- Page 1 User’s Manual Mini-ITX-Motherboard-2801280...
- Page 2 Copyrights This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer. In general, the manufacturer will not be liable for any direct, indirect, special, incidental or consequential damages arising from the use of inability to use the product or documentation, even if advised of the possibility of such damages.
-
Page 3: Package List
Package List 2801280 package includes the following items: 1x 2801280 single board computer 2x Dual RS-232 cable 1x IDE Cable 1x SATA Power Cable 2x SATA Cable 1x I/O Shielding 1 x Mini Jumper Pack 1 x Utility CD 1 x QIG (quick installation guide) -
Page 4: Specifications
Specifications z CPU: Socket 479 Intel® Core 2 Duo/Core Duo/Solo with 667 MHz FSB z System Chipset: Intel® 945GM + ICH7M z BIOS: AMI BIOS z System memory 2×240-pin Dual channel DDRII 400/533/667 MHz up to 3GB z Ethernet Dual Broadcom BCM5787 PCI express GbE with ASF2.0 remote control support z I/O 8 x USB 2.0... -
Page 5: Jumpers Setting And Connectors
Temperature: Operation:0~60°C(32~140°F) z Humidity: Operation:5%~90% non-condensing z Dimension: 170mm x 170mm z Weight: GW: 1100 g; NW: 400 g Ordering Information 2801280 Mini-ITX Motherboard with Intel® Core Duo/Core Solo Processor, SATAII, Dual PCI-E GbE, USB 2.0 Audio RS-232/422/485 Cable USB Cable... - Page 6 COM2 : 14-Pin Serial Port Connector PIN DESCRIPTION DESCRIPTION COM3,4 : 10-Pin Serial Port Connector PIN DESCRIPTION PIN DESCRIPTION DIO1: 10-pin Digital I/O Connector PIN DESCRIPTION PIN DESCRIPTION INPUT0 OUTPUT0 INPUT1 OUTPUT1 INPUT2 OUTPUT2 INPUT3 OUTPUT3 AUDIO2 = Audio Connector. Port1_L PRESENCE Port1_R...
- Page 7 F_PANEL1 : Front Panel Jumper PIN DESCRIPTION PIN DESCRIPTION Power LED+ Speaker+ Power LED- Power Speaker- Power Button- 11 IDE LED+ Reset Button+ 13 IDE LED- Reset Button- CN1 : LCD Back Light connector DESCRIPTION PIN DESCRIPTION Back Light Power 2 Back Light Power Back Light enable LVDS1 : LVDS LCD Connector...
-
Page 8: Board Layout: Jumper And Connector Locations
Board Layout: Jumper and Connector Locations... - Page 10 Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact with us. We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free (U.S. Only) 800-833-8999...
