AP-VP280 BcN Video Phone, Release 1.10

Chapter 6. Appendix

This Appendix describes the pin specification of the cables used for AP-VP280.
• Console port signal and pin-out (RJ-45 to DB9)
• Pin-out of the UTP cable (RJ-45 to RJ-45)
Console Port Signal and Pin-Out
The built-in RJ-45 to DB9 (female DTE connector) cable is used to connect the console port of
this product to the PC where the terminal emulator software operates.
Console Port (DTE)
Signal
RTS
DTR
TxD
GND
GND
RxD
DSR
CTS
[Table 6-1]
Console Port Pin-Out
RJ-45
RJ-45 Pin
1
2
3
4
5
6
7
8
AddPac Technology Proprietary & Documentation
DB-9
DB-9 Pin
8
6
2
5
5
3
4
7
256
Console Device (PC)
Signal
CTS
DSR
RxD
GND
GND
TxD
DTR
RTS
