970 User Guide and Technical Information
MADI I/O (BNC)
4)
Input (top) accepts MADI (AES10) digital
audio. Output (bottom) provides MADI
(AES10) digital audio. 64 channels.
Timecode I/O (BNC)
5)
Input (top) accepts SMPTE timecode.
Output (top) provides SMPTE timecode.
SYNC I/O (BNC)
6)
Wordclock input (top) and output (bot-
tom).
AES3 I/O (DB-25)
7)
8 channels of AES digital audio input
and 8 channels of AES digital output.
"Connector Pin Assignments", page
Analog Audio Output (DB-25)
8)
8 channels of balanced, line-level analog
audio output.
ments", page
Analog Audio Input (DB-25)
9)
8 channels of balanced, line-level analog
audio input.
ments", page
Analog Audio Input (XLR)
10)
2 channels of balanced, line-level analog
audio inputs.
4
v. 2.00 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
(See
54)
(See "Connector Pin Assign-
54)
(See "Connector Pin Assign-
54)
Analog Audio Output (XLR)
11)
2 channels of balanced, line-level analog
audio outputs.
Ethernet (RJ-45)
12)
Attaches to 1G or 100M Ethernet net-
works. Provides Dante connectivity
"Dante Audio Inputs", page
Grouping (See "Network Grouping", page
27), web access for remote control
"Web Interface - PIXNET", page
network file service. (See "Storage and File
Management", page 37)
RS-422 Control (DB-9)
13)
Connects to RS-422 Controllers for exter-
nal control of the 970.
29)
External Drive Connections (eSATAp)
14)
Connector for approved external drives.
Sound Devices maintains a list of tested
and approved media. Visit
vices.com/approved for an up-to-date list of
tested and approved drives.
GPIO Remote (Phoenix 10-pin)
15)
Logic contact points for remote control.
(See "GPIO (General Purpose Input / Out-
put)", page 35)
USB Connection
16)
Factory use only.
(See
12), Network
(See
29), and
(See "RS422", page
www.soundde-
