2.2.5 A C
UX OMM
2.2.6 A C
UX OMM
1 (J9) P C
IN ONNECTIONS

Table 2-5. Aux Comm 1 (J9) Pin Connections

Pin
A AUX Rx + A
B AUX Rx – A
C AUX Tx + A
D AUX Tx – A
E +12.6V LNA A
F IO1 A/Fault
G IO1 B
H GND
Mating Connectors:
Cannon MS3116J12-8P
CN/MS3116J12-8P
2 (J8) P C
IN ONNECTIONS

Table 2-6. Aux Comm 2 (J8) Pin Connections

Pin
A AUX Rx + B
B AUX Rx – B
C AUX Tx + B
D AUX Tx – B
E +12.6V LNA B
F I02 A/Fault
G I02 B
H GND
Mating Connectors:
Cannon MS3116J12-8P
CN/MS3116J12-8P
AUX COMM1 (J9)
AUX COMM 2 (J8)
