- Page 1 HTTP://WWW.FALCOM.DE/ This document is available at TANGO Hardware description Version 1.04...
-
Page 2: Table Of Contents
Reset configuration........................24 GENERAL GUIDELINES FOR THE USE OF THE TANGO ................25 ........................25 ETTING STARTED & ................... 25 ARDWARE SOFTWARE REQUIREMENTS This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 1... - Page 3 F. Beqiri Chapter “Firmware update” removed. 1.04 F. Beqiri updated. Table 1 Determination for DTE or DCE connection (Chapter 2.1.8.3) added. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 2...
- Page 4 FALCOM GmbH. FALCOM GmbH. No patent liability is assumed with respect to the use of the information contained herein. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 3...
-
Page 5: Introduction
FME-female antenna connector GSM/GPRS Class B/multi-slot class 2, TANGO-900/1800-2-G2 FME-female antenna connector TANGO-850/1900-1 GSM only, SMB-male antenna connector Available soon This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 4... -
Page 6: Scope Of The User's Guide
The first one is only GSM and the second one is GSM/GPRS modem. The GSM and GSM/GPRS versions have the same specifications unless otherwise specified. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 5... -
Page 7: Used Abbreviations
• ETSI GSM 07.07 “AT command set for GSM Mobile Equipment” • ITU-T V.25ter “Serial asynchronous automatic dialling and control” This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 6... -
Page 8: Security
Do not hold the antenna when the modem is « IN USE ». Holding the antenna affects call quality and may cause the modem to operate at a higher power level than needed. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 7... -
Page 9: Antenna Care And Replacement
Your modem while the plane is on the ground. To prevent interference with cellular systems, local RF regulations prohibit using Your modem whilst airborne. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 8... -
Page 10: Children
It is also recommended to use the equipment not close to medical devices as for example hearing aids and pacemakers. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 9... -
Page 11: Safety Standards
: Directives of the European Community, Directorate General V in Matters of Radio Frequency Electromagnetic Energy. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 10... -
Page 12: General Characteristics
Telephony (TCH/FS) & Emergency calls • Full Rate, Enhanced Full Rate and Half Rate • Dual Tone Multi Frequency function (DTMF) This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 11... -
Page 13: Short Message Service (Gsm And Gprs Mode)
SIM Toolkit Class 2 • SIM, network and service provider locks • Real Time Clock • UCS2 character set management This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 12... -
Page 14: Interfaces
5/0 (maximum) Serial interface is applied and working. Table 3: Power consumption at 24 VDC. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 13... -
Page 15: Tango-900/1800-X-G2
Serial interface is applied and working. GPRS 84.46 mA in transmit mode at power level 5 Table 5: Power consumption at 24 VDC. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 14... -
Page 16: Tango-900/1800-X -G10
2.1.7 Temperature Range Operating temperature range: -20°C to + 55°C Functional temperature: -20°C to + 70°C Storage temperature: -30°C to + 85°C This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 15... -
Page 17: Rf Characteristics
All TANGO series are designed for use as a DCE unit. Based on the aforementioned conventions for DCE-DTE connections it communicates with the customer application (DTE) using the following signals: This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 16... -
Page 18: Interfaces
SIM card reader for small SIM cards (3V) Interface F LED’s for status indication Table 9: Interface specifications of the Modem This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 17... -
Page 19: Interface A (4-Pin Connector)
A cable, included in the package shall be used for power supply connection. For more deteils see Appendix chapters and 5.1.1. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 18... -
Page 20: Interface B (9-Pin D-Sub Connector)
RTS ↔ Request To Send CTS ↔ Clear To Send RI ↔ Ring Indicator Table 10: Pin assignment of the standard RS232 connector This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 19... -
Page 21: Interface C (8-Pin Rj45 Connector)
Power output 10V ± 5% 150mA TxD ↔ Transmitted Data RxD ↔ Received Data Ground SPK+ SPK- MIC+ MIC- Table 11: Pin assignment of RJ45 This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 20... -
Page 22: Interface D (Antenna Interface)
The SIM interface controls a 3V SIM Card. This interface is fully compliant with GSM 11.11 recommendations concerning SIM functions. Figure 6: SIM interface (interface E) This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 21... -
Page 23: Interface F (Optical Indicator Interface)
Power off or interface C in use. • Yellow light: Power on, interface B in use or both interfaces (B & C) are not connected. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 22... -
Page 24: Ignition Line
RTS (or remove connection). With the interface C you have the audio and control functionality on one interface. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 23... -
Page 25: Reset Configuration
AT+CFUN=1,1 could be used. This will de-register the modem from the network and bring it into the state before the PIN has been entered. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 24... -
Page 26: General Guidelines For The Use Of The Tango
Note: Please use antenna designed for GSM 900/1800 or 850/1900 MHz operation. Incorrect antenna will affect communication and even damage the modem. Figure 8: Connect the GSM antenna This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 25... -
Page 27: Installing The Sim Card
9-pin Sub D-male serial cable to the 9-pin serial interface port on the TANGO modem, as shown in Figure 12.b This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 26... -
Page 28: Connecting The Dc Power Supply
Note: Do not used the external cable for power supply without a (car voltage) voltage adapter. Figure 13.a: Connect the DC power supply Figure 13.b: Power supply cable This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 27... -
Page 29: Mounting The Terminal
(PC, television etc). To avoid interference, place the terminal far enough from other electronic devices. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 28... -
Page 30: Terminal Emulator Setup
On Windows 2000, start the Hyper Terminal program. Assign the name for a new session on the displayed window. Figure 16: Assign the name for a new session This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 29... - Page 31 Figure 18: Check the response from TANGO Now you can configure the TANGO modem according to your requirements and according to the AT-Command set. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 30...
-
Page 32: Getting Started To Gprs Network
Click Start button, point to Settings, then click Control Panel. Double click the Modem icon. Figure 19: Add a new Modem. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 31... - Page 33 Choose the COM port number where the TANGO modem is connected to, then press Next button. Figure 22: Selected ports. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 32...
- Page 34 Properties button from the modem panel. Figure 23: Installed modem. Set the speed to 115200. Figure 24: Select the maximum port speed. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 33...
-
Page 35: Making A Dial-Up Networking
GPRS-specific AT commands (check out the GPRS AT command manual). The GPRS AT command manual is available on the Falcom’s Website for download: www.falcom.de/service/manual/ This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 34... -
Page 36: Making A Dial-Up Networking
Figure 27: Continue the new connection. Activate the Dial-up to private network radio button, then click Next. Figure 28: Network connection type. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 35... - Page 37 Now you need to edit some more settings, Right-click just-made GPRS dial-up icon, then click Properties. Figure 31: Some more settings. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 36...
- Page 38 As next select the Networking tab, choose on the Internet Protocol (TCP/IP) component, then press Properties button. Figure 33: Componnent (TCP/IP) configuration. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 37...
- Page 39 Dial number on the corresponding input field (or refer to your network operation’s instruction). Figure 35: The dialog box of registration. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 38...
- Page 40 TANGO modem within 2 or 3 seconds will be able to build a connection to the Internet. Figure 36: Pre-Dial Terminal Screen. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 39...
-
Page 41: Communications Software
You can use the TANGO modem with most commercially available communications applications, such as Microsoft Exchange, Microsoft Outlook and Netscape Navigator. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 40... -
Page 42: Basic Operation
CME ERROR: 3 PIN already entered (with + CMEE=1 mode) Save AT&W The configuration settings are stored parameter non-volatile This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 41 memory... -
Page 43: Troubleshooting
Check also the SIM card, and be sure to enter PIN code if needed. It's also worth to check the MS's IMEI. 3.2. Failure to activate a session This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 42... - Page 44 If they are so, select them one by one, and for each one hit 'free' to tell Windows this interface is now down and must done ignored when routing. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 43...
-
Page 45: Housing
TANGO VERSION 1.04 4 Housing Figure 40 Housing of TANGO versions -xxx/xxx-1(-xx). This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 44... -
Page 46: Housing Of Cradle
TANGO VERSION 1.04 4.1 Housing of cradle Figure 41: Housing of cradle. Figure 42: View of cradle. This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 45... -
Page 47: Appendix
The connector of power cable is a Micro-Fit 3.0 one. Part number: 43025-0400 (male) Figure 43: View of external cable for power supply This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 46... -
Page 48: Possible External Devices
The active handset HA-88 does not support SMS. The figure below shows the layout of the active receiver HA-88. Figure 44: View of active receiver HA-88 This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 47... -
Page 49: Operation Of The Active Receiver
Figure 45: Designed of main functions to the active receiver HA-88 5.2.2 Interface Figure 46: Pin description of active receiver HA-88 This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 48... -
Page 50: Possible External Antenna
Follow the characteristics to install a headset: 2KΩ differential Microphone impedance Microphone bias voltage 0,5mA Microphone input current >32Ω (<1nF) Speaker impedance This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission. Page 49...
