Anchor minivox pa Owner's Manual

HAVING TROUBLE W/ YOUR SOUND SYSTEM?
CONDITION POSSIBLE CAUSE
No Sound (LED off) • turn POWER switch ON
• charge batteries
No Sound (LED on) • turn microphone switch ON
• make sure all cables are completely plugged in
No Sound When Using CD Input • check for output from source
• make sure all cables are completely plugged in
Distorted Sound • lower system volume control
• replace or recharge batteries
Shortened Battery Life • replace worn NiCad batteries
• 'Cycle' NiCad batteries (see page 3)
• reduce volume to eliminate distortion
Unit Turns Off & Back On During Use • batteries are low and need to be replaced
HAVING TROUBLE W/ YOUR WIRELESS SYSTEM? (Wireless Model Only)
No Sound (RX Indicator: ON) • microphone volume control is to low or off
• no mic plugged into belt-pack transmitter
No Sound (RX Indicator: OFF) • sound system not turned on
• transmitter power switch turned off
• low battery or no battery in transmitter
• transmitter and receiver are not on the same channel
ANCHOR AUDIO CUSTOMER SERVICE
888-444-6077
MINIVOX TECHNICAL SPECIFICATIONS
MiniVox
Rated Power Output 18 watts
Max SPL @ Rated Power 108 dB @ 1 meter
Frequency Response 100 Hz – 12 kHz
Speaker Type 4 inch neodymium woofer
CD / TAPE Input line level, 3.5mm
Mic Input Lo-Z, phantom powered, 3.5mm jack
Mic Input Lo-Z, 1/4"-phone
Battery Type nine C-size, alkaline
Dimensions (HWD) 8 x 6.5 x 9.5" / 20 x 17.5 x 24 cm
Weight 3.75 lbs / 1.7 Kg
Anchor Audio, Inc.
Portable Sound Systems • Torrance, California
RC-25 Recharge Kit (optional)
Battery Type 9 'C' size, 1.5AH rechargeable NiCad
Charger AC-25
AC-25 Input 120 VAC, 60Hz, 10 watts max
AC-25/220 Input 220 VAC, 50Hz, 10 watts max export
AC-25 Output DC taper charge
Shipping Weight 2.1 lbs / 1.0 Kg
(Specifications subject to change without notice)
MiniVox PA System
PORTABLE PUBLIC ADDRESS SOUND SYSTEM
OWNER'S MANUAL
GETTING STARTED / SYSTEM INVENTORY .......................................................................................................... 2
USING AN OUTBOARD CD/TAPE PLAYER ........................................................................................................... 3
RECHARGEABLE BATTERY KIT ............................................................................................................................. 3
BASIC SYSTEM OPERATION ................................................................................................................................. 4
MINIVOX ACCESSORIES ....................................................................................................................................... 4
BATTERY INSTALLATION ..................................................................................................................................... 5
BUILT-IN UHF WIRELESS RECEIVER .................................................................................................................... 6
OPERATING THE WIRELESS MICROPHONE / TRANSMITTER .............................................................................. 7
HAVING TROUBLE W/ YOUR SOUND SYSTEM? ................................................................................................... 8
MINIVOX TECHNICAL SPECIFICATIONS ............................................................................................................... 8
100-0156-000/A - 11/06
CONTENTS
