Quick Manual
Original user manual in German. Keep for future use.
This user manual contains important information for installation and operation.
This should be also noted when this product is passed on to a third party.
Therefore look after these operating instructions for future reference!
Version 06/2019
TVHS10100
User manual
Advertisement
Table of Contents
Related Manuals for Abus TVHS10100
Summary of Contents for Abus TVHS10100
- Page 1 TVHS10100 User manual Original user manual in German. Keep for future use. This user manual contains important information for installation and operation. This should be also noted when this product is passed on to a third party. Therefore look after these operating instructions for future reference!
-
Page 2: Table Of Contents
System Configuration ....................8 Menu description ......................9 Main menu ......................9 Settings ........................11 ABUS IP Installer and integration of door station-camera into ABUS NVR....14 Integration of door station into ABUS NVR and ABUS iDVR Plus App ..... 14... -
Page 3: Declaration Of Conformity
Declaration of conformity ABUS Security Center hereby declares that the enclosed product complies with the requirements of the following directives concerning the product: EMC Directive (2014/30/EU) Low Voltage Directive (2014/35/EU) RoHS Directive (2011/65/EU) The full EU declaration of conformity can be obtained from the following address: ABUS Security Center GmbH &... -
Page 4: Features
• Integrated 2 MPx wide-angle camera with IR-LEDs (day-night function) • Robust stainless steel case with illuminated name plate and call button • Live view of compatible ABUS IP cameras • Use up to 6 interior monitors per door station •... -
Page 5: Installation (System Overview)
Installation (System overview) 2-wire cable Video / Audi Distributor Monitor Network cable 2-wire cable Door station IP Camera Wire the main monitor to channel 1 (CH1) on the Video / Audio Distributor. You can connect up to 5 more monitors to the Video / Audio Distributor. Wire each monitor to channels 2 to 6 (CH2 - CH6). -
Page 6: Monitor
Monitor Connect the 2-wire cable to the monitor as shown in the following sketch. There is no polarity to be considered. Only the 2 upper contacts of the green terminal block (6-PIN) are used on the monitor. The other contacts and connections are currently not used. Secure-Module TVHS10040 This safety module is connected via RS-485 to the door station on the contacts "RS- 485". -
Page 7: System Structure With Security Module
System structure with security module Door Main Monitor station distributor RS-485 Door opener with its TVHS10040 own power supply 12V DC The safety module uses only the connection "Power IN" (12VDC) / "RS485" (connection to door station "RS485" and "lock out"), the other connections are currently not used. -
Page 8: System Configuration
• Make sure all devices are turned on during activation. Note: The video / audio distributor TVHS10100 does not necessarily has to be connected to the LAN. Without the Internet, the time must be set manually because no connection to the NTP server can be established. If no external cameras are integrated or accessed via app, you can omit the connection to the home network. -
Page 9: Menu Description
Menu description Main menu The main menu shows the current time and date, as well as the connection status of the door station (top right in the screen). Touch the time or date for 2 seconds to adjust it. Furthermore, the following functions are available: Note: Some configuration options are only available on the main monitor. - Page 10 Live view Switches to the live view of the door station. From here you can also open the live view of installed network cameras. Draw area Here you can define an area to be digitally zoomed. Note: The system must be restarted to successfully apply the zoom setting. Clear area Here you can delete the previously defined area again.
-
Page 11: Settings
Settings The Settings menu allows you to make all the essential settings for the monitor or your system. Password Here you can change the password assigned during the initial setup. This password is needed when accessing the system via network. Sound Ringtone Here you can choose between three different ringtones. - Page 12 Clean screen Here you can lock the screen so that no function is accidentally triggered when the screen is cleaned. General information Modell: Displays the item number of the monitor Version: Displays the installed firmware version Displays the serial number of the monitor Code: This function is currently not used System language...
- Page 13 Resets all settings except password and network settings. Default Resets all settings, including password and network settings. * Compatible ABUS IP cameras IPCA33500, IPCA53000, IPCA62520, IPCA63500, IPCA66500, IPCA72520, IPCA73500, IPCA76500, IPCB42500, IPCB42501, IPCB42510A, IPCB42510B, IPCB42510C, IPCB42515A, IPCB42550, IPCB42551, IPCB44510A, IPCB44510B,...
-
Page 14: Abus Ip Installer And Integration Of Door Station-Camera Into Abus Nvr
ABUS IP Installer and integration of door station-camera into ABUS NVR With the ABUS IP Installer you can set the network settings of the door station and monitors via network. Please enter the user name (admin) and your password for the advanced functions of the IP installer. - Page 15 Imprint These operating instructions are published by ABUS Security Center GmbH & Co.KG, Linker Kreuthweg 5, 86444 Affing, Germany. No reproduction (including translation) is permitted in whole or part e.g. photocopy, microfilming or storage in electronic data processing equipment, without the express written consent of the publisher.
