OWNER'S MANUAL

Installation and Operation

Model:
BODBAY
This manual contains instructions for Installation, Operation & Maintenance.
Please read this entire manual before you install and use your new room heater. Failure to follow
instructions may result in property damage, bodily injury, or even death.
IMPORTANT SAFETY NOTES:
1) When installing your stove, particular attention should be paid to fire protection. If this room heater is not properly
installed, a house fire may result. To reduce the risk of fire, follow the installation instructions. Contact local build-
ing or fire officials or authority having jurisdiction about restrictions, installation inspection and permit requirements
in your area.
2) CAUTION: Never use gasoline or gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to
start or "freshen up" a fire in this heater. Keep all such liquids well away from heater while it is in use.
3) During operation, if any part of the stove starts to glow, the stove is in an overfired condition. Close the air controls
completely until the glowing has stopped. OVERFIRING VOIDS YOUR WARRANTY!
4) Cool ashes should be disposed of carefully, using a metal container.
5) Do not burn wet or green wood. Store wood in a dry location.
6) DO NOT BURN GARBAGE OR FLAMMABLE FLUIDS SUCH AS GASOLINE, NAPHTHA OR ENGINE OIL. Do
not burn treated wood, or wood with salt (driftwood, etc.). Burning materials other than wood (including charcoal)
under adverse conditions may generate carbon monoxide in the home, resulting in illness or possible death.
7) Do not permit creosote or soot to accumulate excessively in the chimney or inside the firebox.
8) Check your chimney system thoroughly when installing into an existing metal or masonry chimney. Seek profes-
sional advice if in doubt about its condition.
9) Do not connect this unit to a chimney flue already serving another appliance.
10) Comply with all minimum clearances to combustibles as shown in this manual for this appliance.
11) Build fire on brick firebox floor. Do not use grates, andirons or other methods to support fuel.
12) HOT WHILE IN OPERATION! Keep children, pets, clothing and furniture away. Contact can cause skin burns.
13) Do not connect to any air distribution duct or system
14) RISK OF FIRE! Do not operate with stove door open, without the firescreen, or ash removal system door open.
15) For further information refer to NFPA 211 (USA) or CAN/CSA-B365 (Canada).
16) Do not operate without fully assembling all components. Burning your stove without the legs attached (if supplied
with unit) will void your warranty, and could present a serious safety hazard
17) Do not oeprate with broken glass..
PRIOR TO FIRST FIRE: Remove all labels from glass. Clean plated surfaces with a glass cleanser and soft
1445 North Highway
Colville, WA 99114-2008
BODEGA BAY WOOD INSERT
Advanced Combustion Technology (ACT)
cloth to prevent staining from fingerprint oils.
SAVE THESE INSTRUCTIONS
435-1320B
August 20, 2008
R
O-T L
Tested and
Portland
Listed by
Oregon USA
C
US
OMNI-Test Laboratories, Inc.
www.quadrafire.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BODBAY and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Quadra-Fire BODBAY

  • Page 1: Installation And Operation

    BODEGA BAY WOOD INSERT Advanced Combustion Technology (ACT) OWNER’S MANUAL Installation and Operation Model: BODBAY O-T L Tested and Portland Listed by Oregon USA OMNI-Test Laboratories, Inc. This manual contains instructions for Installation, Operation & Maintenance. Please read this entire manual before you install and use your new room heater. Failure to follow instructions may result in property damage, bodily injury, or even death.
  • Page 2: Location & Sample Of Serial Number Label

    BODEGA BAY WOOD INSERT and Welcome to the Quadra-Fire Family earth & Home Technologies welcomes you to our tradition craftsmanship. Each unit is meticulously fabricated and surfaces of excellence! In choosing a Quadra-Fire appliance, you have are hand-finished for lasting beauty and enjoyment. Our pledge our assurance of commitment to quality, durability, and perfor- to quality is completed as each model undergoes a quality control mance.
  • Page 3: Table Of Contents

    BODEGA BAY WOOD INSERT Table of Contents OPERATION OVERVIEW SAFETY & OVERVIEW OF APPLIANCE Wood Selection & Storing ---------------------------------- 16 Location & Sample of Serial Number Label ----------- 2 Overfiring-------------------------------------------------------- 16 Dimensions ----------------------------------------------------- 4 Building A Fire ------------------------------------------------- 16 Minimum Clearances to Combustibles ------------------ 4 Operating Tips ------------------------------------------------- 17 Listings ---------------------------------------------------------- 5 Burn Rates &...
  • Page 4: Dimensions

    BODEGA BAY WOOD INSERT DIMENSIONS TOP VIEW CLEARANCES TO COMBUSTIBLES 30-3/16" United States and Canada (767mm) Maximum Mantel Depth - 10" (254mm) 24-1/16" (611mm) Mantel Fascia or Trim 11-3/4" (298mm) Insert 8-3/8" (213mm) Hearth Extension SIDE VIEW CANADA Sidewall to Stove 15"...
  • Page 5: Listings

    BODEGA BAY WOOD INSERT LISTINGS CHIMNEY HEIGHT/DRAFT (CONT’D) These installation instructions describe the installation and AVOID FIRE: To ensure that insulation or any other combustible operation of the Quadra-Fire Bodega Bay Wood Insert. This material does not contact the chimney, a chimney inside the house insert meets the U.S.
  • Page 6: General Installation Procedures

    BODEGA BAY WOOD INSERT GENERAL INSTALLATION PROCEDURE • DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE. • Install liner, if required, for your chosen installation. • Attach metal warning plate to the back of the fireplace with screws or nails. •...
  • Page 7: Chimney Requirements

    BODEGA BAY WOOD INSERT OVALIZING ROUND STAINLESS STEEL CHIMNEY REqUIREMENTS LINERS A chimney must be the required height above the roof or other obstruction for safety and for proper draft oper- Ovalizing round stainless steel liners to acommodate the liner passing through the damper region of a fire- ation.
  • Page 8: Mobile Home

    BODEGA BAY WOOD INSERT INSTALLATIONS INTO ZERO CLEARANCE FIREPLACES IN MOBILE HOMES (IN USA ONLY) An outside air inlet must be provided for combustion and Spark Arestor Cap must remain clear of leaves, debris, ice and/or snow. It must be unrestricted while unit is in use to prevent room air starvation which can cause smoke spillage and an inability to maintain a fire.
  • Page 9: Installation Options

    BODEGA BAY WOOD INSERT INSTALLATION OPTIONS Refer to: Clearances to Combustibles on page 4, Canadian Installation Requirements on page 11, Hearth Requirements on page 4 and Zero Clearance Adjustable Support Kit on page 15. MASONRY FIREPLACE USING DIRECT-CONNECT METHOD Masonry Chimney Flue Tile This product conforms with the UL Standard for Safety 1482 and ULC S628 (Canada) in all respects, and is approved to...
  • Page 10: Zero Clearance Factory Built Fireplace

    BODEGA BAY WOOD INSERT FACTORY BUILT ZERO CLEARANCE FIREPLACE (USA INSTALLATONS ONLY) The Quadra-Fire Bodega Bay ACT Wood Stove Insert is listed to UL 1482 Standard and approved for installation into listed factory built zero clearance fireplaces listed to UL 127 conforming to the following specifications and instructions: Mantel The original factory-built clearance fireplace chimney cap...
  • Page 11: Canadian Masonry & Heat Circulating

    BODEGA BAY WOOD INSERT INSTALLATION IN CANADA MASONRY and HEAT-CIRCULATING (INSTALLATIONS INTO FACTORY-BUILT FIREPLACES ARE PROHIBITED IN CANADA) Whether installed in a masonry or heat-circulating fireplace, this fireplace insert must be installed with a continuous chim- ney liner of six inch (152mm) diameter extending from the fireplace insert to the top of the chimney. The chimney liner must conform to the Class 3 requirements of CAN/ULC-S635, Standard for Lining Systems for Existing Masonry or Factory-Built Chimneys and Vents, or CAN/ULC-S640, Standard for Lining Systems for New Masonry Chimneys.
  • Page 12: Securing Liner To Chimney Ring

    BODEGA BAY WOOD INSERT SECURING LINER TO CHIMNEY RING There are 2 options to secure the liner to the chimney ring: (See Figure 12A). Option One: If there is enough room on the top of the 2 pre-drilled holes on insert to work, hand bend the two tabs upward 90°.
  • Page 13: Panel And Trim Set

    BODEGA BAY WOOD INSERT PANEL and GOLD or NICKEL TRIM SET STANDARD: 30-1/2” h x 44-5/8”w Screw side panels to top LARGE: 34”h x 50-1/2”w panel SP-BB3044-GD Panel & Trim Set, Std, Gold SP-BB3044-NL Panel & Trim Set, Std, Nickel SP-BB3450-GD Panel &...
  • Page 14: Blower Cord Installation

    BODEGA BAY WOOD INSERT FAN (BLOWER) REPLACEMENT BLOWER CORD LOCATION & BLOWER CONTROL BOX WITH SWITCH Included in Kit: Replacement Blower This insert comes standard with a blower, installed at the Tools Needed: 5-32 Wrench and Phillips Head Screwdriver. factory with blower cord on right side of insert (as you face 1.
  • Page 15: Zero Clearance Adjustable Trim Support

    BODEGA BAY WOOD INSERT ZERO CLEARANCE ADJUSTABLE TRIM SUPPORT, 2” to 10” Part No. 841-0990, size 9”d x 45”w and Part No. ADJSPT-12, size 12”d x 50”w Included in Kit: ( 1) Trim Top, (1) Trim Front, (2) Trim Sides, Double-Sided Tape (already installed) Tools Needed: Phillips Head Screwdriver, Sheet Metal Shears, Measuring Tape, Gloves EXPLODED VIEW OF SCISSORS...
  • Page 16: Wood Selection & Storing

    BODEGA BAY WOOD INSERT OPERATION WOOD SELECTION AND STORAGE Burn only dry seasoned wood. Dry, well-seasoned wood will not only minimize the chance of creosote formation but will give you the most efficient heat output. Even dry wood contains at least 15% moisture by weight and should be burned hot enough to keep the chimney hot enough to maintain particulate (smoke) burning.
  • Page 17: Operating Tips

    BODEGA BAY WOOD INSERT OPERATING TIPS For maximum operating efficiency with the lowest emissions, follow these operating procedures: Regardless of desired heat output, when loading stove, burn your Quadra-Fire with both air controls wide open for a minimum of 5 to 15 minutes. Regulate burn rate (heat output) by using the Primary Control (top rod).
  • Page 18: Air Quality

    BODEGA BAY WOOD INSERT AIR qUALITY AND YOUR qUADRA-FIRE INSERT In recent years there has been an increasing concern about the quality of our air. Much of the blame for poor air quality has been placed on the burning of wood for home heating. In order to improve this situation we at Quadra-Fire have developed cleaner burning inserts that surpass the stringent requirements for emissions established by our governing agencies.
  • Page 19: Maintenance

    BODEGA BAY WOOD INSERT MAINTENANCE CARE AND CLEANING OF PLATED SURFACES IMPORTANT: You must clean all the fingerprints and oils from the plated surfaces before firing the insert for the first time. Use warm soapy water and a soft rag, glass cleaner and a paper towel, or vinegar and a paper towel to remove the oils. DO NOT use abrasive cleaners! If not cleaned properly prior to lighting the first fire, the oils can cause permanent stains.
  • Page 20: Brick Replacement

    BODEGA BAY WOOD INSERT BRICK REPLACEMENT INSTRUCTIONS PART 832-3500 The firebox of your insert is lined with high quality fire- brick which has exceptional insulating properties. There is no need for a grate, simply build a fire on the firebox of your insert.
  • Page 21: Exploded View

    BODEGA BAY WOOD INSERT EXPLODED VIEW 21-1/2" 10.0" 5.0" R5" 14.0" Ceramic Blanket Item Part Name Item Part Name Item Part Name 17 Glass, Front 9 Wire Access Panel Strain Relief Bushing 18 Glass, Sides 10 Cover Plate Speed Control (Rheostat) 19 Top Blower Snap Disc...
  • Page 22: Parts & Accessories List

    Door Gasket, 1/2”, high density 832-3550 Glass Assembly, Door Front 832-3560 Glass Assembly, Side 832-3530 Manifold Tube Set (4) 812-4670 Snap Disc APPLIANCE Advanced Combustion Technology (ACT) BODBAY Bodega Bay Wood Insert, Black Crown Page 22 August 20, 2008 435-1320B...
  • Page 23: Service & Maintenance Log

    BODEGA BAY WOOD INSERT Warranty Policy Lifetime Warranty LIMITED LIFETIME WARRANTY The Hearth & Home Technologies limited Lifetime Warranty guarantees that the following components will work as designed for the lifetime of the stove or Hearth & Home Technologies will repair or replace them. These items include but are not limited to steel and cast iron components, all gas burners, gas logs, combustion chambers, heat exchanger systems, stainless steel fi rebox components, plating, doors, glass damaged by thermal breakage, steel baffl e supports, steel and ceramic baffl es and manifold tubes.
  • Page 24: Contact Information

    CONTACT INFORMATION: Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your quadra-Fire dealer with any questions or concerns. For the number of your nearest quadra-Fire dealer, log onto www.quadrafire.com CAUTION • Do NOT discard this manual. •...
