S A M L E X
20 Years focused on power inverters
POWER INVERTER
With Advanced Technology!!!
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING
SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS
PRODUCT. BEFORE USE, READ AND UNDERSTAND ALL CAUTIONS,
WARNINGS, INSTRUCTIONS AND PRODUCT LABELS, PLUS YOUR
VEHICLE'S BATTERY MANUFACTURER GUIDELINES. FAILURE TO DO
SO COULD RESULT IN INJURY AND/OR PROPERTY DAMAGE.
VR Series
OWNER'S MANUAL
For models (115V):
SI-A1-VR1500
SI-A1-VR2000
SI-A1-VR3000
Advertisement
Table of Contents
Related Manuals for Samlexpower SI-A1-VR1500
Summary of Contents for Samlexpower SI-A1-VR1500
- Page 1 S A M L E X 20 Years focused on power inverters VR Series POWER INVERTER OWNER’S MANUAL For models (115V): SI-A1-VR1500 SI-A1-VR2000 SI-A1-VR3000 With Advanced Technology!!! THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To ensure reliable service, your power inverter must be installed and used properly. Please read the installation and operating instructions thoroughly prior to installation and use. Pay particular attention to the WARNING and CAUTION statements in this manual. The CAUTION statements advise against certain conditions and practices that may result in damage to your inverter. - Page 3 1． INTRODUCTION Your new SAMLEX VR-Series power inverter is one in a series of the most advanced DC to AC inverters available today. With proper care and appropriate usage, it will give you years of dependable service in your car, truck, RV or boat.
-
Page 4: How Your Inverter Works
2． HOW YOUR INVERTER WORKS The inverter converts low voltage DC (Direct Current) from a battery or other power source to 115 volt AC (Alternating Current) household power. PRINCIPLE OF OPERATION The inverter converts power in two stages. The first stage is a DC to DC conversion process that raises the low voltage DC at the inverter input to higher volts DC. -
Page 5: Installation / Environments
3． INSTALLATION / ENVIRONMENTS POWER SOURCE REQUIREMENTS The power source must provide between 10.5 and 14.5 volts DC and must be able to supply the necessary current to operate the load. The power source may be a battery or a well-regulated DC power supply. To obtain a rough estimate of the current (in amperes) the power source must deliver, simply divide the power consumption of the load (in watts AC) by 10. -
Page 6: Installation Notes
INSTALLATION NOTES: WARNING: Keeping ventilation when using batteries. Batteries may generate flammable gas during charging or discharging. The inverter has four slots in its mounting bracket that allow the unit to be fastened against a bulkhead, floor, wall or other flat surface. Ideally, the mounting surface should be cool to the touch. -
Page 7: Connection To Load
Connect a length of wire between the inverter’s negative (-) terminal and the DC power source negative (-) terminal. Connect a short length of wire to the other terminal of the fuse holder or circuit breaker. Mark it “POSITIVE” or “+”. Connect the free end of the fuse or breaker wire to the positive terminal of the DC power source (battery). -
Page 8: Operating Environment
OPERATING ENVIRONMENT For best operating results, the inverter should be placed on flat surface, such as the ground, car floor, or other solid surface. The power cord allows easy positioning of the inverter. The inverter should only be used in locations that meet the following criteria: DRY- Do not allow water and/or other liquids to come into contact with the power inverter. -
Page 9: Operating Tips
OPERATING TIPS RATED VERSUS ACTUAL CURRENT DRAW OF EQUIPMENT Most electrical tools, appliances and audio/video equipment have labels that indicate the power consumption in amps or watts. Be sure that the power consumption of the item you wish to operate is rated at 1500/2000/3000 watts or less. -
Page 10: Protective Features Of The Inverter
5. PROTECTIVE FEATURES OF THE INVERTER Your inverter monitors the following potentially hazardous conditions: OVER TEMPERATURE PROTECTION – If the temperature inside the inverter is too high, the unit will automatically shut down. Allow the unit to cool for at least 15 minutes before restarting after a heat-related shutdown. -
Page 11: Common Problems
(“snow free”) signal and that high quality, shielded antenna cable is used. Do not operate high-power appliances or tools when you are watching TV. By the advanced technology of SAMLEX, L.I.T greatly reduces the possibility of interference with TV signals and audios. -
Page 12: Troubleshooting Guide
TROUBLESHOOTING GUIDE - TABLE 1 TROUBLE/ INDICATION POSSIBLE CAUSE SUGGESTED REMEDY No AC output; DC input below 10.5 volts Recharge or replace battery Yellow LED lit Green LED not lit Inverter overheat Remove or reduce load, wait for inverter to cool. No AC output;... -
Page 13: Fuse Replacement
Low Voltage Alarm……………………………….……………….……..10.8 volt DC Low Voltage Shutdown …………………….………………..…10.2 volt DC Low Voltage auto-restart…………………………………………….12.2 volt DC Fan…………………………………………………………Electronic controlled fan Input Fuse……………………………………………………………………..Internal ** Specifications are subject to change without notice. ** Thank you for using SAMLEX power inverter! © 2009 SAMLEX ELECTRIC COMPANY LIMITED...
