  • Page 1 CV 41 Vehicle Mount Computer (Windows CE) CV41C User Guide...
  • Page 2 Intermec Technologies Corporation. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. © 2012 by Intermec Technologies Corporation. All rights reserved.

  • Page 3: Table Of Contents

    Remove the CV41 from the Smart Dock ........
  • Page 4 Choose a Target Location ..........35 Install Applications Using SmartSystems Foundation Console....36 CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 5 Load a Certificate ............71 CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 6 USB Port ..............97 CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 7 Standard Characters ............104 CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 8 Contents viii CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 9: Before You Begin

    All warranties are expressly disclaimed, including the implied warranties of merchantability and fitness for a particular purpose. Web Support Visit the Intermec website at www.intermec.com to download our current manuals (in PDF). CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 10: Send Feedback

    1 Visit the Intermec website at www.intermec.com. 2 Click the Products tab. 3 Using the Products menu, navigate to your product page. For example, to find the CV41 computer product page, click Computers > Fixed Vehicle Computers > CV41. 4 Click the Manuals tab.

  • Page 11: Patent Information

    7,139,870; 7,159,764; 7,206,338; 7,208,916; 7,210,633; 7,271,679; 7,298,791; 7,325,741; 7,327,988; 7,336,853; 7,451,441; 7,564,799; 7,572,990; 7,580,395; 7,590,425; 7,633,550; 7,669,201; 7,761,864; 7,888,913; 7,895,267; 7,924,346; 7,962,104; 8,002,173; 8,014,354; 8,064,924. There may be other U.S. and foreign patents pending. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 12 CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 13: About The Computer

    About the Computer This chapter introduces the CV41 Vehicle Mount Computer with Windows® CE operating system. Use this chapter to learn about the basic features and available accessories.

  • Page 14: About The Cv41 Vehicle Mount Computer

    The CV41 also contains an internal UPS battery. When fully charged, the battery can power the CV41 for a minimum of 30 minutes when the C41 is not attached to the dock, or when vehicle power is interrupted.
  • Page 15 Chapter 1 — About the Computer CV41 Front View Callout Description Power button Speakers Microphone CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 16 Chapter 1 — About the Computer CV41 Back View with Quick Mount Smart Dock Callout Description Antenna connectors SIM card access panel (not available) COM 1 COM 2 USB connector CANBUS/audio connector Quick release handle Provision for padlock Provision for laptop security cable...

  • Page 17: Mount And Power The Cv41

    Connect the Smart Dock to a DC/DC Power Supply To provide power to the CV41, you must first provide power to the smart dock. The CV41 comes with a DC power cable to connect a a forklift running 10-60 VDC power. Other power supply options (sold separately) include: •...

  • Page 18: Connect The Smart Dock To A Ac/Dc Power Supply

    To provide power to the CV41, you must first provide power to the smart dock. If you are going to use the CV41 at a desk, use the AC/DC power supply. The AC/DC power supply must be connected to a 120 V, 60 Hz supply in North America, or to a 230 V, 50 Hz power supply outside of North America (appropriate AC cable not included).

  • Page 19: Remove The Cv41 From The Smart Dock

    RAM mount. 7 Press the Power button on the smart dock to turn on the dock. Power Button 8 Press the Power button on the CV41 to turn on the CV41. Power button Remove the CV41 from the Smart Dock The CV41 can easily be moved from one vehicle equipped with the smart dock to another.

  • Page 20: About Auto-On For The Cv41

    • the CV41 is placed into the dock. • the CV41 is placed into the dock and the vehicle is turned on. 1 Tap Start > Settings > Control Panel > Options. The Options screen appears. 2 Tap the Misc tab.

  • Page 21: About The Leds

    2 Tap the Misc tab. 3 Make sure that Enable Auto-On is not selected and tap OK. About the LEDs The LEDs on the CV41 tell the state of the computer. Use this section to learn about the connection and system LEDs. Connection LEDs...
  • Page 22 Callout LED State Description System Solid green The CV41 is on, or the CV41 is on but the backlight or display may be off. Blinking green The CV41 is in suspend mode, or external power is not every 4.5 seconds present.

  • Page 23: Cv41 Accessories

    Chapter 1 — About the Computer CV41 Accessories The CV41 does not ship with any accessories. All accessories are sold and ordered separately. For help, contact your local Intermec sales representative. CV41 Accessories Accessory Description Quick Mount Smart Dock The smart dock provides a mount for the CV41, and supplies conditioned power to the CV41.

  • Page 24: About Internal Ups Battery

    UPS battery usage. The changes you make to these settings are cumulative. For example, if you set the backlight and screen turn off times to 15 sec and the CV41 turn off times to 5 min, the CV41 actually turns off after 5 min and 30 sec.

  • Page 25: About The Backup Battery

    4 Tap OK when you are finished to save your changes. About the Backup Battery The CV41 has a permanent Lithium-Ion battery installed to maintain the time, date, and CMOS setup information for a minimum of 90 days. The Lithium-Ion battery is not user-replaceable and should last five years before it needs a replacement.
  • Page 26 Chapter 1 — About the Computer 2 Press the Power button to place the CV41 in Suspend mode. 3 Using a small Phillips screwdriver, remove the two screws that secure the SD card access panel. SD card access panel 4 Insert the SD card into the SD card slot.

  • Page 27: About The Touch Screen

    Note: If you are going to use the CV41 in extreme cold conditions for an extended period of time, you should turn on the power at room temperature for at least 15 minutes prior to using it. This process of “warming up”...

  • Page 28: Enable The Defroster

    3 Repeat Steps 1 and 2 to increase or decrease brigthness. Enable the Defroster If your CV41 contains a defroster, use it to help reduce condensation on an external surface when the computer is moving between sub-freezing and normal temperatures.

  • Page 29: Change The Volume

    5 Tap OK to save and exit the Heater screen. Change the Volume The CV41 can make sounds when you tap the screen or use an attached scanner. You can change the CV41 volume to suit your needs and the environment.

  • Page 30: Install An External Antenna

    Note: If you have the internal 802.11 antenna option, you cannot connect an external antenna to your CV41. GPS and WWAN antennas are optional and require an external antenna. 1 Secure the antenna to one of the antenna plugs on the CV41. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 31: About The Keypad

    Intermec sales representative. About the Keypad The CV41 comes with one standard keypad overlay and contains a backlight for low light conditions. Use the following sections to understand how to use the keypad. For information on remapping the keypad, download the Device IDL Resource Kit from the Intermec website at www.intermec.com/idl.

  • Page 32: Use The Modifier Keys

    Chapter 1 — About the Computer CV41 Keypad Overlay Use the Modifier Keys The CV41 keypad provides modifier keys to let you access additional characters, symbols, and functions printed on the keypad overlay. Once you understand how to use the modifier keys and key sequences, you can access all of the additional features printed on the keypad overlay.

  • Page 33: Capitalize Characters

    Press the key, and then the key. The Shift key LED lights up • green to show that the CV41 is in Caps Lock mode. To disable Caps Lock • When Caps Lock is enabled, press the key, and then the key.

  • Page 34: Set The Keypad And Display Backlight Timer

    1 Tap Start > Control Panel > Intermec Settings. The Intermec Settings screen appears. 2 Tap Device Settings > Power Management > Battery Power. The Battery Power screen appears. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 35: Transfer Files To And From Your Pc

    You can use Microsoft ActiveSync (Windows XP or earlier) or Windows Mobile Device Center (Windows Vista or Windows 7) to establish a connection between the CV41 and a PC. After you connect to your PC, you can transfer files, synchronize files, remotely debug, and perform other device management activities.
  • Page 36 Chapter 1 — About the Computer 5 Follow the onscreen instructions to establish a partnership. When the partnership is established, the Microsoft ActiveSync screen appears on your PC. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 37: Understand The User Interface And Intermec Applications

    Understand the User Interface and Intermec Applications Use this chapter to learn about the Windows Embedded CE 6.0 user interface and how to interact with the screen. You can also use this chapter to learn about the Intermec applications on your computer, as well as additional Intermec applications you can download.

  • Page 38: About The User Interface

    Learning to use the computer is easy. This section describes the basic concepts of using and customizing the vehicle mount computer and Windows CE. Use the Touch Screen Use your finger or stylus to move around the CV41 user interface. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 39: Use The Taskbar

    The Taskbar is located at the bottom of the screen. It displays the Start menu icon, the current time, the Input panel icon, and the current status of information such as external power connections, and battery power remaining. Use the following table for CV41 specific tasbar icons. Taskbar Icons...

  • Page 40: Use Pop-Up Menus

    Transcriber. The characters appear as typed text. 1 Tap the Input Panel icon. The Input Panel menu appears. 2 Tap LargeKB. The large keyboard displays on the desktop of the computer. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 41: Use Transcriber

    Set the Date and Time Use this section to learn how to set the date and time for the CV41. Optionally, you can sync the date and time to a local time server. 1 Tap the clock on the taskbar. The Date/Time Properties screen appears.

  • Page 42: Sync To A Local Time Server

    Chapter 2 — Understand the User Interface and Intermec Applications Sync to a Local Time Server To keep your CV41 time and date running accurately, you can sync it to a local time server through an internet connection. 1 Establish an ActiveSync connection.

  • Page 43: Applications You Can Download For The Computer

    Intermec website. Some of the applications require the purchase of a license to run. To find the application you want, go to www.intermec.com > Support > Downloads and then enter the information to find your computer. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 44: About Intermec Launcher

    IT resources, and lower the total cost of ownership for Intermec data collection equipment. SmartSystems Foundation can be downloaded at no charge from the Intermec website. For more information, visit www.intermec.com/SmartSystems. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 45: Manage The Computer

    Manage the Computer Use this chapter to learn how to remotely update, configure, and monitor your Intermec computers. You will also find information on installing and developing software applications as well as how to upgrade the system software.

  • Page 46: Manage The Computer In Your Network

    • save configuration settings from a single device and deploy those settings to many devices simultaneously. • remotely change settings on SmartSystems-enabled computers and peripherals. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 47: Develop And Install Applications

    Intermec sales representative. Develop and Install Applications Use the Intermec Resource Kits and the CV41 Software Development Kits to develop applications to run on the computer. The Resource Kits are a library of C++, .NET, Java, and web components grouped by functionality that you can use to create applications for the computer.

  • Page 48: Install Applications Using Smartsystems Foundation Console

    1 Connect to the computer using ActiveSync. 2 Copy the .cab files from your PC to the CV41. 3 Browse to the .cab files and tap the files to install them. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 49: Install Applications Using An Sd Card

    1 Copy your application file to the storage card. 2 Install the SD card in the CV41. 3 On the CV41, browse to the SD Card folder and run your application. Launch Applications Automatically There are two ways to launch an application automatically on a cold boot: •...

  • Page 50: Update The Operating System And Low-Level Firmware

    Chapter 3 — Manage the Computer Update the Operating System and Low-Level Firmware Use a USB flash drive to upgrade the operating system (OS) and low -level firmware of the CV41. Before you can update your CV41, you need: •...

  • Page 51: Update Bundles Using Smartsystems Foundation

    Update Bundles Using SmartSystems Foundation You can use the SmartSystems console to update the SSPB on your CV41. The console is part of SmartSystems Foundation and is available from the Intermec website. Before you can update your CV41, you need: •...

  • Page 52: Update Bundles Using A Activesync

    OS/Firmware/Drivers list. 3 Transfer the bundle file to \System directory on the CV41. 4 Tap on the file on the CV41. The computer reboots. After the computer reboots, the bundle files installs. When the installation is finished, the CV41 reboots once again.

  • Page 53: Configure The Computer

    Configure the Computer Use this chapter to learn about the available methods for configuring your computer and how to use Intermec Settings. You can also use this chapter to learn how to configure network communications and wireless security.

  • Page 54: How To Configure The Computer

    Remotely using Intermec SmartSystems Foundation. When you • use SmartSystems, you can remotely configure all of your CV41 vehicle mount computers as well as other SmartSystems-enabled Intermec computers and peripherals. For more information, see “Use Intermec Settings Remotely With SmartSystems...

  • Page 55: Start Intermec Settings

    If you see ... next to a menu option, there is only one more screen available. Most parameters are saved when you tap OK. Some settings , require you to reboot the computer for the changes to take effect. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 56 • Funk Security Settings • Microsoft Security settings • IP settings • Certificates • Radio bands • Security changes Bluetooth Bluetooth settings (power, discoverable, connectable, and so on) CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 57 Note: The Printer menu displays settings for Bluetooth connected printers. The settings that appear in the menu are dependent on the printer that is paired with the device. The printer needs to be paired using the Bluetooth Printing application. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 58 Port (read-only) Keep Alive Ping Interval Keep alive ping interval SmartSystems Information Menu SmartSystems Information Options Parameters You Can Configure Identity Identity information (hardware version, firmware version, OS version, and so on) (read-only) CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 59 None (displays applications that are licensed) RFID Menu RFID Options Parameters You Can Configure RFID Service RFID Service settings For more information on all parameters in Intermec Settings, see the Intermec Settings Command Reference Manual. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 60: Navigate In Intermec Settings

    Profile Settings is available from the Start > Programs menu so you can make it available to the end user for easy configuration. Profile Settings Screen CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 61: Restore Default Settings

    You can easily restore a menu to its default settings or all of the Intermec Settings parameters to their default settings if necessary. 1 Navigate to the menu that you want to restore to defaults. 2 Tap Menu > Restore Menu Defaults. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 62: Hide Menu Items In Intermec Settings

    Menu > Unhide All Items. Note: When you restore default settings in Intermec Settings, only the settings for visible items are restored to defaults. The settings for hidden menu items are not affected. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 63: Use Intermec Settings Remotely With Smartsystems Foundation

    USB and serial communications. Configure 802.11a/b/g (Wi-Fi) Radio Communications Make sure all components with antennas are at least 30 cm (1 ft) apart when power is applied. Failure to comply could result in equipment damage. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 64: Configure Bluetooth Communications

    4 Configure 802.11 security. For help, see “About Wireless Security” on page Configure Bluetooth Communications Your computer is Bluetooth™-enabled, which lets you connect to other Bluetooth devices, such as scanners or printers. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 65: Connect To A Bluetooth Scanner

    Connect to a Bluetooth Scanner You can connect the computer to an Intermec Bluetooth scanner, such as the SF51 or SR61. 1 Tap Start > Settings > Control Panel > Bluetooth Scanning. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 66: Connect To A Bluetooth Printer

    For help, see the next procedure. Note: You can also print wirelessly using Microsoft APIs with Bluetooth extensions for Winsock and Bluetooth virtual COM ports. For help, see the Bluetooth Resource Kit documentation. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 67: About Serial And Usb Communications

    For the SR30 or SR61T, you must purchase the correct scanner USB cable to use with the CV41. For more information, see the following table. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 68: Connect To A Serially Tethered Scanner

    Use this procedure to connect your computer to connect a tethered scanner and enable RS-232 communications. For the SR30 or SR61T, you must purchase the correct serial cable to use with the CV41. For more information, see the following table.
  • Page 69 • then tap OK. Set up the appropriate COM port settings by selecting Scanner Port Settings. 5 Tap Enable scanner port. 6 Check the Enable scanner port check box and tap OK. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 70: Create An Isp Connection

    5 Select the Dial-up Connection radio button. 6 Tap Next. 7 If you are using an external modem connected to your computer with a cable, select Hayes Compatible on COM1 from the Select a modem list. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 71 Chapter 4 — Configure the Computer 8 Tap Next. 9 Enter the access phone number and then tap Finish. 10 Double-tap on the connection you just created. 11 Tap Dial Properties. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 72: Create A Vpn Server Connection

    5 Step through the screens to set up your VPN connection. About Wireless Security The computer provides five types of security for your wireless network: • Wi-Fi Protected Access 2 (WPA2™) • Wi-Fi Protected Access (WPA) • 802.1x CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 73: Choose Between Microsoft And Funk Security

    CCX v4.0 compliance, support for LEAP and TTLS, and configuration for up to four profiles. To use Funk security, you need to select a profile. For help, see the next section, “Select a Funk Security Profile.” CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 74: Select A Funk Security Profile

    1 Make sure the communications and radio parameters on your computer are configured. 2 Make sure Funk is selected as your security choice. 3 Start Intermec Settings. 4 Choose Communications > 802.11 Radio > Funk Security. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 75 8 For Pre-Shared Key, enter the pre-shared key or passphrase. The pre-shared key must be a value of 32 hex pairs preceded by 0x for a total of 66 characters. The value must match the key value on CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 76 Load a user and root certificate on your computer. For help, see “Load a Certificate” on page b For Validate Server Certificate, choose Yes. c Enter a User Name and Subject Name. 11 Save your settings. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 77 4 Choose Communications > 802.11 Radio > Funk Security. 5 Select the profile you want to configure. 6 For 8021x choose None. 7 For Association, choose Open. 8 For Encryption, choose WEP. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 78: Select Microsoft As Your Security Choice

    With Microsoft as your security choice, you can configure: • WPA or WPA2 • 802.1x • Static WEP CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 79 Select the certificate you want to use from the list. The User Logon dialog box appears. d Enter a User Name and Domain and tap OK. e Tap OK to exit the Certificates dialog box. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 80 66 characters. The value must match the key value on the authenticator. The passphrase must be from 8 to 63 characters. After you enter a passphrase, the computer internally converts it to a pre-shared key. 7 Save your settings. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 81 Enter a User Name, Password, and Domain. Select Save Password if you want to save the password for future authentication sessions. d Tap OK to save the Microsoft Security settings. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 82 1 Start Intermec Settings. 2 Choose Communications > 802.11 Radio > Microsoft Security. 3 For Network Authentication, choose Open. 4 For Data Encryption, choose Disabled. 5 Tap OK. Your settings are saved. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 83: Load A Certificate

    Tap OK. A dialog box appears asking if you want to load the root certificate. e Tap OK. The Enrollment Tool message box appears telling you that the certificate has been added. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 84 Tap Import Certificates to install the selected certificate. c In the CertImportUI screen, tap the <<< button next to the Select pfx to import text field. d Select the root certificate from the list. e Tap Import Certificate. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 85: Troubleshoot And Maintain The Computer

    Troubleshoot and Maintain the Computer If you encounter any problems while using the computer, look in this chapter to find a possible solution. You will also find information on routine maintenance.

  • Page 86: Troubleshoot Your Computer

    Make sure the network name matches the access point network name. The access point may not be communicating with the server. Ensure the access point is turned on, properly configured, and has 802.1x security enabled. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 87: Troubleshoot 802.1X Security

    Check 802.11 Network Status If you have trouble connecting to your 802.11 wireless network: • Make sure you have correctly set network parameters on the computer. • Check your wireless security settings. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 88 Tap Ping. The graph shows the amount of time it takes for the host to return the ping. Tap List to see this information in a list format. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 89: Troubleshoot Reading Bar Codes

    The imager hardware trigger might be disabled in Intermec Settings. To check the setting go to Start > Settings > Control Panel > Intermec Settings > Data Collection > Scanner Settings. Hardware trigger should be checked. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 90 ASCII scanner. engine. • The scanner may be in an unknown state. Reset the scanner to the factory default settings by scanning the manufacturer’s configuration bar code, and reconnect the scanner. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 91: Troubleshoot Operating The Computer

    You cannot type a character on You may have locked a modifier key on the keypad. Press the the keypad or you can only type necessary key sequence to unlock the key. uppercase or lowercase letters. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 92: Call Product Support

    Settings. Consult your application developer for information on your custom application. Find Your Configuration Number Use the following procedure to help you find the configuration number of your computer. • Look at the label on the back of the computer. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 93: Find Your Operating System Version

    Cold Boot the Computer If the computer seems to be locked up, try cold booting it. Cold booting the CV41 restarts the computer and RAM is cleared, while the registry and files under \System folder are preserved. 1 Tap Start > Settings > Control Panel > Registry.

  • Page 94: Clean Boot The Computer

    If the CV41 stops responding, or you plan on shipping the CV41, you need to disconnect the UPS battery. 1 Press and hold the Power button on the CV41 for ten seconds to turn the computer off. 2 Pull down on the red quick release handle and lift the bottom of the CV41 up and away from the dock.
  • Page 95 5 Reinstall the SIM card access panel and tighten the screws to a torque to a value of 4-5 in/lbs. Once power external power is reconnected to the CV41, the UPS battery automatically reconnects. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 96: Replace The Fuse

    Chapter 5 — Troubleshoot and Maintain the Computer Replace the Fuse The CV41 uses a 10 A time delay (slow blow) fuse, which is located on the smart dock. If you need to replace the fuse, make sure that you replace it with the same size, rating, and type of fuse (Littelfuse 03260 10 MXP or equivalent).
  • Page 97 Chapter 5 — Troubleshoot and Maintain the Computer 3 Wipe off the touch screen. Do not allow any abrasive material to touch these surfaces. 4 Wipe dry. CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 98 Chapter 5 — Troubleshoot and Maintain the Computer CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 99: Specifications And Default Settings

    Specifications and Default Settings...

  • Page 100: Physical And Environmental Specifications

    Internal power supply: 10 to 60 VDC AC adapter: 90 to 240 VAC DC power supply : 72 to 96 VDC Backup battery (CMOS) Field replaceable, rechargeable lithium-ion battery, 30 minutes of life at -20 °C (-4 °F). CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 101: Hardware

    Dual internal anennas or optional external antennas Removable storage Secure Digital Operating system Microsoft Windows CE 6.0 Standard Communications • 802.11a/b/g • Bluetooth • • Serial Wireless LAN Data rates Supports all 802.11a/b/g data rates. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 102: Default Configuration

    BT-Configure On Connect Overwrite with computer settings Symbology Settings Symbology Default Value AustraliaPost Disable Aztec Disable Disable CanadaPost Disable Codabar Disable Codablock A Disable Codablock F Disable Code 11 Disable Code 39 Enable CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 103 QR Code Disable Standard 2 of 5 Disable Telepen Disable TLC 39 Disable Symbology Option Settings Symbology Option Settings Default Value Preamble None (Disable) Postamble None (Disable) Symbology Identifier Disable Multicode Disable CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 104: Communications

    Different Consecutive Timeout Center Decoding Disable Center Decoding Tolerance Communications Use communications settings to configure how the computer communicates with the network. Communications Settings Communications Setting Default Value Device Name Intermec CV41 CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 105: Device Settings

    Default Value Keypad Backlight Enable Heater Settings Screen Setting Default Value Screen Heater Enabled Screen Heater Turns On at 40 °C Keypad Settings Keypad Setting Default Value Caps Lock on Reboot Disabled CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 106 Screen Settings Default Value Brightness High Screen Blanking On Motion Disable Screen-On Delay After Motion Stops (sec) 1.0 Sound Settings Sound Setting Default Value Beeper and Voice Headset Beeper Screen Taps Key Clicks CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 107: Core Messaging Service Settings

    90 seconds Network Device Health 45 seconds Printer Network Device Health Refresh (seconds) 45 RFID Settings Use RFID settings to enable the RFID service. RFID Settings RFID Settings Default Value Enable RFID Service CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 108: Virtual Wedge Settings

    Label Encoding (Code Page) 1252(D)-ANSI Win3.1 US Port Pin Assignments Use this section to learn about the ports pin assignments on the CV41, smart dock, and cables. COM 1 and COM 2 Ports The COM 1 and COM 2 ports are located on the smart dock. By default, Pin 9 is configured to provide + 5 V for an external bar code scanner, or it can be configured to provide RI.

  • Page 109: Usb Port

    USB host 1 data signal USBC_VBUS USB client (5 V detect from attached host) CANBUS/Audio Port The CV41 CANBUS and audio port is located on the smart dock. The CV41 cannot support CANBUS and audio simultaneously. CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 110: Power Supply Connector

    Optional CAN external power supply Power Supply Connector Power is supplied from the smart dock to the CV41 through the power connector. The power supply connector also provides a connection point for the vehicle chassis ground to be connected internally to the conductive chassis of the computer.

  • Page 111: Usb Dongle Cable

    Appendix A — Specifications and Default Settings The CV41 internal power supply can accept DC input voltages in the range of 10 to 60 VDC. Power Supply Connector Signal Description V In+ 10-60 nominal DC input + V In+ 10-60 nominal DC input +...
  • Page 112 USB client 5 V detect from attached host USB Dongle Cable Host Connector Signal Description 5V_USB USB power, current limited USB2N_A USB D- EUSB2PA_A USB D+ DGND USB power return Shell CGND Chassis ground CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 113 USB Dongle Client Connector Signal Description V In+ 12 to 48 V nominal DC input + V In+ 12 to 48 V nominal DC input + V In- Input - V In- Input - CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 114 Appendix A — Specifications and Default Settings CV41 Vehicle Mount Computer (Windows CE) User Guide...

  • Page 115: Keypads And Keystrokes

    Keypads and Keystrokes...

  • Page 116: Standard Characters

    (SIP), which you can access by tapping the keyboard icon on the touch screen. CV41 Alphanumeric Characters To Enter Keypad CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 117 Appendix B — Keypads and Keystrokes To Enter Keypad CV41 Function Keys To Enter Keypad ¡ ¢ £ ¤ ¥ ¦ § ¨ © ª b ¡ b ¢ b £ b ¤ b ¥ b ¦ CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 118 @ (at symbol) # (pound) b & & (ampersand) % (percentage) : (colon) ; (semicolon) , (comma) $ (dollar) ! (exclamation) ? (question mark) - (hyphen or minus) . (period) + (plus) ‘ (apostrophe) CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 119 } (right curly brace) ~ (tilde) \ (backslash) / (forward slash) “ (quotes) Insert Delete ¦ (broken vertical bar) ̀ (grave) Forward Tab Backspace Up Arrow Down Arrow Left Arrow Right Arrow CapsLock CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 120 Enter Shift Space Start (Windows) Ctrl Ctrl CV41 Intermec Terminal Emulator Keys To Enter Keypad Attention Autolog Clear Duplicate EEOF Erase Find Field + Field - Fieldmark Help Home Keypad Menu Mode CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 121 Appendix B — Keypads and Keystrokes To Enter Keypad New Line Next Screen Page Print Previous Screen Remove Reset Return Roll Down Roll Up Select System Request View Down View Up CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 122 Appendix B — Keypads and Keystrokes CV41 Vehicle Mount Computer (Windows CE) User Guide...
  • Page 124 Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2012 Intermec Technologies Corporation. All rights reserved. CV41 Vehicle Mount Computer (Windows CE) User Guide *934-066-001* P/N 934-066-001...

This manual is also suitable for:

Cv41c

Table of Contents
