NetComm N3G002W Quick Start Manual

NetComm N3G002W Quick Start Manual

3g wireless router
Hide thumbs Also See for N3G002W:

Advertisement

Quick Links

Download this manual See also: User Manual
3G Wireless Router
3G Wireless Router
Mac Quick Start Guide
Mac Quick Start Guide
Start Here
This Quick Start guide provides basic instructions for connecting your N3G002W to an
Apple Macintosh computer and to a 3G Internet Server Provider .
Ethernet Installation
1.
2.
Airport Installation
Before you can use this Quick Start Guide, you must already have a 3G PC Card or 3G USB
Modem and an active data enabled SIM card with a 3G Internet Service Provider (ISP).
These instructions provide a basic set-up configuration that should get home or small office
Macs up and running. This will be sufficient for most users.
If you need to perform more advanced configurations, please see the comprehensive User
Guide on the supplied CD-ROM for additional instructions.
Connecting your N3G002W
The NetComm N3G002W can be connected directly to your Mac via an Ethernet interface.
In addition, you can use your Mac's Airport to connect to the N3G002W wirelessly.
Warning:
Before you begin, turn the power off for all devices. These include your Mac and your N3G002W Modem.

Advertisement

loading
Need help?

Need help?

Do you have a question about the N3G002W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NetComm N3G002W

Summary of Contents for NetComm N3G002W

  • Page 1 The NetComm N3G002W can be connected directly to your Mac via an Ethernet interface. In addition, you can use your Mac’s Airport to connect to the N3G002W wirelessly. Warning: Before you begin, turn the power off for all devices. These include your Mac and your N3G002W Modem.

  • Page 2: Ethernet Installation

    Carefully insert the 3G card into the N3G002W slot until it is firmly fitted. > Attach the power connector. Connect the AC power adapter to the Power connector on the back of the N3G002W and plug in the adapter into a wall outlet or power strip. Switch on the power.
  • Page 3 3G Wireless Router Mac Quick Start Guide Ethernet The Systems Preferences window opens. Installation (cont) Double click on “Network” and the below window opens. Your Ethernet status should be “connected”. If the status is not connected, please consult the detailed user guide.
  • Page 4 3G Wireless Router Mac Quick Start Guide Ethernet 3. Open Safari and type in 192.168.123.254 in the address bar. Installation (cont) 4. This will open the modem configuration screen as below. 5. Select “Wizard” and click enter.
  • Page 5 The setup wizard will now guide you though the step by step configuration. Installation Click on “Next” to proceed. (cont) 7. Select your WAN connection and then click next. Note: NetComm used a 3G card from 3 mobile broadband for the purpose of this quick start guide.
  • Page 6 (cont) Note: NetComm used a 3G card from 3 mobile broadband for the purpose of this quick start guide and the APN of 3 mobile is “3netaccess”. Please ask your 3G broadband service provider for the APN 9.
  • Page 7 3G Wireless Router Mac Quick Start Guide Ethernet 10. Click “finish” to return to the status page. Installation (cont) 11. You are now connected via Ethernet to the N3G002W router.
  • Page 8 3G Wireless Router Mac Quick Start Guide Airport Turn Airport on Installation Click on “Join Other Network” This will take you to the screen below. Do not type in any name, but click on “Show Networks” at the bottom left of the screen. Make sure “Remember this network”...
  • Page 9 3G Wireless Router Mac Quick Start Guide Airport Airport will now scan all the available networks as shown below Installation (cont)
  • Page 10 The default password is a1b2c3d4e5 – please type this in and ensure that “Show password” and “Remember this network” are ticked. (cont) Now, when you click on the Airport icon, you will see a number of wireless networks. Select “netcomm n3g series” You are now connected wirelessly to the N3G002W router.
