Page 1: User Guide
Eycasa Door & House Wireless Video System User Guide Version 12/2013 Original user guide in German. Retain for future reference. - Page 2 ABUS Security-Center GmbH is not liable or responsible for direct or indirect damages resulting from the equipment, performance, and use of this product. No forms of guarantee are accepted for the contents of this...
- Page 3 English Explanation of symbols The triangular high voltage symbol is used to warn of the risk of injury or health hazards (e.g. caused by electric shock). The triangular warning symbol indicates important notes in this user guide which must be observed. This symbol indicates special tips and notes on the operation of the unit.
- Page 4 English Wireless transmission The wireless range depends on a variety of environmental factors. The local conditions at the installation site may have a negative impact on the range. A range of up to 100 m can be achieved if there is line of sight between the receiver and transmitter, and a range of up to 30 meters can be achieved indoors (this can be less depending on the situation in the building).
-
Page 5: Table Of Contents
English Contents Intended use ................................6 Eycasa system components ..........................6 Features and functions ............................7 Device description ..............................8 4.1 Description of the Eycasa main unit ........................8 4.2 Description of the Eycasa video door station ....................9 4.3 Description of the Eycasa outdoor camera ....................13 4.4 Description of the Eycasa Family Care camera .................... -
Page 6: Intended Use
Eycasa family: Eycasa outdoor cameras (monitoring of driveways or gardens). The system can manage a total of up to four cameras from the Eycasa product family. For a detailed description of functions, refer to Section 3, “Features and functions”. 2. Eycasa system components CASA30100 CASA30150 CASA30200 Eycasa video door station... -
Page 7: Features And Functions
English 3. Features and functions Eycasa door & house wireless video system for watching, speaking, listening, and switching The Eycasa door & house wireless video system set contains the Eycasa video door station and Eycasa main unit Secure wireless transmission using 2.4 GHz digital wireless for video and 1.9 GHz DECT for audio ... -
Page 8: Device Description
English 4. Device description 4.1 Description of the Eycasa main unit Used for writing short notes on the memo board. Dry erase Board marker board marker. Intercom for Eycasa video door station and Eycasa ... -
Page 9: Description Of The Eycasa Video Door Station
English Removable table mount, can be used instead of the included Table mount wall mount. 12 V DC / 1 A Power supply Device starts automatically when powered by line voltage. RJ45 connection Integrated network access, 10/100 Mbps. ... - Page 10 English Backlit doorbell button (not in battery mode). Backlighting switches on automatically in night mode (camera photo sensor). Doorbell button When the doorbell button is pressed, a connection to the Eycasa main unit is established with a video image. Built-in microphone for two-way voice communication with ...
- Page 11 English Connection examples for an electronic door opener/door bell Description of the terminal block Description Note 12V-24 Network connection for video door station 12-24V direct current or AC/DC 12-24V alternating current RELAY Terminal connector for electronic door opener. Potential-free relay, NO (normally open) RELAY Terminal connector for electronic door bell.
- Page 12 English Connection for an electronic door bell: Connect the electronic door bell to RELAY 2. Before use, ensure that your door bell has a suitable opening contact for triggering. The door bell is supplied with power via the door bell’s intended voltage source (separate power supply unit or batteries).
-
Page 13: Description Of The Eycasa Outdoor Camera
English 4.3 Description of the Eycasa outdoor camera Antenna Screw-on antenna for 2.4 GHz digital wireless. Photo sensor Sensor for switching between day and night mode. Camera Camera with fixed lens. -
Page 14: Description Of The Eycasa Family Care Camera
English 4.4 Description of the Eycasa Family Care camera Camera module with fixed lens and IR LEDs, including photo Camera sensor. IR-LEDs Built-in IR LEDs. Activated in night mode. ... -
Page 15: Pairing The System Components
English 5. Pairing the system components 5.1 Pairing the Eycasa components in the Eycasa main unit We recommend that you pair the video door station in the entrance area to camera position 1 (factory setting with the CASA31000). All other components can be paired to any of the other camera positions. Pair the components as follows: Note: The CASA31000 Eycasa video door station and Eycasa main unit included in delivery are... - Page 16 English First remove the battery compartment to be able to remove the front cover. You can now continue the pairing process for your video door station. The setup wizard of your main unit should show the following view: A notification message will appear that a camera already paired to the selected camera slot will be overwritten by this action.
- Page 17 English Your Eycasa main unit connects to your video door station. The process can take several seconds. The setup wizard will signal whether the process is complete or whether it needs to be repeated due to a pairing error. If the message “Video door station was successfully paired” appears, the pairing process is finished. The status LED goes out on your video door station, signaling readiness.
-
Page 18: Pairing The Eycasa Outdoor Camera
English 5.3 Pairing the Eycasa outdoor camera Ensure that your Eycasa outdoor camera is supplied with power. You can now proceed with the pairing process for your outdoor camera. The setup wizard of your main unit should show the following screen: Follow the instructions on the screen and press and hold the pairing button on the power cable of the camera. - Page 19 English Follow the instructions on the screen and press and hold the pairing button on the camera. The Status LED on the camera starts flashing red and green. Now press “Next”. Your Eycasa main unit then connects to the Family Care camera. The process can take several seconds. The setup wizard will signal whether the process is complete or whether it needs to be repeated due to a pairing error.
-
Page 20: Mounting The System Components
English 6. Mounting the system components 6.1 Mounting the Eycasa main unit The Eycasa main unit can be installed either on a table or wall. When delivered, the table mount is already attached, allowing you to place the device wherever you would like indoors. Alternatively, the back cover of the main unit can be replaced with the included wall mount. -
Page 21: Mounting The Eycasa Video Door Station
English Now place the main unit on the wall mount and connect the included power supply unit. Ž 6.2 Mounting the Eycasa video door station The Eycasa video door station can be mounted either horizontally or vertically. The video door station is designed for use in protected outdoor areas, thanks to its degree of protection of IP54. - Page 22 English You can now open the plastic cover of the doorbell button and attach your nameplate. For labeling, you can use the included nameplate or the PDF template on the included CD. 55 mm Connect the power (12–24 V AC/DC) and an optional electronic door opener (RELAY 1) and/or an electronic door bell (RELAY2) to the terminal block of the video door station.
-
Page 23: Mounting The Eycasa Outdoor Camera
English After connecting the power supply, mount the video door station on the house wall. The recommended installation height is 1.6 meters between the ground and camera module. Put on the video door station at the desired location and use the screw holes on the bottom shell to mark the drill holes. After finishing the wall mounting, put the door station back together to complete the installation. -
Page 24: Mounting The Eycasa Family Care Camera
English 6.4 Mounting the Eycasa Family Care camera Bolt the camera onto the bracket and select a suitable place to mount You can decorate the camera with one of the stickers provided. The camera should be mounted no further than 3 metres away from the child in order to ensure optimum visibility and reliable sound detection. -
Page 25: System Operation
English 7. System operation 7.1 Start-up of the Eycasa main unit Sequence: Connect the power supply unit to your Eycasa main unit. The device starts automatically after the line voltage is present. Wait until the boot process is complete. During initial start-up, the system language is set after the system boots. Select the language by pressing the corresponding country flag on the display. - Page 26 English Operates RELAY 1 on the video door station to open the door. Establish/terminate a voice connection to the video door station. Receiver Play a preset lullaby on the Family Care camera for 90 seconds. Lullaby The lullaby is repeated until 90 seconds have passed. You can end the lullaby manually by pressing the button.
-
Page 27: Event List And Event Behavior
English 7.3 Event list and event behavior Event list In the event list, the following control options are available: Changes the view to the event list. You can browse through the event list in steps of seven using the buttons. The event log includes 500 entries. Opens the general filter dialog of the event list. -
Page 28: Playback Of Event Recordings
English Battery strength: Shows the time of weak battery strength on an Eycasa video door station and Family Care camera. When the battery is low, the video door station automatically switches off video transmission. Change the batteries promptly if this message appears. 7.3.1 Playback of event recordings Event list Possible user actions... -
Page 29: Doorbell Event
English 7.3.1 Doorbell event Sequence of doorbell ringing: 1. Doorbell is pressed on the video door station. 2. The screen on the Eycasa main unit is activated. 3. RELAY2 on the door station is switched for 2 seconds to activate the door bell. 4. -
Page 30: Proximity Key Event
English 7.3.2 Proximity key event Sequence of the proximity application: 1. Hold the paired proximity key up to the video door station. 2. The door opener (RELAY 1) on the video door station is operated. 3. The screen on the Eycasa main unit is activated. 4. -
Page 31: Family Care Event
English 7.3.5 Family care event Voice activation sequence: 1. The VOX function of the Family Care camera is activated using the monitoring function on the main unit. 2. The integrated voice detection function of the Family Care camera detects a sound source. 3. -
Page 32: General System Settings
English 7.4 General system settings Pressing the button gives you access to the system settings. Note that you can block access to the settings menu by assigning a PIN. You can save settings in the submenus by pressing the button. Pressing this button also takes you to the higher-level item in the main menu. -
Page 33: Software Update Settings
English 7.4.2 Software update settings Here you can update the software of your Eycasa main unit using an SD card. On our homepage, http://www.abus.com you can check whether a new firmware file is available for the CASA31000 Eycasa main unit. The following steps must be carried out with the update: 1. -
Page 34: Screen Saver Settings
English 7.4.4 Screen saver settings Select the activation time for the screen saver. The screen saver is automatically activated after the set time if during this time there has been no user input on the touchscreen and no events on the main unit. The monitor dims in this mode, but the system functions are still active. -
Page 35: Time And Date Settings
English 7.4.6 Time and date settings Here you set the current time, date, and time zone. These settings are important for proper recording of the messages in the event log of the main unit. Activate the “Automatic” setting if your Eycasa main unit is connected to your home network (which provides access to the internet). - Page 36 English Activate network Activates/deactivates the network port of the Eycasa main unit. DHCP If this function is activated, your main unit takes its IP configuration from your router (or another network device with a DHCP server). Manual IP address If this function is activated, you can make the IP address configuration manually.
-
Page 37: Camera Settings
English 7.5 Camera settings The camera settings allow you to pair new cameras in the Eycasa main unit and change the configuration. Depending on the paired camera type, different configuration elements are available. General camera settings: ... - Page 38 English the setting is deactivated, the video image of the door station is transmitted only during the doorbell ringing process. This setting is not relevant for operation of the door station in battery mode. Setting of the loudspeaker volume on the video door station. Important: In order to ensure legal compliance, it is recommended that continuous transmission of the video image be deactivated when publicly accessible spaces can be viewed.
-
Page 39: Recording Settings
English Family Care camera settings: Setting the lullaby. This tune is played when you press the “Lullaby” button on the main unit of the Family Care camera. Voice detection sensitivity setting of the Family Care camera. The higher the set value, the more quickly the camera reacts to sounds, and triggers the VOX alarm. -
Page 40: Proximity Key Settings
English You can play the recorded video data directly via the event list if the Eycasa main unit, or play it on your PC. The video data is saved in the \eycasa\videofiles folder on the SD card. Important: The recording function operates using the integrated circular buffer of the event list. The circular buffer has a capacity of 500 entries. - Page 41 English After successful pairing, you can specify a name for the chip key and then pair further keys. If you answer the question with “No”, pairing mode is terminated on all video door stations. Managing proximity keys Press a key from the list to select it and display the chip key management options. ...
-
Page 42: Factory Settings
English 7.8 Factory settings Select “Reset” to reset your Eycasa main unit to the factory settings. The following settings are deleted: All settings for doorbell tones are set to the standard settings. All camera names are deleted. The wireless connection to all connected cameras is deleted. -
Page 43: Maintenance And Cleaning
English 8. Maintenance and cleaning 8.1 Maintenance Examine the technical safety of the product regularly, e.g. check the housing for damage. If it seems that it may no longer be possible to operate the device safely, stop using the product and protect it from unintentional use. -
Page 44: Technical Data
English 10. Technical data CASA30100 Model number Eycasa video door station Alarm Doorbell signal on main unit Connectible devices Eycasa main unit Orientation Horizontal or vertical Operating mode Permanent power supply or battery-operated Image sensor 1/4" CMOS Resolution 640 x 480 pixels (VGA) Lens 2.5 mm... - Page 45 English Audio transmission power < 20 dBm Audio sensitivity -82 dBm Audio data rate 64 Kbps Wireless range 30 m (depending on site conditions) * Event log Adjustable alarm tone 5 doorbell tones Loudspeakers 8 Ohm, 2 W x 2 Microphone Integrated Network...
- Page 46 English CASA30500 Model number Eycasa outdoor camera Frequency 2.4 GHz Modulation GFSK Transmission power 16 dBm Sensitivity -82 dBm Resolution 640 x 480 pixels (VGA) Lens 3.6 mm Horizontal angle of view 60° Number of IR LEDs 27 IR LEDs Range of night vision function Approx.
