Generac Power Systems 004709-0 Owner's Manual page 47

GN-220 H/SH Engine Drawing No. 0D8355-AG Part 1
ITEM PART NO. QTY.
1 0D8433 1
2 0C1069 10
0C1069 11
3 090965F 1
0G6468 1
4 081810 1
5 083312 1
6 0D8400 1
7 0C8917A 1
8 0C8798A 1
9 045756 9
10 082774 1
11 022129 2
12 081990 2
13 0D9004A 1
14 0E7585 1
15
16 0G3111 2
17 0G3231 1
19 0D7666A 1
0D7666B 1
20 090051 1
21 080316 2
22 090948 1
23 078631 1
24 0D8332 1
25 091846 1
26 0D7558 1
27 078643 2
28 0D8372 1
29 0C2756 1
30 0D7458 1
31 0C3979 1
32 085953 1
33 0D8739 1
34 0D8398 1
DESCRIPTION
GUARD, FAN
SCREW, HHTT M6-1.0 X 8MM
(04709 ONLY)
BLOWER HOUSING
BLOWER HOUSING 220RV (04709
ONLY)
NUT, HEX M16-1.5
WASHER, M16 CONICAL
ASSEMBLY CHOKE SOLENOID
BRACKET
FLYWHEEL, WITH RING GEAR
BACKPLATE, ELECTRIC START
SCREW HHTT M6-1.0 X 10MM
KEY, WOODRUFF 4 X 19D
5/16"-M8 LOCK WASHER
SCREW SHC M8-1.25 X 40MM
ASSY, STARTER
SPARK PLUG, CHAMPION RC14YC
TAPTITE, M6-1.0 X 25 ZINC
ASSEMBLY, IGNITION COIL ADV. W/
DIODE
BREATHER TUBE
BREATHER TUBE (04709 ONLY)
GASKET, MANIFOLD/ HEAD
SCREW HHFC M6-1.0 X 30MM
INTAKE MANIFOLD
GASKET CARBURETOR/MANIFOLD
CARBURETOR
GASKET, CARB/ ADAPTOR
ADAPTOR, CARB
BOLT, CARB MOUNT M6-1.0 X 75MM
GASKET, CARB TO AIRBOX
ASSEMBLY, GOVERNOR LEVER
ROD, GOVERNOR
SPRING, ANTI LASH
WASHER, CARB WEAR
ASSEMBLY BRACKET GOVERNOR
ADJUST
ROD, CHOKE LINKAGE
Exploded Views & Parts Lists
ITEM PART NO. QTY.
35 091638A 1
36 0G7967 1
37 082025 1
38 092984 1
39 094820 1
40 089739 1
41 091848 1
091848 2
42 0D8778 1
43 040945 2
040946 2
44 0D9235 1
45 070185B 1
52 0G6437 1
53 043182 2
54 0C4739 2
55 0D9689 1
56 0A7095 2
57 077091 1
58 0D8397 1
59 077075 1
60 0C2824 2
61 0A7094 2
62 0D8590 1
63 0D8591 1
64 0G6277A 21"
65 0G6273 1
66 0G7458 1
67 069598 1
68 059502 1
69 045764 2
70 0E9406A 1
71 0G3662B 4
72 0G4695B 2
73 0A6344 2
74 0G6502 1
75 040143 1
76 0F9176F 1
DESCRIPTION
SPRING, GOVERNOR
SCREW, HHTT 5/16" X ½" SEMI-
GIMLET
NUT, M5-0.8 LOCK
TOP WRAPPER
PLUG, EXPANSION
LOWER WRAPPER
GASKET, OIL PSI PAD
(04709 ONLY)
ADAPTER, OIL FILTER
SCREW SHC M6-1.0 X 20MM G12.9
SCREW SHC M6-1.0 X 35MM G12.9
(04709)
SWITCH, OIL- 5 PSI
FILTER, OIL
SWITCH, THERMAL 305F
WASHER LOCK M3
SCREW PPHM M3-0.5 X 6MM
ELBOW 90D STREET 1/8NPT
RHMS #4-40 X 5/16" SEMS
COTTER PIN
ROD, CHOKE CONTROL
BOOT CHOKE SOLENOID PLASTIC
SCREW TAP-R #10-32 X 9/16"
RHMS #4-40 X 1/4" SEMS
ASSEMBLY, BI-METAL/HEATER
SOLENOID, CHOKE
FUEL HOSE 3/8 LO-PERM
BARBED TEE 1/2X3/8X1/2
BARBED EL 90 1/4NPT X 3/8
BULKHEAD ADAPTOR FITTING
BARBED EL 90 1/4 NPT X 5/16
SCREW HHTT M4-0.7 X 8 BP
OIL COOLER 220
CLAMP ,HOSE OETIKER STEPLESS 18.5
HOSE 3/8" X 16.25" BRAID-WRAP
BARBED EL 90 1/8NPT X 3/8
OIL FILTER SPACER 220RV
CLAMP , HOSE #5.5
HOSE, ¼" SAE30R11 GREENBAR 7"
45
