AP-VP280 BcN Video Phone, Release 1.10
Menu Option
Call transfer mode
Confer. Service Tag
Confer. Service Name
Enable ping
Media Channel
Min se
Retry Count
The Other Party ID
Secondary Path
Domain Setup
Signaling Port
SIP Server

[Table 4-29] Description of SIP Menu Options

Description
Choose an option to determine the call-transfer-mode. The available options basic
and attend.
Enter a VoIP tag for a conference
Specify a name for conference service
For using the AP-VP280 in the NAT/Firewall configuration, enter a Firewall address
to verify the actual public IP
Transmit a RTP Session to listen to the inband ringbacktone of PSTN in
NAT/Firewall network configuration
Specify a setting for session timer
Assigns SIP UA retry count to the transmission count of SIP INVITE
If the trying message for the INVITE does not come in a specified time due to a
network failure, the AP-VP280 sends the next INVITE message. 10 is set at default
and the general setting is 3.
When the user-name is not numeric, but textual, it is applied within the message.
This is applied when the inbound call number is not numeric but textual.
Transmit From/To field to SIP message to a specified domain instead of an IP
address.
5060 is set at default and this option is used to make a change
Choose an option to set SIP Server
