Microseven
MSH-RD080PTW IR Middle Speed P/T IP Camera
®
4. Instructions for Main Parts
⑦
⑥
⑤
④
① Audio out put terminal (yellow)
② Video output terminal
③ Audio input terminal (black)
④ Power Supply Connector
DC 12V power supply connector (please connect according to the marked polarity.)
⑤ USB Port
⑥ Alarm input/output cable
⑦ RJ45 network connector
⑧ Dome body
⑨ IR LED board
⑩ Lens
①
②
③
⑧
⑨
⑩
© 2002-2008 Microseven Systems, Inc. All Rights Reserved.
- 7 -
