3.1 O
PERATION
This chapter contains instructions for operating the MBT-4000.
3.1.1 B D
LOCK OWN
The BDC-4000 translates a band-specific input frequency block (C-, X-, or Ku- or Ka-),
from the LNA, down to L-Band (950 to 2000 MHz).
BDC-4000 C, X, Ku, Ka
Band
C-Band
X-Band
Ku-Band-W
Ka-Band
Notes: 1. No spectral inversion, selectable inversion for inverted Block Down Converter
2. 10 dB gain adjustment.

Chapter 3. System Operation

C (BDC-4000)
ONVERTER
Frequency
3400 – 4200 MHz
7250 – 7750 MHz
10.95 – 12.75 GHz
11.7 – 12.20 GHz
12.250 – 12.275 GHz
20.20 – 21.20 GHz
LO Frequency
5150 MHz
6300 MHz
10.00 GHz
10.75 GHz
11.30 GHz
3-1
Inverting
Yes
No
No
