering the RTC. Software is This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 18... -
Page 20: Alarm Mode
AT commands is accessible. 5.2 Power Up / Power Down Scenarios In general, be sure not to turn on SAMBA 75 while it is beyond the safety limits of voltage and temperature. SAMBA 75 would immediately switch off after having started and detected these inappropriate conditions. -
Page 21: Automatic Shutdown
Furthermore, take into account that there is a delay until the network proceeds to a lower or, accordingly, This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 20... - Page 22 This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 21...
-
Page 23: System Requirements
Make sure that the SIM card is sit firmly into the SIM card reader slot. See also figures below. This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 22... -
Page 24: How To Use Samba 75 Phone With A Terminal Software, Only
During the installation of the SAMBA 75 driver, please, follow the on-screen instructions. Insert the CD-ROM into your computer CD drive This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 23... - Page 25 The SAMBA 75 is not already plugged into the USB interface of your PC, plug Figure 7: Connect USB connector of SAMBA 75 to the USB serial port of PC. (Note that, the SAMBA-USB-Kit is not a part of modem SAMBA 75).
-
Page 26: Setup Hyperterminal Program
SAMBA 75 phone. To test the SAMBA 75 phone type on the terminal screen: AT<enter> Modem responds: This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 25... -
Page 27: Making A Dial-Up Networking
The included software support also a comprehensive overview, and an easy and quickly way to start up this application when the SAMBA 75 is already registered into the GSM network. This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 26... -
Page 28: Data And Fax Communication
Group 3 compatible. The SAMBA 75 phone can also be controlled with AT Commands. For more information, refer to the AT-Command manual, which is free available on the Falcom’s homepage. This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 27... -
Page 29: Rf Exposures
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 28... -
Page 30: Appendix
If the problem persists, avoid using GPRS connection during the time when network traffic is overloaded, or move to a location where signal reception is better. This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 29... - Page 31 To use some advanced call functions (such as call divert, call barring or call waiting), you need to subscribe them to your operator. This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission. Page 30...
