Comtech EF Data MBT-4000 Installation And Operation Manual page 69

Multi-Band Transceiver System
Remote Command
Command
Valid on
Parameter (Instruction
MBT,
Type Code and
BDC, or
qualifier)
BUC
Serial Number N/A
Retrieve N/A MBT
Utility Status
Remote Baud SBR=xxxx MBT
Rate
Summary Fault N/A
Status
Remote Address SPA=xxxx MBT
Arguments for
Command or (Note that all arguments are ASCII numeric codes, that
Response to
Query
All 9 bytes, numeric Query only.
000000000 to Used to Query the units 9 digit serial number.
999999999 Slave returns its S/N, in the form xxxxxxxxx.
Example: RSN=000000165
24 bytes Query only.
alphanumeric Used to Query the utility status of the MBT-4000 base unit..
Example:
<0001/RUS={cr}
>0001/RUS={cr}{lf}
ADR=0001{cr}
BDR=9600{cr}{lf}
4 bytes, Command or Query.
Set remote baud rate as follows:
9600 = 9600 baud
19K2 = 19200 baud
All N/A Query only.
Used to Query the status of the Summary Fault Relay.
Where:
0=OK
1=FT
Example: SFS?
4 byte, Command or Query.
numeric Set Physical Address-between 0001 to 9999.
Resolution 0001
Example: SPA=0412
MN/MBT4000.IOM
Description of arguments
is, ASCII codes
between 48 and 57)
A-25
Revision 3
Query
Response to
(Instruction
Command
Code and
(target to controller)
qualifier)
N/A RSN?
N/A RUS?
SBR= (message ok) SBR?
SBR? (received ok, but
invalid arguments
found)
SBR! (Command not
accepted by BUC and
BDC sub-units.)
N/A SFS?
SPA= (message ok) SPA?
SPA? (received ok, but
invalid arguments
found)
SPA! (Command not
accepted by BUC and
BDC sub-units.)
Response to
query
(target to
controller)
RSN=xxxxxxxx
x
(see
description for
details of
arguments)
RUS=x....x
(see
description for
details of
arguments)
SBR=xxxx
(same format
as command
arguments)
SFS=x
(see
description for
details of
arguments)
SPA=xxxx
(same format
as command
arguments)
