Operation - Currie tech Izip Assembly Manual

Battery
Installation:
Your bicycle comes with a 24 volt Lithium-battery. To install the battery, simply
as shown in photo Q.
This type of battery does not have a 'memory', and riding on a partial charge will not harm the battery in
any way. Recharge time for this battery is 4-6 hours to reach a full charge.
Locking:
A lock is integrated into the battery pack to keep it in place while riding. It is recommended that the battery
pack be locked whenever you are riding in order to maintain a strong connection.
included keys (usually in the parts box or rubber-banded to the rack), making sure the lock cylinder fully engages into the rack. All keys included with
your bicycle are identical.

Operation

On Via Rapido bicycles, the electric assist functions are controlled using the handlebar-mounted control
pad below the throttle (Photo S). The red ON/OFF toggle button is used to turn the system on or off,
indicated by the glowing lights on the throttle. The green PAS/TAG toggle button is used to switch between
'PAS' (Pedal Assist) and 'TAG' (Twist and Go) modes. Setting the button to the 'out' position sets the bike
to TAG mode; the 'in' position sets the bike to PAS mode.
On Eco Ride bicycles, the PAS/TAG button is attached to the throttle, but it acts exactly the same as that
of the Via Rapido. The Eco Ride does not have a handlebar-mounted power switch; the switch is located
on the rack between the seat post and the battery. (Photo T)
PAS (Pedal Assist)
In this mode, the twist-throttle is only active when the pedals are in forward motion. A magnet
ring on the bottom bracket spindle rotates when the pedals are turned. A sensor picks up this
rotation and activates the throttle when necessary. After a few seconds of pedaling in this
mode, the motor will automatically spin up to 50% power to provide additional assistance.
TAG (Twist and Go)
In TAG mode, the twist-throttle is always active. The pedal sensor is disabled in this mode,
and the motor will not activate unless the throttle is turned.
1-800-377-4532
Currie Technologies
Technical and Customer Service
Q
slide it into the rear rack ,
After sliding a battery pack into place, lock it with one of the
S
T
Eco Ride power
switch
• Remove all remaining packaging on the bike.
• Check the operation of your front and rear brakes
by pushing the bike forward and operating the brake levers.
• Check the tightness of all nuts and bolts
, especially the stem bolts and the bolts securing the brake levers and shifters to the handlebars.
• Make sure the stem's wedge bolt is tight.
Check that it is tightened properly by standing over the front wheel, holding it with your thighs, then
trying to turn the handlebars. If the handlebars can be turned independently of the wheel, the wedge bolt must be tightened further.
• Make sure your front wheel is secure in the frame.
Refer to the appendix to this guide discussing quick release levers for detailed
instructions on using quick releases.
• Make sure your tires are filled to the pressure recommended on the sidewall.
a fall. We recommend using a bicycle pump with pressure gauge.
• Test power
: lean the bike on its kickstand, raising the rear wheel off the ground. When the bike is powered on (indicated by the throttle lights )
you can test system power by twisting the throttle in TAG mode and watching the rear wheel. Refer to the troubleshooting chart on this page for
assistance if the bike will not power on.
Refer to owner's manual for detailed troubleshooting chart
Bike won't turn on (no lights on Battery not seated properly against rack terminals
throttle) Need to press handlebar ON/OFF switch
Battery not charged
Throttle lights work, but motor
Bike may be in Pedal Assist mode. Press the green button next to
will not run the throttle to change to Twist-and-Go mode.
Brakes rub when riding Re-adjust brakes, referring to owner's manual
Gears/chain make clicking or Re-adjust drivetrain, referring to owner's manual
grinding noises while riding
Can someone help me with...? Call the Currie Technologies technical and customer service
department at 1-800-377-4532
Before your first ride...
Over- or under-inflated tires can blow off the rim and cause
1-800-377-4532
Currie Technologies
Technical and Customer Service
