330 PEDOMETER
USER GUIDE
/INSTRUCTION MANUAL
www.sportline.com
Walking Advantage by Sportline
TM
is distributed for EB Sport Group,
Yonkers, NY. in Canada by / Walking Advantage par Sportline
TM
distribué pour EB Sport Group, au Canada par ACI Brands Inc,
2616 Sheridan Drive, Oakville, Ontario L6J-7Z2.
All Rights Reserved/Touts droits reservé ©2012
WV1054IS02SCC
3- BUTTONS AND THEIR FUNCTIONS
The Sportline 330 Pedometer has a single button for operating and programming:
RESET (located on the front of the unit below the display).
• PRESS: Scrolls through display modes.
• PRESS & HOLD: Resets pedometer data.
WV1054IS02SCC.indd 1
WV1054IS02SCC.indd 1
Fold 3
1- INTRODUCTION
Congratulations on your purchase of a Sportline 330 Pedometer. The 330 Pedometer
features a highly advanced pedometer technology that accurately measures your
body movements when worn from multiple locations on the body and in multiple
orientations.
Please keep in mind your pedometer is a sensitive technical instrument. With
proper care and maintenance, it will last for many years. However, improper care
and handling can cause the various sensors to be damaged and to stop functioning.
HOW TO USE THIS MANUAL
Please read all sections of this manual carefully and become fully familiar with the
operation of the pedometer before using it in the fi eld. Proper setup and operation
will greatly enhance the pedometer's usefulness and your enjoyment. The steps for
the programming or operation are adjacent to the screen illustration. Key points
and important information are shown in highlighted blocks.
CUSTOMER SUPPORT
If you have questions, comments or need assistance with your Sportline
est
Pedometer, you may contact Customer Support by calling 1-866-694-4575.
4- OPERATING THE PEDOMETER
The 330 Pedometer automatically begins capturing data once movement occurs.
There are no Start or Stop buttons to push.
Scroll through display modes: STEPS AND EXERCISE TIME by PRESSING THE
RESET BUTTON.
STEPS
www.sportline.com
Fold 2
2- REMOVING BATTERY INSULATOR TAB
NOTE: In order to activate your pedometer after purchase, you must remove the
battery insulator tab inside the battery compartment.
1. Locate the tab on the lower edge of the pedometer.
2. Firmly grasp the tab and pull away from the pedometer until completely
removed from the unit.
3. Remove the label that appears on the pedometer display.
1
5- RESETTING PEDOMETER DATA
TO CLEAR ALL CURRENT PEDOMETER DATA:
1. PRESS & HOLD the RESET button on the front of the unit.
2. Continue holding as the display reads "RESET".
3. When pedometer data reads zeros (O), RELEASE THE RESET button. The unit
is now ready for a new workout.
1
EXERCISE TIME
WV1054IS02SCC
9/11/12
Ron
Fold 3
2
Fold 1
2
330 PEDOMETER
9/13/12 5:30 PM
9/13/12 5:30 PM

Advertisement

loading
Need help?

Need help?

Do you have a question about the 330 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sportline 330

  • Page 1 330 PEDOMETER 2- REMOVING BATTERY INSULATOR TAB Congratulations on your purchase of a Sportline 330 Pedometer. The 330 Pedometer NOTE: In order to activate your pedometer after purchase, you must remove the features a highly advanced pedometer technology that accurately measures your battery insulator tab inside the battery compartment.
  • Page 2: Replacing The Battery

    STORE the unit in a dry place when you are not using it. 9- REPLACING THE BATTERY 10- BATTERY SAFETY INFORMATION The Sportline 330 Pedometer uses one CR2032 3V lithium battery. CAUTION – BATTERY SAFETY INFORMATION Battery replacement will be required from time to time, and should occur when: •...
  • Page 3 5- REMISE À ZÉRO DES DONNÉES DU PODOMÈTRE Le podomètre 330 de Sportline n’a qu’un bouton servant à l’utiliser et à le Le podomètre 330 commence automatiquement à enregistrer les données dès POUR SUPPRIMER TOUTES LES DONNÉES COURANTES DU PODOMÈTRE : programmer : RESET [REMISE À...
  • Page 4 RANGEZ l’appareil dans un endroit sec quand vous ne vous en servez pas. 9- REMPLACEMENT DE LA PILE 10- INFORMATION SUR LA SÉCURITÉ CONCERNANT LES PILES Le podomètre 330 de Sportline fonctionne à l’aide d’une pile au lithium CR2032 de AVERTISSEMENT – INFORMATION SUR LA SÉCURITÉ CONCERNANT 3 volts. LES PILES La pile doit être remplacée de temps à...
