- Page 1 OWNER'S MANUAL LAMINATOR MODEL NO.HSH-1201 Read all instructions carefully before use. Royal Sovereign International Inc.
-
Page 2: Table Of Contents
HSH-1201 TABLE OF CONTENTS TOPIC PAGE INTRODUCTION MAJOR PARTS SAFETY PRECAUTIONS CONTROL PANEL INSTRUCTIONS HOT LAMINATING PROCEDURE COLD LAMINATING PROCEDURE COLOR FOIL LAMINATING PROCEDURE MAINTENANCE TROUBLESHOOTING SPECIFICATIONS WARRANTY... -
Page 3: Introduction
HSH-1201 INTRODUCTION Thank you for purchasing a Royal Sovereign HSH-1201 Laminating Machine. It has been designed and manufactured to provide years of continuous service. To insure high quality lamination, please read this instruction manual thoroughly. This manual will provide you with complete operating and maintenance information. -
Page 4: Safety Precautions
HSH-1201 SAFETY PRECAUTIONS The safety recommendations outlined in this section are to be read, understood and followed before operating the machine. Failure to comply with any of the following safety procedures could result in serious injury. Keep this information for future reference. -
Page 5: Control Panel Instructions
HSH-1201 CONTROL PANEL INSTRUCTIONS Appropriate speed and temperature may be set, using the LCD controller. CONTROL PANEL SETTINGS LCD DISPLAY BUTTONS... -
Page 6: Lcd Display
HSH-1201 LCD DISPLAY CONTROL PANEL FUNCTIONS FILM This displays the current film thickness. 10 film settings 3 mil=75 mic, 4 mil=100 mic, 5 mil=125 mic 6mil=150mic,7 mil=175 mic, 8mil=200mic, T-Check 10mil=250mic, Press this to check the current temperature SPEED Hot / Cold... -
Page 7: Hot Laminating Procedure
HSH-1201 HOT LAMINATING PROCEDURE 1. Place and use the laminator on a sturdy, flat work surface. 2. Plug in the laminator after verifying the correct outlet voltage. 3. Press the power button. 4. Make sure the machine is in the HOT lamination mode by pressing the HOT/COLD button. -
Page 8: Cold Laminating Procedure
HSH-1201 COLD LAMINATING PROCEDURE 1. Set the laminator in the COLD lamination mode by pressing the HOT/COLD button. 2. The symbol will appear and you will hear 3 beeps when the machine is in the cold temperature mode. The machine is now ready for lamination. -
Page 9: Maintenance
HSH-1201 MAINTENANCE When adhesives from film build up on the rollers, the quality of lamination will decrease and jamming may occur. Please clean the rollers regularly. 1. Turn on the laminator and set the temperature to 212°F(100°C) and set the mil thickness to 4mil(100mic). -
Page 10: Troubleshooting
HSH-1201 TROUBLESHOOTING Problem Possible Cause Possible Solution - Check and plug in the - Power cord may not be power cord. plugged in. Motor doesn’t work - Check and turn on the - Power switch is off power. - If laminating heat sealed... -
Page 11: Pouch Film Settings
HSH-1201 POUCH FILM SETTINGS Please refer to the settings below if you are laminating a few items. Please refer to the settings below if you are laminating a few items. - Page 12 Royal Sovereign International will repair or replace this product if it is found to be defective in material or workmanship. Defective product must be returned to Royal Sovereign International, freight prepaid, with proof of purchase and Return Shipping &...
