Playback By Time; Operation When Playback - LJD Digital Security COLOSSUS Quick Start User Manual

"Search" button and press【ENTER】key, DVR will search and list the matched files.
If the matched files are more than 8, you can use "Page No." to select page (use numeric keys or【↑】【↓】keys to select page). In the file list box, use【↑】【↓】keys to
move the scroll bar to the file, press【ENTER】key to playback the file. If the second channel is selected, these two channels can be playbak synchronously.
If DVR can not find the matched files, a failure dialog will pop-up.
2. Playback by Time: In the playback interface, select main channel, second channel (2-ch playback), record type and time section, move "Active Frame" to "Play" button,
press【ENTER】key, DVR will start to playback based on time section.

Operation when playback

Playback picture:
One Channel Playback
At the bottom of image, there is an information bar and the following information is included: Volume, Play Progress, Play Speed, Played Time and File Total Time.
Display/Hide information bar: 【MENU】
Open/Close sound: 【PLAY】
Adjust play progress: 【←】(Backward),【→】(Forward). The unit is "%".
Adjust play speed: Normal speed is "1x". Use 【↑】to increase play speed ( 2X, 4X,
8X and MAX). Use【↓】to decrease play speed (1/2X, 1/4X, 1/8X and Frame by Frame)
Pause/Continue: Press 【ENTER】to pause/continue playback. If played frame by frame, Press【ENTER】to paly one frame.
Copy segment:【EDIT】
Two Channels Playback
Page 4
