• Thumbwheel
• Universal asynchronous receiver/transmitter (UART)
• LEDs
• Push buttons
• Expansion interface: all ADSP-BF548 processor signals
• Other features
For information about the hardware components of the EZ-KIT Lite,
refer to the ADSP-BF548 EZ-KIT Lite Evaluation System Manual.
xii
CTS Corp rotary encoder
ADM3202 RS-232 line driver/receiver
DB9 female connector
10 LEDs: 1 power (green), 1 board reset (red), 1 USB (red),
6 general-purpose (amber), and 1 USB monitor (amber)
5 push buttons: 1 reset, 4 programmable flags with
debounce logic
JTAG ICE 14-pin header
USB OTG connector
interface connector
HOST
Blackfin power measurement jumpers
IDC connector
PPI1
and
SPORT2
SPORT3
TWI, SPI, timers,
Getting Started with ADSP-BF548 EZ-KIT Lite
IDC connectors
IDC connectors
UART3
