McQuay AGZ 030A Installation And Operation Manual

Air-cooled global chiller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Air-Cooled Global Chiller
Type AGZ 030A through 065A
60 Hertz, English and Metric
Scroll Compressors using Refrigerant R-22
© 1997 McQuay International
Installation and Operation Manual
IOM 686
Group: Chiller
Part Number: 062994901
Effective: March 1997
Supersedes: None
