10. Mounting the Module / Finishing the Installation
1. Mount the module to a brace or wire harness under the dash. The module and harnesses must be clear of
moving parts.
2. Completely uncoil the antenna and route up the nearest front window pillar to the headliner. Be careful not
to pinch the antenna under vehicle panels, or route near moving parts.
3. Route the antenna across the headliner to a position behind the rearview mirror.
4. Attach the antenna to the inside of the windshield behind the rearview mirror:
• The glass surface must be clean before mounting antenna. Use rubbing alcohol to thoroughly clean the
mounting location.
• Remove protective backing and press firmly against windshield.
5. Plug antenna into the Reciever Plug located in the back of module. (Black Connector)
Installation Complete
