- Page 1 12.1 -Inch LED Backlit LCD Roof-Mount DVD Player With DVD/CD/MP SYSTEM aVxMTG InSTaLLaTIon GUIDE...
-
Page 3: Table Of Contents
TaBLE oF ConTEnTS Important Notices ����������������������������������������������������������������������������������������������������������������������������������������� 2 IR Transmit and Receive Modes M1 or M2) ����������������������������������������������������������������������������������� 3 Materials Included in this Package ����������������������������������������������������������������������������������������������������� 4 Removing and Installing Snap On Covers ������������������������������������������������������������������������������������� 5 General Vehicle Installation Approach ��������������������������������������������������������������������������������������������� 8 Connecting the Dome Lights ��������������������������������������������������������������������������������������������������������������11... -
Page 4: Important Notices
System adjustments can be accomplished using the remote control, while seat-belts remain fastened� Enjoy your AUDIOVOX entertainment system but An LCD panel and/or video monitor used for television reception, video or remember that the safety of all passengers remains the number one priority�... -
Page 5: Ir Transmit And Receive Modes M1 Or M2)
M1 mode� Conversely a unit set to M1 mode will not work with a remote control programmed to the M2 mode� To change from M1 to M2 mode, point the remote control towards the IR receiver on the AVXMTG12U� Press and hold the M2 button for 5 to 7 seconds� The following screen will be displayed: Note: The OSD will appear on the screen for 4 –... -
Page 6: Materials Included In This Package
(3 pcs) *Note: The AVXMTG12U is supplied with a black snap-on shroud and screen cover� To install the pewter or shale snap-on shroud or screen cover, the black snap- on shroud and screen cover must be removed first� See the following page for the removal process�... -
Page 7: Removing And Installing Snap On Covers
REMoVInG anD InSTaLLInG SnaP-on CoVERS Preparation Place the unit on a soft surface to avoid damaging the plastic� Materials Required Shroud Screen Back Cab Pry Tool 10” Overhead LCD Monitor 12�1” with DVD Player Disconnecting the Screen Cover “C” “B” “A”... - Page 8 Installing the Screen Cover “D” “D” “D” “D” 1� Open the LCD screen� 2� Hook the two tabs “D” at the bottom edge of the screen cover into the notches on the bottom edge of the LCD screen� 3� Snap the opposite side of the screen cover over the hinges�� Disconnecting the Shroud “E”...
- Page 9 Installing the Shroud “F” 1� Open the LCD screen� 2� Slide the shroud over the unit� The shroud will snap into place at locations “F”�...
-
Page 10: General Vehicle Installation Approach
2� If it is not certain how the dome lamps tie into the vehicle electrical system, wire the dome lamp circuit (of the DVD overhead) to the driver’s door pin switch� 3� Follow the instructions on pages 11-13� 4� Contact the Audiovox tech support line if you have any questions regarding dome lamp wiring�... - Page 11 GEnERaL VEhICLE InSTaLLaTIon aPPRoaCh Installing Unit to Roof Roof Roof Support Headliner Mounting Bracket Self-drilling Screws Video Unit M5 Screw CaUTIon: The 20mm and 40mm screws in the hardware kit are provided to facilitate installation� Use extreme caution when using these screws to avoid damage to vehicle roof or other components, wiring, etc�...
- Page 12 GEnERaL VEhICLE InSTaLLaTIon aPPRoaCh...
-
Page 13: Connecting The Dome Lights
ConnECTInG ThE DoME LIGhTS The dome lights in the video monitor require three connections to the vehicle’s wiring� There are two common types of dome light circuits used, positive or negative switched� Positive systems supply voltage to the interior lights to turn them on� Negative switched systems apply ground to illuminate the bulbs� To determine which system you have, you must locate the wires at the vehicle dome light�... - Page 14 Positive Switched Dome Lighting To 6 pin Red/black-Lamp on To 12 pin constant connector Black/red-Lamp common +12 VDC on Monitor Purple/brown-Lamp Auto * Connect to a vehicle ground constant +12 VDC Factory Door Ajar Switch or Body Control Computer...
- Page 15 Negative Switched Dome Lighting Red/black-Lamp on To 12 pin To 6 pin Black/red-Lamp common connector Purple/brown-Lamp Auto * Connect to a vehicle ground constant +12 VDC constant +12 VDC Factory Door Ajar Switch or Body Control Computer...
- Page 16 © 2010 aUDIoVox,150 Marcus Blvd. hauppauge, nY 11788 2012 AUDIOVOX,150 Marcus Blvd. Hauppauge, NY 11788 128-8991...
