2.1 U
NPACKING AND
Inspect shipping container for damage. If shipping containers are damaged, keep them
until contents of shipment have been carefully inspected and checked for normal
operation.
Remove the packing list from the outside of the shipping carton. Open the carton and
remove the contents, checking the contents against the packing list. Verify completeness
of the shipment and that the unit functions correctly. If damage is evident, contact the
carrier and Comtech EF Data immediately and submit a damage report. If the unit needs
to be returned to Comtech EF Data, use the original shipping container.
2.2 I
NSTALLATION AND
The Common Module of the MBT-4000 may be located near or on the antenna. The
band-specific BUC and BDC is latched into place on top of the Common Module (M&C,
Power Supply, Reference). Cables to the antenna and IDU complete the installation. To
change the band of operation, cables to the BUC and BDC are removed and clips
released, allowing removal and replacement of the BUC/BDC with appropriate band-
specific modules.
2.2.1 PWR IN (J1) P
Chapter 2. Installation
I
NSPECTION
O
PERATION
C
IN
ONNECTIONS
Table 2-1. PWR IN (J1) Pin Connections
Pin
A
LINE
B
NEUTRAL
C
GND
Mating Connectors:
ITT Cannon KPT06B-12-35
CEFD PN CN/MS-STPG03F02
2- 1
PWR IN (J1)
