HD1400
LEG EXTENSION/CURL
Note: Both Serial Number and Model Number are Required when Ordering Parts
Customer Service
RECORD SERIAL NUMBER HERE
(800) 548-5438
(858) 578-7676
Fax
CATALOG NUMBER
(858) 578-9558
0302-001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD1400 and is the answer not in the manual?

Questions and answers

Related Manuals for Hoist Fitness HD1400

Summary of Contents for Hoist Fitness HD1400

  • Page 1 HD1400 LEG EXTENSION/CURL Note: Both Serial Number and Model Number are Required when Ordering Parts Customer Service RECORD SERIAL NUMBER HERE (800) 548-5438 (858) 578-7676 CATALOG NUMBER (858) 578-9558 0302-001...

  • Page 2: Table Of Contents

    PARTS LISTING ................HARDWARE LISTING ..............BOLT SIZING CHART ..............WASHER SIZING CHART ............WEIGHT RATIOS................WEIGHT TRAINING TIPS............. WEIGHT TRAINING EXERCISE LOG ........DECAL PLACEMENT ..............GENERAL MAINTENANCE INFORMATION ......MAINTENANCE SCHEDULE............LIMITED WARRANTY ..............Page - 1 HD1400 Assembly...

  • Page 3: Instructions (Step 1)

    TOOLS REQUIRED Socket Wrench (9/16”, 1/2”) 3/4" Open End Wrench Standard Allen Wrench set (5/64” thru 1/4”) External snap ring pliers with a tip size between .035" ~ .043". Crescent Wrench Rubber Mallet Tape Measure HD1400 Assembly Page - 2...

  • Page 5: Frame Assembly (Step 2)

    O W N E R S Step 2 F R A M E A S S E M B L Y HD1400 Assembly Page - 4...
  • Page 6 4 - Main Support Frame AA - 1/2” Flat Washer 5 - Rear Upright BA - 1/2” Nylok Nut 6 - Main Frame Support CA - Rubber Foot Pad 7 - Right Side Handle 8 - Left Side Handle Page - 5 HD1400 Assembly...
  • Page 7 O W N E R S HD1400 Assembly Page - 6...
  • Page 8 BA - 1/2” Nylok Nut 10 - 12 ½ LB Intermediate Plate CB - Weight Stack Bumper 11 - 8 ¼ LB Intermediate Plate CG - Guide Rod Top Mount 12 - 8 ¼ LB Top Plate Page - 7 HD1400 Assembly...
  • Page 9 O W N E R S HD1400 Assembly Page - 8...
  • Page 10 14 - Right Side Support Mount AA - 1/2” Flat Washer 15 - Left Side Elbow Pad Mount BA - 1/2” Nylok Nut 16 - Right Side Elbow Pad Mount 17 - Leg Extension Mount Page - 9 HD1400 Assembly...
  • Page 11 O W N E R S HD1400 Assembly Page - 10...
  • Page 12 E - 1/2”-13UNC x 3 1/4” Hex Bolt 18 - Leg Extension AA - 1/2” Flat Washer 19 - Lower Swivel Bracket BA - 1/2” Nylok Nut 20 - Dia. .75 x 2.25 LG CRS Page - 11 HD1400 Assembly...

  • Page 13: Hd1400 Assembly

    O W N E R S HD1400 Assembly Page - 12...
  • Page 14 19 - Lower Swivel Bracket CH - 3/8” Flat Head Cap 21 - Roller Pad Bar CN - Upholstery Pad CP - Upholstery Pad CQ - Pad Assembly DC - Roller Pad DE - Plastic Washer Page - 13 HD1400 Assembly...
  • Page 15 Repeat assembly for (CP). Repeat assembly for (CP). (Shown assembled or clarity.) (Shown assembled or clarity.)

  • Page 16: Cable Assembly (Step 3)

    NOTE: NOTE: Hardware Descriptions BE SURE CABLE RUNS BE SURE CABLE RUNS BETWEEN THE PULLEY AND BETWEEN THE PULLEY AND J - 3/8”-16 UNC x 3” Hex Bolt THE GUARD SHAFT. THE GUARD SHAFT. K - 3/8”-16 UNC x 2 1/2” Hex Bolt AB - 3/8”...
  • Page 17 Warning - Cable Bolt must be threaded a minimum of 1/2” into the Weight Plate Stem with Jam Nut tightened securely to ensure proper connection. See Quick Release Cable Anchor Detail For Assembly. Quick Release Cable Anchor Detail With Retaining Ring Assembly.

  • Page 18: Shield Assembly (Step 4)

    Wrench Tighten *IMPORTANT* Now that the Hd1400 machine is completely assembled take time to assure that your unit is assembled square and perpendicular. To check this use a Level to check that the Guide Rods are perpendicular in both directions. If they are not perpendicular in both directions. It will be necessary to loosen some Frame hardware to re-align the Frame and re-tighten bolts.
  • Page 19 O W N E R S HD1400 Assembly Page - 18...

  • Page 20: Pre-Assembled Parts (Step 5)

    CW - 3/4” Flanged Ball Bearing 23 - 16 Plate Selector Stem CX - End Cap 50mm x 75mm CY - Bumper CZ - Closed End Black Foam Grip DA - Closed End Black Foam Grip Page - 19 HD1400 Assembly...
  • Page 21 O W N E R S Shown assembled Shown assembled for clarity. for clarity. Repeat assembly Repeat assembly for other handle. for other handle. HD1400 Assembly Page - 20...

  • Page 22: Parts Listing

    Right Side Elbow Pad Mount 26-STD-04-1248 Leg Extention Mount 26-STD-04-1249 Leg Extension 26-STD-04-1250 Lower Swivel Bracket 26-STD-05-0290 Dia. .75 x 2.25 LG C.R.S 26-STD-04-1251 Roller Pad Bar 26-STD-10-0187 Frame Shield 26-STD-SW111 16 Plate Selector Stem Page - 21 HD1400 Assembly...

  • Page 23: Hardware Listing

    O W N E R S H A R D W A R E L I S T I N G HD1400 Assembly Page - 22...

  • Page 24: Bolt Sizing Chart

    O W N E R S B O L T S I Z I N G C H A R T Page - 23 HD1400 Assembly...

  • Page 26: Washer Sizing Chart

    O W N E R S W A S H E R S I Z I N G C H A R T 1” LONG HEAVY 11/16” LONG HEAVY FLANGED SPACER FLANGED SPACER Page - 25 HD1400 Assembly...
  • Page 27 O W N E R S W A S H E R S I Z I N G C H A R T SMALL, SAE, 26mm LARGE, USS, 34mm LARGE, USS, 25mm HD1400 Assembly Page - 26...

  • Page 28: Weight Ratios

    80% Curl weight plate you have pinned. Hoist reserves the right to modify the weight stack from the one shown without prior notice. 80% Extension Page - 27 HD1400 Assembly...

  • Page 30: Weight Training Tips

    Pay attention to your breathing. Exhale when you exert is a general rule of thumb. Never hold your breath. Page - 29 HD1400 Assembly...

  • Page 32: Weight Training Exercise Log

    O W N E R S Page - 31 HD1400 Assembly...

  • Page 35: Decal Placement

    O W N E R S D E C A L P L A C E M E N T SERIAL # DECAL 021-0003254 021-0003221 WARNING PINCH POINTS 021-0003138 HD1400 Assembly Page - 34...
  • Page 36 D E C A L P L A C E M E N T This decal has been attached to this piece of equipment to provide information regarding operation, safety and maintenance. Before use, take the time to read these decals. 021-0003011 NOTICE 021-0003131 Page - 35 HD1400 Assembly...
  • Page 37 O W N E R S M A N U A L D E C A L P L A C E M E N T WARNING 021-0003334 021-0003130 HD1400 Assembly Page - 36...

  • Page 38: General Maintenance Information

    O W N E R S M A N U A L HOIST FITNESS SYSTEMS GENERAL MAINTENANCE INFORMATION Links, Pull-Pins, Snap Locks, Swivels, Weight Stack Pins: Check all pieces for signs of visible wear or damage. Check springs in snap hooks and pull-pins for proper tension and alignment.
  • Page 39 (lithium, super lube, etc.) into the inside of the bearing. Using your finger, press the grease into the ball-bearings and their tracks. Repeat until the ball-bearing tracks are full of grease. Insert the shaft back into the bearing and wipe off excess grease. PLEASE KEEP THIS FOR YOUR RECORDS. HD1400 Assembly Page - 38...

  • Page 40: Maintenance Schedule

    6 MONTHS YEARLY Linear Bearings Replace; YEARLY 3 YEARS Cables, Belts and Connecting Parts Your equipment comes with a commercial maintenance decal. For personal, in home use, please follow the home maintenance schedule listed above. Page - 39 HD1400 Assembly...

  • Page 41: Limited Warranty

    If at any time a component part is defective, Hoist Fitness Systems shall repair or replace it (at Hoist under normal use or service. If at any time a component part is defective, Hoist Fitness Systems shall repair or replace it (at Hoist Fitness Systems option) within a reasonable period of time.
