Exit: 【ESC】
Playback switch: When in 2-ch playback, press【PREV】to switch between main channel and second channel.
Note: When DVR is busy, if you select high play speed, maybe there is difference for actual play speed.
Exit playback

Motion Detection Alarm

If you enable this function, when there is motion detected, DVR will make alarm.
Step 1: Enter into "Image Setup" menu:
Step 2: Select camera: Use【 】【 】key to select one camera.
Step 3: Select motion detection sensitivity: On the right side of "Motion Det. Level" item, there is a list box. That is motion detection sensitivity. There are 7 options, from 0
(the lowest) to 5 (the highest). You can use【↑】【↓】keys to select one. If you select other options, it will activate "Motion Area Setup" button and "Policy Setup" button. If you
select low sensitivity such as 0, only when there is great motion detection, will the DVR respond. On the other side, for high sensitivity such as 5, DVR will respond with small
motion detection.
Step 4: Motion area setup: You must define motion areas so that DVR will response when there is motion in those areas. Move "Active Frame" to "Area" buton on the right
side of sensitivity list box, press【ENTER】key, you can enter into "Motion Area Setup" interface.
