Generac Power Systems 004709-0 Owner's Manual page 41

Enclosure Drawing No. 0D8352-N
ITEM PART NO. QTY.
1 0D6822 1
2 0D6942 1
3 0D6939 1
4 0D6943 1
5 0D6941 1
0D6941A 1
6 0D6940 1
0D6940A 1
7 0D6945 1
8 0D6944 1
9 0D8254 1
10 0C5644 2
11 0D7513 1
12 087769 1
13 0D7613 1
14 0D7614 1
15 040173 2
16 047411 2
17 022473 2
18 023484S 1
19 022097 2
20 086729 1
21 0D3700 24
22 022129 2
23 022259 2
24 075763A 2
25 0D7293 1
26 064113 1
27 0C7561 1
28 0A4456 1
30 049813 2
DESCRIPTION
TRAY, ENCLOSURE
PANEL, ENCLOSURE SIDE
PANEL, REAR DIVIDER
PANEL, ENCLOSURE ROOF
PANEL, ENCLOSURE BACK
PANEL, ENCLOSURE BACK, EXTERNAL
PORT (04709 ONLY)
PANEL, FRONT DIVIDER
PANEL, FRONT DIVIDER, EXTERNAL
PORT (04709 ONLY)
COMPARTMENT, AIR INTAKE
PANEL, ENCLOSURE DOOR 4KW RV
SHIELD, MUFFLER
SLIDE LATCH, FLUSH
PUMP , FUEL
FILTER, FUEL
FUEL LINE, FILTER TO PUMP
FUEL LINE, PUMP TO CARB
CLAMP ,HOSE WORM GEAR
SCREW HHC M6-1.0 X 16
WASHER FLAT ¼"
BUSHING, 1.09" SNAP
WASHER LOCK M6-1/4"
CONTACTOR, STARTER
NUT FLANGE M6-1.0 NYLOK
WASHER LOCK M8-5/16"
NUT HEX 5/16"-18
BOOT BATTERY CABLE
PANEL AIR BOX COVER
SCREW, M6-1.00 X 20MM WING
BOLT CARR 3/8"-16 X 1"
3/8" SPECIAL L/WASHER
NUT HEX M6 X 1.0
Exploded Views & Parts Lists
ITEM PART NO. QTY.
31 022237 1
32 022131 2
33 0C5443 1
34 0C7423 1
35 029451 2.1'
36 074908 4
37 0D8717 1
38 0D9020 1
39 0742600144 1
40 0E0724 1
41 0G4933 18
42 0742600143 1
43 0D8595 1
44 0D8627 2
45 0D8628 1
46 0D8628A 1
47 0D8691 1
48 0D7176 4
49 0A2115 1
50 0D9282 1
51 023484E 1
52 0F9176 8.5"
53 0E0014 1
54 0E0017 1
55 0C7968 4
56 0E0393 1
57 0D8981 1
58 029451A 8.75'
59 0D8628B 1
DESCRIPTION
WASHER LOCK 3/8"
WASHER FLAT 3/8-M10"
BLOCK, TERMINAL BATTERY POST
STUD 3/8"-16 X 2"-1/4" BRASS
TAPE FOAM 1/8" X ½"
SCREW HHTT M5-0.8 X 10
CUSTOMER CONNECTION HARNESS
FOAM, AIR OUT COMPARTMENT SIDE
CABLE, STARTER
ASSEMBLY OIL DRAIN
SCREW SWT 1/4-20 X 5/8 W/W
CABLE, BATTERY CONNECTION
MOUNT, FUEL FILTER SUPPORT
FOAM, AIR INTAKE COMPARTMENT
FOAM, ROOF AIR OUT COMPARTMENT
FOAM, BACK COMPARTMENT
FOAM, DOOR PANEL
WASHER SELF LOCKING 1"
WASHER NYLON .250"
HARDWARE CLOTH COMPARTMENT
AIR OUT
BUSHING, 0.50" SNAP
HOSE, 1/4" ID
BOX, MUFFLER TAIL PIPE
GASKET, MUFFLER TAIL PIPE BOX
NUT HEX JAM 3/8"-16 BRASS
ASSEMBLY, CAP & DIPSTICK
FILTER GASKET
FOAM TAPE 1/16" X ½"
FOAM, FRONT AIR OUT
COMPARTMENT
39
