Master Keypad Definitions

21
20
19
18
17
16
15
When you use the keypad to enter codes and commands, press the keys within 2 seconds of one another. If 2
seconds elapse without a key depression, the entry is aborted and must be repeated from its beginning.
NOTE: Different timeouts may occur when defining auxiliary functions and setting the real-time clock.
Note: The system functions described below are for reference only and require additional key entries to activate.
1. DISPLAY WINDOW: Liquid Crystal Display
(LCD). Displays protection point identification
and system status,
instructions.
2. ARMED INDICATOR:
system has been armed
DELAY). Blinks when armed and fault exists, or
once per second when AVM (VOX or Talk) or
speaker phone mode is active.
1 2
1
OFF
ESCAPE RECORD
4
AWAY
ADD LIGHTS ON
7
LIGHTS OFF
STATUS
12
11
14 14 13
IMPORTANT!
messages, and user
(RED) Lit when the
(STAY, AWAY, NO
3
ARMED READY
2 3
STAY
VOLUME PLAY DELETE
5 6
AUX
TEST BYPASS SELECT
8 9
CODE CHIME
0
NO DELAY FUNCTION
R
10
3. READY INDICATOR: When lit, indicates
system is ready to be armed; blinking indicates
system is not ready (a zone is open). Blinks once
per second when AVM (VOX or Talk) or speaker
phone mode is active.
PLAY
4. KEY: Announces a user's message if
one was previously recorded. See RECORD
function. Used to adjust volume of voice
messages.
– 12 –
4
5
6
7
8
9
