  • Page 2 • If this product becomes inordinately hot or emits smoke, or unusual odor or noise, immediately turn OFF the power switch, unplug the power cord from the power outlet, and then call your Kodak Service Representative. A fire or electrical shock could result if you continue to use the product.
  • Page 3 This symbol indicates that when the last user wishes to discard this product, it must be sent to appropriate facilities for recovery and recycling. Please contact your local Kodak representative or refer to www.kodak.com/go/recycle for additional information on the collection and recovery programs available for this product.
  • Page 4 REACH statement Please consult www.kodak.com/go/REACH for information about the presence of substances included on the candidate list according to article 59(1) or Regulation (EC) No. 1907/2006 (REACH). Battery Information This product contains a Lithium Ion button cell battery. This battery can only be removed or replaced by a qualified Service Engineer.
  • Page 5 All other users WARNING: Use of controls, adjustments of performance or procedures other than those specified in this manual may result in hazardous radiation exposure. This is a semiconductor laser. The maximum power of the laser diode is 15mW, and the wavelength is 770-800 nm. For Denmark ADVARSEL: Usynlig laserstråling ved åbning, når sikkerhedsafbrydere er ude af funktion.

  • Page 6: Table Of Contents

    Contents 1 Overview ..........1-1 Product description .
  • Page 7 4 Printer Functions ........4-1 Printer components .

  • Page 8: Overview

    1 Overview This Operator’s Manual provides information and procedures for using the Kodak 3000 DV Plus Digital Scanner. Following is a summary of what is included: Chapter 1, Introduction — provides general information about the Kodak 3000 DV Plus Digital Scanner including a product description, installation information, environmental specifications, an overview of external components, and how to turn the scanner on and off.

  • Page 9: Installation

    Installation Placement of the unit in the environment described below will ensure optimal performance throughout the long life of service for which it was designed. • A well-ventilated place. • An area which is free from ammonia or other organic gases. •...

  • Page 10: Grounding

    Grounding To prevent electrical shocks caused by electrical leakage, always ground the printer. • Connect the grounding wire to: - the ground terminal of the outlet - a grounding contact that complies with the local electrical standards • NEVER connect the grounding wire to a gas pipe, the grounding wire for a telephone, or a water pipe.

  • Page 11: Operating Environment

    This scanner is available in the following configurations: Printer mode (connected to the printer) The scanner is connected to a dedicated Kodak 34 ppm Video Laser Printer, allowing scanned images to be printed out directly. PC mode (connected to a personal computer via a USB 2.0 cable) The scanner is connected to a personal computer and the scanned images can be uploaded to the computer.

  • Page 12: Scanner Components

    Scanner components Front view Screen — the image from the film is displayed for viewing on the screen. The frame on the screen marks the data reading range. Control Panel — most operations are controlled from the keys and indicators on the control panel. See Chapter 2, Control Panel and Functions for more information.
  • Page 13 Rear view Power Switch — used to turn the power to the unit on and off. Connectors — provides connection points for the various options (Film Carrier and Controller). Power Cord Socket — plug the power cord included with the scanner into this socket.

  • Page 14: Optional Accessories

    Optional accessories Optional accessories are available for the scanner. Contact your Kodak Representative for more information about these accessories. Projection Lenses — several projection lenses are available to change the size and adjust the focus of the image. Four lenses are available: Single lens 7.5X...
  • Page 15 Film carriers Fiche Carrier-5 — for use with jackets, microfiche and aperture cards. UC-2 — a motorized carrier for semi-automatic loading of 16 and 35 mm open spool film, microfiche, aperture cards, jackets. UC8 — a motorized carrier for roll films but manual threading.

  • Page 16: Turning The Power On And Off

    9 pages (letter or A4 size/400 dpi). The printer allows that print process to be started as soon as the printer completes warming up. Both ends of the Exposure display blink. If you want this function disabled, contact your Kodak Service Representative. A-61371 April 2010...
  • Page 17 These functions may be disabled or enabled. When enabled, timing can be selected to 30 or 60 minutes. The default for both of these functions is Disabled. Contact your Kodak Service Representative for more information. When the system is in the Auto Power Save mode, each outside segment of the Multi-Print Display LEDs light up sequentially.

  • Page 18: Control Panel And Functions

    2 Control Panel and Functions Following are descriptions of the Control Panel functions. Some functions are available by using the Shift key and some of the functions provide access to optional accessories. This chapter provides an overview of each function and a description of image processing features.
  • Page 19 Lamp Illuminance — manually adjusts the Projection Lamp illuminance. When the Projection Lamp is Off, it can be turned On again by pressing any key. Film Type — rotates between Auto, Nega, and Posi each time the key is pressed. •...
  • Page 20 PR mode. 14 Start — starts the print (scan) process of the displayed image. 15 Indicators: Misfeed/Call Kodak: lights up when a paper misfeed or malfunction occurs. Wait: lights when the scanner is initializing and the Wai t symbol printer is warming up.

  • Page 21: Using The Shift Function On Control Panel 1

    Using the Shift When you use the Shift function (Clear/Stop key) on Control Panel 1, other options are available. function on Control Panel 1 Control Panel 1 - Shift Function Paper Selection Exposure Print Mode Print Position Paper Selection Film Type 8 ×11 Text Auto...
  • Page 22 Control Panel 2 Centering Fit Masking Auto Auto Skew Masking Correction Focus Centering/Fit key — when pressed, enables or disables the Centering and Fit functions. When Auto Masking, Trimming or Masking are set to Off, Auto Masking will automatically be enabled when Centering is selected.
  • Page 23 After printing, the skew is retained by default. Contact your Kodak Service Representative to change the default. Manual Focus — press the up or down arrow keys to manually adjust the focus of the displayed image.

  • Page 24: Image Processing Features

    Image processing This section provides a description of the image processing features. Procedures on how to use these features can be found in Chapter 3, features Using the Scanner. Screen image to Print Image Description Auto Masking (1 Frame) The black borders along the edges of the image are masked.
  • Page 25 11 x 17” (A3) landscape paper. Imprint Time, date and messages can be included on a print. To enable this function, contact 1234ABCD January 1, 2001 your Kodak Representative. 1234ABCD January 1, 2001 A-61371 April 2010...

  • Page 26: Using The Scanner

    3 Using the Scanner This chapter provides procedures on how to us the Kodak 3000 DV Plus Digital Scanner. Following is an outline of the basic printing procedure. Detailed procedures on these steps follow in this chapter. 1. Load the film. The procedure for loading film is determined by the type of Film Carrier (optional) that is being used.

  • Page 27: Selecting A Projection Lens

    Selecting a Projection lenses are available in the following types. Select the type of lens that corresponds to the film you are using. projection lens Type 1: 7.5X Type 2: 9 to 16X Type 3: 13 to 27X Type 4: 20 to 50X The following list shows the standard types of film and the recommended zoom ratios of lenses to be used with the system printer.

  • Page 28: Replacing The Projection Lens

    Replacing the To replace a lens with a magnification different from the pre-installed lens. projection lens 1. Grasp the Prism Holder lever and push it up. 2. Pull out the projection lens unit. 3. Slide the desired projection lens unit into the scanner along the lens holder guide.

  • Page 29: Positioning The Film Image

    Positioning the film The size frame markers that correspond to the scanning size are marked on the screen. Through zooming and image rotation, and by image operating the film carrier mounted on the system, position the image on the screen so the image fits in the scanning size. Size Frame 11 x 17”...

  • Page 30: Zooming, Focusing And Image Rotation

    Zooming, focusing Zooming in on the displayed image: and image rotation • Turn the Zooming Ring dial (blue) to bring the image on the screen into the print size frame. Focusing the displayed image: • Center the displayed image and press the AF (Auto Focus) key to let the scanner automatically bring the image into focus.

  • Page 31: Selecting The Film Type

    Selecting the film Auto type The system will automatically determine the polarity of the film being used when Auto is selected. NOTE: The system cannot determine the polarity of certain types of film. If the system cannot detect a film type, select it manually. The system does not detect exterior conditions such as when the glass surface of the carrier is dirty or scratched.

  • Page 32: Selecting The Paper Size

    Selecting the paper Press the Paper Selection key to select the desired print size. The system cycles through the available sizes each time you press the key. size NOTE: If the printer is not loaded with a desired size paper, load the paper into the printer.

  • Page 33: Using The Auto Film Format Selection Function

    Using the Auto Film When the paper feeding tray and paper cassette is loaded with Format Selection 8 1/2 x 11” (A4) paper, this function can be used to automatically select the appropriate size of paper for the current print job. function 1.

  • Page 34: Selecting The Image Density

    Selecting the image Using Auto Exposure density 1. Press the Exposure Mode key to select the Auto Exposure mode. 2. If the Auto Exposure setting is not satisfactory, press the appropriate Exposure Adjustment key, either Lighter or Darker, to set the desired image density.

  • Page 35: Entering The Number Of Prints To Be Made

    Entering the number of This function is only available in PR mode. prints to be made Entering a number from 1-9 • Enter the desired number of prints using the Multi Print key “1”. If the 1 key is pressed when 9 is displayed, the number on the display is incremented by one: 10, 11, 12, etc.

  • Page 36: Adjusting Image Processing Features

    Adjusting Image Processing features Using Auto Masking The Auto Masking function prevents the frame (non-image area) of a film image from appearing on the print. • Press the Auto Masking key to turn on this function. Correction NOTES: • The image area of the screen must provide at least 45 mm horizontally and vertically.

  • Page 37: Manual Masking Panels (Option)

    Manual Masking panels (option) 1 Lengthwise Area Indication panel — use to specify the print area in the vertical direction of the image on the screen. The system makes a print of the image corresponding to the way the Area keys are illuminated.
  • Page 38 Selecting Trimming • Press the Masking key to select Trimming. The lights on the panel light up according to the currently selected paper size and print position. A4 vertical, Center Example: A4 vertical, Center NOTE: You can print the area specified by the green lights. The lights which do not match with the selected paper size and the print position may light up just after the Job Program is called.
  • Page 39 Defining two separate areas • Define the areas to print by specifying the vertical and horizontal areas as follows: 2 end points for vertical and 4 end points for horizontal. NOTE: The points defining the vertical and horizontal area can be selected in any order.

  • Page 40: Using Centering And Fit

    Clearing a defined print area • Press the Vertical and Horizontal Clear keys. Selecting Masking • Press the Masking key to select Masking when you want to mask a specific area of an image. NOTE: The basic operation for Manual Masking is similar to Trimming. Refer to the previous procedures on Trimming and defining areas for Manual Masking procedures.

  • Page 41: Using The Cycle Print Mode

    Images are manually loaded on the carrier glass in between cycles. Cycle Print mode is a system setting that must be entered by an Kodak Service Representative. This function is only available in the PR mode.

  • Page 42: Selecting The Connection Mode

    Specifying the interval between scanning operations The chart below provides the time intervals that can be set between scanning operations. The time interval is based upon how much time it takes you to move, for example, a roll of film from frame-to-frame. Refer to this table when making a value selection.

  • Page 43: Selecting The Resolution

    Selecting the Resolution 1. Press the Shift key and the Resolution key together. The current resolution is displayed. Resolution 2. Press the Resolution key while holding down the Shift key to set the resolution. Connection mode Resolution Display PR mode 400 dpi 600 dpi PC mode...

  • Page 44: Calling The Job Program

    Calling the Job Program To call a registered Job Program: 1. Press the Shift key and the Job Recall key together. Job Recall Each time the Job Recall key is pressed while the Shift key is held down, the display is cycled in order of 1J to 2J to 3J. When the desired setting is displayed, release the keys.

  • Page 45: Adjusting Screen Illumination

    Skip magnification Hold down the 10 key and the Zoom+ or Zoom- key together, the magnification skips as follows: Inch Area Metric Area Magnification Size Magnification Size 0.50 minimum 0.50 minimum 0.65 11 x 17” to 8 1/2 x 11” 0.71 A3 to A4 0.77...

  • Page 46: Printer Functions

    4 Printer Functions This chapter provides information on how to use and maintain your Kodak 34 ppm High Speed Video Laser Printer. Printer components 1 Top cover release lever — used to open the top cover. 2 Output tray extension — fold open when printing on B4 paper larger.
  • Page 47 8 Interface connectors ⎯ these two connectors allow the connection with separate scanner units. 9 Power cord socket ⎯ plug the power cord into this socket. 9 Top cover ⎯ open to replace the toner cartridge and to clear misfed sheets of paper. 10 Image transfer roller ⎯...

  • Page 48: Paper Specifications

    Paper specifications Use only the following types of paper: Type — plain and recycled paper (weight 16 to 24 lbs / 60 to 90 g/m Standard sizes — 11 x 17”, 8 1/2 x 11”, 8 1/2 x 14”, A3 and A4. Capacity •...

  • Page 49: Loading Paper In The Paper Cassette

    4. While pressing the button on the right side of the media guide, slide the media guide to adjust it. NOTE: Make sure the paper fit easily between the guides. Improperly adjusted guides may cause poor print quality, paper jams, or printer damage. Loading paper in the 1.
  • Page 50 4. Lift up the gray lever on the right end of the paper retainer, and slide the paper retainer to the right. 5. Lift up on the left end of the paper retainer to remove it. 6. Insert the right end of the paper retainer into the slot for the size of paper to be loaded.
  • Page 51 8. Align the four edges of the paper, and then load the paper printing side up. Do not load paper on this side. Long-edge Feed Examples Short-edge Feed Examples Letter, A4 and B5 Ledger, Legal, A3 and B4 NOTE: A maximum of 500 sheets (20 lb. bond [75 g/m ] plain paper) can be loaded.
  • Page 52 12. When printing on paper B4 or larger, fold open the output tray extension. 13. Affix the paper size labels (supplied with the printer) to the paper cassette in order to indicate the size of loaded paper. A-61371 April 2010...

  • Page 53: Replacing The Toner Cartridge

    Replacing the toner 1. Slide the top cover release lever to the right, and open the top cover cartridge NOTES: • Never touch the copper or brass electrodes or electrical parts that are located inside the top cover and underneath the toner cartridge, as a printer malfunction can result.
  • Page 54 4. Peel off the packing tape. NOTE: Hold the toner cartridge by its handle. Do not open the protective cover of the OPC (the green area) or allow anything to come in contact with the OPC. It is extremely sensitive to hand oils and scratches, both of which reduce print quality.
  • Page 55 • Guidelines are available for disposal of toner cartridges that are replaced during maintenance or service. Follow local regulations or access the Kodak website at: www.kodak.com/go/msds and refer to the Material Safety Data Sheet (MSDS). When accessing the MSDS from the website, you will be required to provide the toner cartridge catalog number: CAT No.

  • Page 56: Replacing The Exhaust Filter

    Replacing the Replace the exhaust filter on the back of the printer when you replace the toner cartridge. exhaust filter 1. Remove the used exhaust filter and dispose of it according to your local regulations. 2. Remove the new filter from its box and insert it into place. Troubleshooting Misfeed clearing Locate the misfeed using the code and perform the misfeed clearing...

  • Page 57: Clearing A Misfeed From The Paper Feeding Tray

    Clearing a misfeed from 1. Remove all paper from the paper feeding tray. the paper feeding tray 2. Pull out the misfed paper. 3. Correctly load the paper into the paper feeding tray. 4. If necessary, open and close the top cover to cancel the misfeed code.
  • Page 58 4. After removing the misfed paper, lower the two levers. 5. Open the paper feed roller cover. 6. Pull out the jammed paper. 7. Close the paper feed roller cover. 8. Align the tabs on the toner cartridge with the notches in the printer and insert the cartridge.

  • Page 59: Printer Maintenance

    Printer maintenance Clean the printer at regular intervals. NOTES: • Use a soft cloth and NEVER use abrasives or corrosive detergents; a damp cloth and a mild home detergent can be used for heavier cleaning. • Never spray cleaning solution directly on the printer’s surface; the spray could penetrate the air vents and damage the printer.

  • Page 60: Maintenance

    5 Maintenance This chapter provides maintenance procedures for cleaning the scanner and replacing the projection lamp. Cleaning the scanner The scanner should be cleaned daily for optimal operating conditions. Cleaning the scanner screen • With a damp cloth, clean and remove any dust or debris from the surface of the screen.
  • Page 61 Carrier Glass (option) NOTE: Before cleaning the carrier glass, remove the projection lens from the scanner. Refer to Chapter 3, “Installing the projection lens” for procedures. • With a damp cloth, clean and remove any dust or debris from the surface of the carrier glass.

  • Page 62: Replacing The Projection Lamp

    Replacing the Use the following procedure to replace the projection lamp whenever a reduction in brightness on the screen is detected or whenever the lamp projection lamp burns out. Make sure that the replacement lamp is specified for use with this scanner. If the projection lamp burns out during a print operation, an L2 code appears and the print job will stop (a blank piece of paper may be output depending upon the stage of the job).
  • Page 63 5. Insert the new projection lamp so that the mark on its base is facing upwards. Make sure that the new projection lamp is inserted securely so there is no gap between the projection lamp and the lamp socket. Mark CAUTION: Do not touch the reflector mirror surface of the projection lamp.

  • Page 64: Troubleshooting

    6 Troubleshooting/Messages This chapter contains information on analyzing and correcting operating problems or errors that may occasionally arise during the use of the Kodak 3000 DV Plus Digital Scanner. Printer /Scanner malfunctions Display Code Description Power to the printer is off or there is a problem with the connection of the interface cable to the printer.

  • Page 65: Solving Printing Problems

    Call your Kodak Service Representative if one of the following codes is displayed. Display Location Code Description Scanner Optical path switch failure A scanner malfunction A condenser lens motor malfunction Shading correction malfunction A fan motor malfunction Imperfect auto focusing...

  • Page 66: Appendix A Specifications

    Appendix A Specifications The following are specifications for the Kodak 3000 DV Plus Digital Scanner and the Kodak 34 ppm Video Laser Printer. NOTE: Specifications are subject to change without notice. Kodak 3000 DV Plus Digital Scanner Specifications Type Desktop-type microfilm scanner Type of Film Microfiche, Jackets, Aperture Cards, 16 mm &...
  • Page 67 PR Mode - Kodak 34 ppm Video Laser Printer Specifications Resolution 600 dpi Output Scale Binary Printing Method Laser Electrostatic Developing System Super Micro-Toning (Super-MT) System Print Size A3, A4 (portrait), A4 (Landscape) 11 x 17”, 11 x 8 1/2”, 8 1/2 x 11”, 8 1/2 x 14”...

  • Page 68: Appendix B User And System Settings

    Print position Center Print mode Text Resolution 600 dpi Kodak 34 ppm Video Laser Printer Electrical zoom 1.00 magnification NOTE: When any of these functions are changed, store the new setting in the system’s memory by pressing the Memory Input key.
  • Page 69 This function automatically scans the next image (PR mode only) Disabled following a preset period of time (the period can be set by your Kodak Service Representative). Images are set by the user onto the carrier glass in between cycles. Paper Size of Paper...
  • Page 70 The paper source must be refilled or the paper source must be switched by pressing the Output Selection key to resume printing. * To change any of the system settings described above, contact your Kodak Service Representative. A-61371 April 2010...

  • Page 71: Appendix C Key Operator Information

    • Your company name, address, telephone number, department name, floor number, machine location, etc. • K# (Mainframe and/or Printer), model name, serial number, condition or system(s) indications(s) on the display, etc. Kodak 3000 DV Plus Digital Scanner Serial Number Model Name Kodak 34 ppm Video Laser Printer Serial No.

  • Page 72: Appendix D Setting System Default Values

    User mode allows the default values of various functions to be set or changed as necessary. Most of these functions are set-up and changed with the User mode by your Kodak representative, however some User modes can be changed by you. Setting these default values according to your needs saves time and allows you to work more efficiency.

  • Page 73: Entering And Exiting The User Mode

    Entering and exiting the 1. Hold down the Shift key and Paper Selection key at the same time User mode for 0.5 seconds. The Multi-Print Display displays a “U”. Paper Selection 11×17 8 ×11 8 ×11 Shift User Mode 2. Press the Exposure Adjustment key (Darker or Lighter) to select the specific function.

  • Page 74: Settings In Each User Mode Function

    Settings in each User U1: Special Print mode — this function is not available. mode function U2: Engineering Enhancement mode — slight image distortion occurring in the scan direction can be corrected with this function. 1. Select U2 in the User mode. 2.
  • Page 75 U4: Paper Feeding Tray Size — the size an direction of the paper loaded in the Paper Feeding Tray can be set with this function. 1. Select U4 in the User mode. 2. Press the Exposure Mode key to display d*. 3.
  • Page 76 U6: Year, Month and Date Set mode —the print pattern for the Date Print function can be set with this function. 1. Select U6 in the User mode. 2. Press the Exposure Mode key to display d*. 3. Press the Exposure Adjustment key (Darker or Lighter) to select the desired setting value.
  • Page 77 3. In each setting mode, press the Multi-Print key to enter the setting value. Each press of the Multi-Press key increases the setting value. When the value exceeds the maximum setting of the selected mode, it returns to 00 or 01 (month, day). 4.
