2801114
User's Manual
Edition 1.0
Copyright
©
Copyright
2002, 2003. All rights reserved. This document is copyrighted and
all rights are reserved. The information in this document is subject to change
without prior notice to make improvements to the products.
This document contains proprietary information and protected by copyright.
No part of this document may be reproduced, copied, or translated in any
form or any means without prior written permission of the manufacturer.
All trademarks and/or registered trademarks contains in this document are
property of their respective owners.
Disclaimer
Global American Inc. shall not be liable for any incidental or consequential
damages resulting from the performance or use of this product.
Global American Inc. does not issue a warranty of any kind, express or
implied, including without limitation implied warranties of merchantability or
fitness for a particular purpose.
The company has the right to revise the manual or include changes in the
specifications of the product described within it at any time without notice and
without obligation to notify any person of such revision or changes.
Trademark
All trademarks are the property of their respective holders.
2801114 User's Manual
1
Advertisement
Table of Contents
Related Manuals for Global American 2801114
Summary of Contents for Global American 2801114
- Page 1 Global American Inc. shall not be liable for any incidental or consequential damages resulting from the performance or use of this product. Global American Inc. does not issue a warranty of any kind, express or implied, including without limitation implied warranties of merchantability or fitness for a particular purpose.
-
Page 2: Packing List
2801114 Motherboard............Cable Kit 40-pin ATA100 IDE Flat Cable.......... 34-pin Floppy Cable ............Dual-USB Port Cable ............DB9 COM Port Cable............Audio Cable ..............I/O Shield ................Printed Matter and Software User’s Manual ..............Driver CD ................2801114 User’s Manual... -
Page 3: Table Of Contents
TATE ............18 OWER AND ONNECTOR VGA I ................19 NTERFACE ............... 22 THERNET NTERFACE ................23 UDIO NTERFACE 2.10 ..............25 WITCH AND NDICATOR CHAPTER 3. BIOS SETUP................27 CHAPTER 4 AUDIO CHANNEL CONFIGURATION ........29 2801114 User’s Manual... - Page 4 APPENDIX. A I/O PORT PIN ASSIGNMENT ..........31 APPENDIX B. FLASH THE BIOS ............... 37 BIOS A ..............37 LASH ................37 LASH ETHOD APPENDIX C. SYSTEM RESOURCES ............39 CONTACT INFORMATION................44 2801114 User’s Manual...
-
Page 5: Chapter 1. Introduction
S/P DIF 3D audio, TV-out and embedded flash disk interfaces. Compact Mini-ITX Form Factor @ 170 x 170 mm 2801114 is based on the ultra compact mini-ITX form factor at only 170 x 170 mm of dimension, meets the demand of compact and powerful computing platform. -
Page 6: Specification
One external bi-direction parallel port with SPP/ECP/EPP mode Floppy Port One FDD port supports up to two FDD IrDA Port One IrDA compliant Infrared interface supports CIR/SIR K/B & Mouse External PS/2 keyboard and mouse ports on rear I/O panel 2801114 User’s Manual... - Page 7 S/P DIF digital audio encoding signal input and output Line-in, line-out, CD-in and MIC-in Connector External three phone jack for 5.1 channel audio on rear panel External S/P DIF connector on rear panel Internal 10-pin header for line-in/-out, MIC-out, 4-pin header for CD-in 2801114 User’s Manual...
- Page 8 C (32 ~ 140 Storage within -20 ~ 85 C (-4 ~ 185 Ordering Code 2801114-GAI Mini-ITX Socket 479 Pentium 4 processor –M Motherboard with Intel Extreme VGA, LAN, TV-out, 5.1-CH/SPDIF Audio, Hi-Speed USB 2.0, IEEE1394 Interface and LVDS interface. 2801114 User’s Manual...
-
Page 9: Component Placement
Controller and CD-in Interface Intel 845GV GMCH Intel 82801DB ICH4 With 533 / 400 MHz Host Bus With Hi-Speed USB 2.0 200 / 266 /333 MHz Memory Bus UltraATA100 IDE Intel Extreme Graphics Intel PRO/100+ LAN Mac 2801114 User’s Manual... -
Page 10: Block Diagram
GMCH UltraATA100 IDE ATAPI Device Intel ICH4 100 MBps Hi-Speed USB 2.0 USB Devices 480 Mbps PCI Slot LAN1 PCI Bus Interface IEEE1394 Codec Audio Devices AT Keyboard PS/2 Keyboard PS/2 Mouse Floppy Serial Device Parallel Device 2801114 User’s Manual... -
Page 11: Chapter 2. Hardware Setup
CPU and memory installation, fan, I/O and panel connections. Connector Location CPUFAN JAUDIO CDIN1 CONLCD PCI1 IDE2 DIMM1 IDE1 FLOPPY JIR1 JRTC JFRNT CHASFAN JWOL JCOM1 Printer USB1 SVDIO1 RJACK1 VGA1 USRJ1 P1 RJACK2 2801114 User’s Manual... - Page 12 S/P DIF Input / Output Setting Panel Voltage Setting Jumper Setting Quick Reference Jumper JRTC Clean CMOS Normal Operation JKBV KB with +5V KB with +5VSB IEEE1394 Enable IEEE1394 Disable S/P DIF Output S/P DIF Input +3.3V Default setting 2801114 User’s Manual...
- Page 13 RJACK1 AV TV-out RCA Jack Standard VGA1 VGA DB15 Female Connector Standard LAN RJ45 Connector with LED Standard USRJ1 Dual USB Connector Standard IEEE1394 Connector Standard Audio RCA Connector Standard RJACK2 S/P DIF Digital Audio Connector Standard 2801114 User’s Manual...
-
Page 14: Cpu And Dram Setting
1. Unlock the processor socket. 2. Install the processor onto the socket well. 3. Lock the processor socket. Lock switch Unlock Lock Notice! Before you install the processor on the socket, please check the pin director well 2801114 User’s Manual... -
Page 15: Cmos Setting
The board’s data of CMOS can be setting in BIOS. If the board refuses to boot due to inappropriate CMOS settings, here is how to proceed to clear (reset) the CMOS to its default values. Jumper: JRTC Type: onboard 3-pin header JRTC Mode Clear CMOS Normal Operation Default setting JRTC 2801114 User’s Manual... -
Page 16: Watchdog Timer Setting
2E, 07 2F, 08 Logical Device 8 2E, 30 Activate 2F, 01 2E, F5 Set as Second* 2F, 00 2E, F6 Set as 5 2F, 05 * Minute: bit 3 = 0; Second: bit 3 = 1 2801114 User’s Manual... -
Page 17: Embedded Solid State Disk
DiskOnModule (DOM) embedded flash disk. The onboard 40-pin IDE1 and 44-pin IDE2 box header supports normal DOM (DiskOnModule) or M- systems DiskOnChip IDE Pro flash disk with or without the additional Vcc power cable. 2801114 User’s Manual... -
Page 18: Power And Fan Connector
Description Ground Ground +12V +12V Connector: PW1 Type: 20-pin ATX power connector PIN assignment 3.3V 3.3V 3.3V -12V PS_ON PW_OK 5V_SB Connector: CPUFAN, SYSFAN Type: 3-pin fan wafer connector Pin Description Description Description Ground +12V Fan Control 2801114 User’s Manual... -
Page 19: Vga Interface
Extreme Graphics with 266 MHz VGA core, 256-bit 3D engine and Intel Dynamic Video Memory up to 64 MBytes shared with system memory. The CRT / analog VGA interface includes one external DB15 female connector on bracket on board. 2801114 User’s Manual... - Page 20 The board’s digital video interface provides LVDS flat panel. The built-in 40-bit dual channel LVDS interface offers the economical solution for LVDS-based LCD display. CONLCD Connector: J4 Connector: J3 Type: 5-pin LVDS Power Header Type: 3-pin Power select Header Description Description ENABKL VCC3 +12V 2801114 User’s Manual...
- Page 21 Connector: CONLCD Type: onboard 40-pin connector for LVDS connector Signal Signal LCDVCC LCDVCC ATX0- BTX0- ATX0+ BTX0+ ATX1- BTX1- ATX1+ BTX1+ ATX2- BTX2- ATX2+ BTX2+ ATXC- BTX3- ATXC+ BTX3+ ATX3- BTXC- ATX3+ BTXC+ PANELCLK PANELCLK PANELDATA PANELDATA 2801114 User’s Manual...
-
Page 22: Ethernet Interface
Ethernet Interface The 2801114 is integrated with Intel PRO/100+ Fast Ethernet interface at the type of 10Base-T/100Base-TX auto-switching Fast Ethernet with full duplex and IEEE 802.3U compliant. The 2801114 LAN interface is controlled by the Intel 82801DB ICH4 and 82562ET PHY, and connect with the external RJ45 connector on rear I/O panel. -
Page 23: Audio Interface
Audio Interface The 2801114 offers the AC97 3D audio with 5.1-channel and S/P DIF interface based on Intel ICH4 and Realtek ALC650 codec. JAUDIO CDIN 1 2 3 4 Red: Center / Mic-in Blue: Rear / Line-in Green: Front / Line-out... - Page 24 Line Out – Left Line Out – Right Ground Jumper: J2 Type: onboard 3-pin header Mode S/P DIF Output S/P DIF Input Default setting Connector: CDIN Type: 4-pin header Description CD – Left Ground Ground CD – Right 2801114 User’s Manual...
-
Page 25: Switch And Indicator
2.10 Switch and Indicator JFRNT Connector: JFRNT Type: onboard 14-pin (2 x 7) 2.54-pitch header Function Signal Signal Function Vcc (+) (+) Vcc IDE LED Power Active Reset Reset Speaker Power PWRBT Button SPKIN 2801114 User’s Manual... - Page 26 Notes (This page left blank intentionally) 2801114 User’s Manual...
-
Page 27: Chapter 3. Bios Setup
Set Supervisor Password >Power Management Setup Set User Password >PnP / PCI Configurations Save & Exit Setup >PC Health Status Exit Without Saving ↑ ↓ → ← : Select Item Esc : Quit F10 : Save & Exit Setup 2801114 User’s Manual... - Page 28 Notes (This page left blank intentionally) 2801114 User’s Manual...
-
Page 29: Chapter 4 Audio Channel Configuration
Chapter 4 Audio Channel Configuration In order to enable 5.1 channel, please follow the setup steps below: lunch the Control Panel lunch the Sound Effect Ma nager 3.select Speaker Configuration and choose 6 channel mode for 5.1 speaker output 2801114 User’s Manual... - Page 30 Notes (This page left blank intentionally) 2801114 User’s Manual...
-
Page 31: Appendix. A I/O Port Pin Assignment
Appendix. A I/O Port Pin Assignment IDE Port Connector: IDE1 Type: 40-pin (20 x 2) box header Description Description Reset Ground Ground Ground IOW-/STOP Ground IOR-/HDMARDY Ground IORDY/DDMARDY IDESEL DACK- Ground CBLID CS0 (MASTER CS) CS1 (SLAVE CS) LED ACT- Ground 2801114 User’s Manual... - Page 32 Connector: IDE2 Type: 44-pin (22 x 2) box header Description Description Reset Ground Ground Ground IOW-/STOP Ground IOR-/HDMARDY Ground IORDY/DDMARDY Ground DACK- Ground ASP1 Ground Ground Ground 2801114 User’s Manual...
- Page 33 DIRECTION- Ground STEP- Ground WRITE DATA- Ground WRITE GATE- Ground TRACK 0- Ground WRITE PROTECT- Ground READ DATA- Ground HEAD SELECT- Ground DISK CHANGE- Serial Port Connector: JCOM1 Type: 10-pin (5 x 2) header Description Description Ground 2801114 User’s Manual...
- Page 34 Type: 10-pin (5 x 2) header for dual USB Ports Description Description Data0- Data1- Data0+ Data1+ Ground Ground IrDA Port Connector: JIR1 Type: 10-pin (5 x 2) header for SIR/CIR Ports Description Description CIRRX IRRX 5V Standby Ground IRTX 2801114 User’s Manual...
- Page 35 VGA Port Connector: VGA Type: 15-pin D-sub female connector on bracket Description Description Description Ground GREEN Ground 5VCDA BLUE Ground HSYNC LVGA5V VSYNC Ground Ground 5VCLK LAN Port Connector: LAN Type: RJ45 connector with LED on bracket Description 2801114 User’s Manual...
- Page 36 Notes (This page left blank intentionally) 2801114 User’s Manual...
-
Page 37: Appendix B. Flash The Bios
File name of the tool is “awdflash.exe”, it’s the utility that can write the data into the BIOS flash ship and update the BIOS. Flash Method Get the “.bin” file including the image of new BIOS you want to update. Power on the system and flash the BIOS. Re-star the system. 2801114 User’s Manual... - Page 38 Notes (This page left blank intentionally) 2801114 User’s Manual...
-
Page 39: Appendix C. System Resources
PC Compatible Eisa/Isa HAL 00C0-00CF PC Compatible Eisa/Isa HAL 00F0-00FF PC Compatible Eisa/Isa HAL 01CE-01CF VgaSavve 01F0-01F7 atapi 02F8-02FE Serial 0378-037A Parport 03B0-03BB VgaSavve 03C0-03DF VgaSavve 03F0-03F5 Floppy 03F6-03F6 atapi 03F7-03F7 Floppy 03F8-03FE Serial E000-E0FF alcxnt E400-E43F alcxnt 2801114 User’s Manual... - Page 40 Intel (R) USB Enhanced Host Controller (ICH4) 0xEC000000-0xEC000FFF Intel(R) PRO/100 VE Network Connection 0xEC001000-0xEC001FFF OHCI Compliant IEEE 1394 Host Controller 0xFEBFFC00-0xFEBFFFFF Intel(R) 82801DB Ultra ATA Storage Controller - 24CB 0xEC181000-0xEC1811FF Avance AC'97 Audio 0xEC182000-0xEC1820FF Avance AC'97 Audio 2801114 User’s Manual...
- Page 41 Intel(R) 82801DB/DBM USB Universal Host Controller – 24C7 PS/2 Compatible Mouse Port Numeric Data Processor Intel(R) 82801DB Ultra ATA Storage Controller – 24CB Primary IDE Controller (Dual FIFO) Intel(R) 82801DB Ultra ATA Storage Controller – 24CB Secondary IDE Controller (Dual FIFO) 2801114 User’s Manual...
- Page 42 C3.2 DMA Channel Device (free) (free) Standard Floppy Disk Controller (free) Direct Memory Access Controller (free) (free) (free) 2801114 User’s Manual...
- Page 43 Notes (This page left blank intentionally) 2801114 User’s Manual...
-
Page 44: Contact Information
Any adviser or comment about our products and service, or anything we can help you please don’t hesitate to contact with us. We will do our best service for you. Global American Inc. Address 17 Hampshire Drive Hudson NH 03051 1-603-886-3900 1-603-886-4545 Website: www.globalamericaninc.com 2801114 User’s Manual...
