Icom IC-M32 Instruction Manual page 27

D Self check function "SC"
The self check function checks transceiver conditions by it-
self, and informs you in case a problem is found. The follow-
ing items are checked after the power is turned ON, then it
switches to operation mode.
• Temperature : Outside of –25°C to +65°C; –13°F to +149°F
(approx.)
• Connected battery voltage
• Water intrusion
Push
Self check OFF (default)
When error messages as shown below are displayed, see
troubleshooting for advice. (p. 29)
Temperature error Battery voltage error
D Battery voltage indicator "bt"
The voltage of the connected battery pack can be turned ON
(displayed for 2 sec.) or OFF (non-displayed) after power is
turned ON.
Battery voltage
indication OFF
Self check ON
Water intrusion error
Push
(default)
7
SET MODE
Battery voltage
7
indication ON
21
