Maximum Cable Distances - Extron electronics HDMI 101 Plus Setup Manual

HDMI 101 Plus • Setup Guide (Continued)
4. If required, connect the power supply (provided) to the 2-pole captive screw connector.
CAUTION:
Connector" section of the HDMI 101 Plus User Guide, at www.extron.com.
NOTE: If all the devices are correctly cabled and powered on and you do not see
an image on the display device, you may need to buffer the DDC signal (see the
HDMI 101 Plus User Guide).

Maximum Cable Distances

The maximum cable distance depends on resolution, frequency, whether the HDMI 101 Plus
receives power from the source device or from the external power supply, and, for PC
resolutions, the power of the graphics card (when powered by source). When the source is
a PC, Extron recommends the HDMI 101 Plus be powered by an external power supply.
Video Resolution
720p
1080i
1080p 8 bit
1080p 10 bit
1080p 12 bit
1024x768 (60 Hz)
1280x1024 (60 Hz)
1600x1200 (60 Hz)
1920x1200 (60 Hz)
Extron USA - West Extron USA - East
Headquarters
+800.633.9876 +800.633.9876
Inside USA and Inside USA and
Canada Only Canada Only
+1.714.491.1500 +1.919.863.1794
+1.714.491.1517 FAX +1.919.863.1797 FAX
© 2011 Extron Electronics All rights reserved.
Before connecting the power supply, see the Caution in the "Power
Maximum Distance
(powered by source)
150 feet (46 m)
150 feet (46 m)
150 feet (46 m)
150 feet (46 m)
125 feet (38 m)
150 feet (46 m)
150 feet (46 m)
125 feet (38 m)
125 feet (38 m)
Extron Europe Extron Asia
+800.3987.6673 +800.7339.8766
Inside Europe Only Inside Asia Only
+65.6383.4400
+31.33.453.4040 +65.6383.4664 FAX
+31.33.453.4050 FAX
Maximum Distance (powered by
external power supply)
250 feet (76 m)
250 feet (76 m)
200 feet (61 m)
175 feet (53 m)
150 feet (46 m)
250 feet (76 m)
250 feet (76 m)
200 feet (61 m)
200 feet (61 m)
Extron Japan Extron China
+81.3.3511.7655 +400.883.1568
+81.3.3511.7656 FAX Inside China Only
+86.21.3760.1568
+86.21.3760.1566 FAX
www.extron.com
Extron Middle East
+971.4.2991800
+971.4.2991880 FAX
68-1983-50
Rev. A 05 11
