AP-VP280 BcN Video Phone, Release 1.10
[Table 1-4]
No.
Name
SW
(1)
(2) DC 5V 5A
(3) USB
(4) LAN
(5) PC
(6) RS232C
(7) AIN
(8) AOUT
(9) VIN
(10) VOUT
(11) S-Video
(12) PSTN
Description of the Connectors on the Rear Side
Description
Power Switch
DC 5V 5A adapter port
Universal Serial Bus connector in the standard of 1.1 for transmitting 12Mbps at
maximum and connecting to USB memory devices.
Fast Ethernet port (10/100Mbps for connecting to the uplink (RJ45)
Fast Ethernet port (10/100Mbps for connecting to the downlink (RJ45)
Console port for network management and camera control (RJ45)
Audio Input port for connecting an external device such as microphone. Use
the remote control to configure MIC and Line In
Audio Output port for connecting an external device such as headphone or
speaker
RCA composite video input port for connecting video input devices such as camera
or DVR player.
RCA composite video output port for connecting analog video output devices such
as TV
S-VIDEO video output port for connecting video output devices such as high video
quality TV, projector and PDP.
1-port PSTN Backup port for accommodating PSTM Central Office line.
