Stamina 1773 Owner's Manual

Magnetic cross trainer elliptical
Hide thumbs
Table of Contents

Advertisement

Quick Links

CAUTION:
Weight on this product should not exceed 250 lbs.
2009, 08
This Product is Produced Exclusively by
2040 N. Alliance, Springfield, MO 65803
Customer Service
1 (800) 375-7520
www.staminaproducts.com
Owner's
Manual
WARNING
Exercise can present a health
risk. Consult a physician
before beginning any exercise
program with this equipment.
If you feel faint or dizzy,
immediately discontinue use
of this equipment. Serious
bodily injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur if
all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify the
following number.
Model#: 55-1773
STAMINA PRODUCTS
MADE IN CHINA
Product May Vary Slightly
From Pictured.
2009 Stamina Products, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1773 and is the answer not in the manual?

Questions and answers

Related Manuals for Stamina 1773

Summary of Contents for Stamina 1773

  • Page 1 MADE IN CHINA Weight on this product should not exceed 250 lbs. Product May Vary Slightly From Pictured. This Product is Produced Exclusively by 2040 N. Alliance, Springfield, MO 65803 Customer Service 1 (800) 375-7520 www.staminaproducts.com 2009, 08 2009 Stamina Products, Inc.

  • Page 2: Table Of Contents

    We recommend that two people be available for assembly of this product. Keep children away from the Magnetic 1773 Elliptical. Do not allow children to use or play on the Magnetic 1773 Elliptical. Keep children and pets away from the Magnetic 1773 Elliptical when it is in use.
  • Page 3 Magnetic 1773 Elliptical To help you get started, we have pre-assembled most of your Magnetic 1773 Elliptical at the factory with the exception of those few parts left unassembled for shipping purposes. Simply follow the few assembly instructions set forth in this manual.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the Magnetic 1773 Although Stamina constructs its products with the Elliptical. We take great pride in producing this finest materials and uses the highest standards of quality product and hope it will provide many hours...

  • Page 5: Equipment Warning & Notice Labels

    EQUIPMENT WARNING & NOTICE LABELS This chart is provided to help identify the warning & notice labels on the Magnetic 1773 Elliptical. Please take a moment to familiarize yourself with all of the warning & notice labels. Label is larger than actual size...

  • Page 6: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 7: Assembly Instructions

    (64), ARC WASHERS(M8)(87), LOCK WASHERS(M8)(89), and ACORN NUTS(M8x1.25)(85). STEP 2 Attach the REAR STABILIZER(3) to the MAIN FRAME(1) with BUTTON HEAD BOLTS(M8x1.25x 75mm) (68), ARC WASHERS(M8)(87), and LOCK WASHERS(M8)(89). NOTE: You can adjust the LEVELING CAPS(61) on the REAR STABILIZER(3) to keep the Magnetic 1773 Elliptical stable.
  • Page 8 ASSEMBLY INSTRUCTIONS Metal Fitting Cable End Bracket Spring Hook STEP 3 Refer to the inset drawing. Lay the UPRIGHT(6) on the floor close to the front of the MAIN FRAME(1). Set the TENSION KNOB(25) on the UPRIGHT(6) at position 8, so the CABLE END of the TENSION KNOB KNOB(25) extends out of the metal fitting as far as possible.
  • Page 9 ASSEMBLY INSTRUCTIONS LEFT RIGHT STEP 6 There is an "L" decal on the LEFT PEDAL ARM(4), and an "R" decal on the RIGHT PEDAL ARM(5). NOTE: The RIGHT PEDAL SHAFT(42) has right hand threads and is tightened by turning clockwise. The LEFT PEDAL SHAFT(41) has left hand threads and is tightened by turning counterclockwise.
  • Page 10 ASSEMBLY INSTRUCTIONS LEFT Look down from the top Pivot Tube Shaft Pivot Tube RIGHT STEP 8: There is an "L" decal on the LEFT HANDLEBAR(8), and an "R" decal on the RIGHT HANDLEBAR (9). To assemble the RIGHT HANDLEBAR(9), place a SPACER(51) and a LARGE WASHER(M16)(52) on the right side of the SHAFT on the UPRIGHT(6).
  • Page 11 ASSEMBLY INSTRUCTIONS Strap STEP 11 Refer to illustration A. Tie the STRAP to the plug end of the PULSE SENSOR WIRE(27). Pull the STRAP from the square hole on the top of the UPRIGHT(6) until the PULSE SENSOR WIRE(27) is pulled through and extends out of the square hole.

  • Page 12: Set Up Instructions

    SET UP INSTRUCTIONS Place the Magnetic 1773 Elliptical in the area where it will be used. It is recommended that the Magnetic 1773 Elliptical be placed on an equipment mat. The maximum operation dimensions of the Magnetic 1773 Elliptical are approximately 54 inches long x 59 1/2 inches tall x 24 3/8 inches wide. (These dimensions may vary up to one inch.) An area 4 feet wide x 7 feet long is required for safe operation of the Magnetic...

  • Page 13: Operational Instructions

    EXERCISE WORKOUT To start using the Magnetic 1773 Elliptical simply stand on the foot pedals with the front of your shoes close to the front edge of the pedal cap. Place your hands at a comfortable position on the handlebars.
  • Page 14 USING THE METER POWER ON: Pedal movement or press any button. POWER OFF: Automatic shut off after 4 minutes of inactivity. Resets all values to zero. Upper Display FUNCTION BUTTONS: MODE : Press and release to select each function for display on Upper Display or preset target values.

  • Page 15: Storage

    To store the Magnetic 1773 Elliptical, simply keep it in a clean dry place. The minimum rest dimensions of the Magnetic 1773 Elliptical are approximately 47 5/8 inches long x 60 1/4 inches tall x 24 3/8 inches wide. These dimensions may vary. Please measure your Magnetic 1773 Elliptical if exact dimensions are needed.

  • Page 16: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.

  • Page 17: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place Stretching Stretching while your muscles are warm after a proper warm-up and again after your strength...

  • Page 18: Product Parts Drawing

    PRODUCT PARTS DRAWING FRONT Strap BACK...

  • Page 19: Parts List

    PARTS LIST PART# PART NAME Main Frame Front Stabilizer Rear Stabilizer Left Pedal Arm Right Pedal Arm Upright Stationary Handlebar Left Handlebar Right Handlebar Lower Pivoting Arm Linkage Pulley and Axle Bearing (6003Z) Bearing Washer (M17) C Ring (17mm) V-Ribbed Belt Idler Arm Idler Wheel ø...
  • Page 20 PARTS LIST PART# PART NAME Plastic Washer (M8 x ø18 x 2mm thick) Round Plug (28.6mm) Spacer Large Washer (M16 x ø32 x 0.5mm thick) Dome Plug (28.6mm) Foam Grip Short Foam Grip Round Plug (25.4mm) Round Plug (24.8mm) Roller Roller Spacer Wheel Leveling Cap...

  • Page 21: Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customerservice@staminaproducts.com, or call us at 1-800-375-7520.

  • Page 22: Notes

    NOTES...

  • Page 23: Fax/Mail Ordering Form

    FAX/MAIL ORDERING FORM Please do not return the product. For your convenience, Stamina's Customer Service Department can be reached by email at customerservice@staminaproducts.com or toll free at 1-800-375-7520 (in the U.S.). Should a part be missing or a defective part found, please call us from 7:30 A.M. to 5:00 P.M. Central Time, Monday through Thursday and 8:00 A.M.
