- Page 1 2801020 User’s Manual Mini-ITX Motherboard supporting Intel Pentium M / Celeron M Version 1.1...
- Page 2 Copyrights This document is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.
- Page 3 Copyright Copyright 2005, all rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products. This document contains proprietary information and protected by copyright. No part of this document may be reproduced, copied, or translated in any form or any means without prior written permission of the manufacturer.
-
Page 4: Packing List
Packing List: Please check the package content before you starting using the board. Hardware: 2801020 motherboard x 1 Cable Kit: 44-pin 44-pin 40-pin ATA33 IDE Cable x1 Floppy Cable x 1 SATA Cable x 1 COM port Cable x 1... - Page 5 Index Chapter 1 <Introduction> ................7 1.1 <Product Overview>................7 1.2 <Product Specification> ..............8 1.3 <Mechanical Drawing>..............10 1.4 <Block Diagram>................11 Chapter 2 <Hardware Setup>................ 13 2.1 <Connector Location> ............... 13 2.2 <Jumper Location & Reference> ............14 2.3 <Connector Reference>...
-
Page 6: Table Of Contents
Chapter 3 <System Setup> ................34 3.1 <Video Memory Setup> ..............34 Appendix A <I/O Port Pin Assignment>............38 A.1 <IDE Port> ..................38 A.2 <Serial ATA Port>................39 A.3 <Floppy Port> ................... 39 A.4 <IrDA Port> ..................39 A.5 <Serial Port> ..................40 A.6 <VGA Port>.................. - Page 7 (This Page is Left for Blank)
-
Page 8: Chapter 1
Chapter 1 <Introduction> 1.1 <Product Overview> 2801020 is the new generation of the Mini-ITX motherboard, with supporting last Intel Pentium M processors for 533MHz front side bus, Intel 915GME and ICH6-M chipset, integrated GMA900 graphics, DDR2 memory, REALTEK High Definition Audio, Serial ATA, PCI Express 16x interface and dual Gigabit LAN. -
Page 9: Product Specification
1.2 <Product Specification> General Specification Form Factor Mini-ITX motherboard Intel® Pentium M / Celeron M processors Package type: FC-PGA478 L2 Cache: 512KB/1MB/2MB Front side bus: 400/533MHz Memory 2 x 240-pin DDR2 400/533MHz SDRAM up to 2GB Up to 8GB/s of bandwidth with dual-channel interleaved mode Dual-Channel technology supported Unbufferred, none-ECC memory supported only Chipset... - Page 10 Operating within 0 ~ 60 C (32 ~ 140 Storage within -20 ~ 85 C (-4 ~ 185 Ordering Code 2801020 Intel Pentium M platform with onboard VGA, HD audio, SATA USB2.0, LVDS, HDTV, PCI-Express, Mini-PCI, CF, PCMCIA 4 x COM 3907643 PCI-Express add-on card for single DVI interface The specifications may be different as the actual production.
-
Page 11: Mechanical Drawing
1.3 <Mechanical Drawing>... -
Page 12: Block Diagram
1.4 <Block Diagram> Intel Pentium M/Celeron M Processors Intel GMA900 Graphics PCI-Express x16 2 x 240-pin DDR2 LVDS 400/533MHz up to 915GME HDTV Compact Flash 2 x Serial ATA ports UltraDMA33 IDE PCI Express 1x ICH6-M 6 x USB2.0 ports Marvell E8053 Gigabit LAN HD Audio... - Page 13 (This Page is Left for Blank)
-
Page 14: Chapter 2
Chapter 2 <Hardware Setup> 2.1 <Connector Location> Solder side: CARDBUS CN_AUDIO SPDIF CDIN CN_IR MINIPCI CN_USB PWRIN SATA1 SATA2 CN_LVDS CN_DIO CN_COM CPUFAN CN_TV SYSFAN CN_INV CN_BPWR DDRIIB/A JFRNT DC_IN COM1/2 USB_RJ45_A/B AUDIO... -
Page 15: Jumper Location & Reference
2.2 <Jumper Location & Reference> Jumper Function JRTC CMOS Operating/Clear Setting JCFSEL CF with IDE mode selection JVLCD Panel Voltage Setting JCFSEL JRTC JVLCD... -
Page 16: Connector Reference
2.3 <Connector Reference> 2.3.1 <Internal Connectors> Connector Function Remark Socket479 for CPU Standard DDRIIA/B 240 -pin DDR2 SDRAM DIMM socket Standard 44-pin IDE connector Standard 26-pin slim type floppy connector Standard S_ATA1/2 7-pin Serial ATA connector Standard PWRIN 4-pin power input connector Standard CN_BPWR 4-pin power output connector... -
Page 17: Cpu And Memory Setup
2.4 <CPU and Memory Setup> 2.4.1 <CPU Setup> The board comes with the socket479 for Intel Pentium M/Celeron M processors, it supports new generation of Intel Pentium M processors with 533MHz of front side bus and 2MB L2 cache. Please follow the instruction to install the CPU properly. Unlock way 1. -
Page 18: Memory Setup
2801020 User’s Manual Hardware Setup 2.4.2 <Memory Setup> The board provides two 240-pin DDR2 DIMMs to support DDR2 400/533 memory modules up to 2GB of capacity. Non-ECC, unbuffered memory is supported only. While applying two same modules, dual channel technology is enabled automatically for higher performance. -
Page 19: Cmos Setup
2.5 <CMOS Setup> The board’s data of CMOS can be setting in BIOS. If the board refuses to boot due to inappropriate CMOS settings, here is how to proceed to clear (reset) the CMOS to its default values. Jumper: JRTC Type: Onboard 3-pin jumper JRTC Mode... -
Page 20: Enhanced Ide Interface
2.6 <Enhanced IDE Interface> The board has one UltraDMA33 IDE interface to support up to 2 ATAPI devices, and one CompactFlash Type I socket on the solder side, with jumper JCFSEL for IDE master/slave mode selection. Jumper: JCFSEL Type: onboard 3-pin header JCFSEL Mode Master... -
Page 21: Floppy Port
2.8 <Floppy Port> The board provides one slim type floppy port. Lift up the brown plastic bar Slot the cable in (Blue paste for brown bar side) Press back the plastic bar Floppy rear side Lift up this plastic bar Slot the cable in (Blue paste for outside) Press back the plastic bar... -
Page 22: Ethernet Interface
2.9 <Ethernet Interface> The board integrates with two Marvell E8053 PCI Express Gigabit Ethernet controllers, as the PCI Express 1x can speed up to 250MB/s of transfer rate instead of late PCI bus with 133MB/s of transfer rate. The Marvell E8053 supports triple speed of 10/100/100Base-T, with IEEE802.3 compliance and Wake-On-LAN supported. -
Page 23: Onboard Display Interface
2.10 <Onboard Display Interface> Based on Intel 915GME chipset with built-in GMA (Graphic Media Accelerator) 900 graphics, the board provides one DB15 connector on real external I/O port, and one 40-pin LVDS interface with 5-pin LCD backlight inverter connector. The board provides dual display function with clone mode and extended desktop mode for CRT and LCD. -
Page 24: Digital Display
2.10.2 <Digital Display> The board provides one 40-pin LVDS connector for 18-bit single/dual channel panels, supports up to 1600 x 1200 (UXGA) and 1920 x 1200 (WUXGA) of resolution, with one LCD backlight inverter connector and one jumper for panel voltage setting. CN_LVDS CN_INV JVLCD... - Page 25 Connector: CN_INV Connector: JVLCD Type: 5-pin LVDS Power Header Type: 3-pin Power select Header Description Description +12V LCDVCC VCC3 ENABKL Connector: CN_LVDS Type: onboard 40-pin connector for LVDS connector Signal Signal LCDVCC LCDVCC ATX0- BTX0- ATX0+ BTX0+ ATX1- BTX1- ATX1+ BTX1+ ATX2- BTX2-...
- Page 26 LCD Installation Guide: Preparing the 2801020, LCD panel and the backlight inverter. Please check the datasheet of the panel to see the voltage of the panel, and set the jumper JVLCD to +5V or +3.3V.
- Page 27 The panel type mapping is list below: BIOS panel type selection form Single channel Dual channel Output format Output format 640 x 480 1024 x 768 800 x 600 1280 x 768 1024 x 768 1280 x 1024 1280 x 768 1366 x 768 1280 x 1024 1400 x 1050 @ 108Mhz...
-
Page 28: Hdtv Interface
2.10.3 <HDTV Interface> The board provides one HDTV interface up to 1024 x 768 resolution by NTSC/PAL supported, for three output types with Composite, S-Video and Component (YPbPr). Connector: CN_TV Connector type: 8-pin header TV-out connector (pitch = 2.54mm) Pin Number Assignment Pin Number Assignment... -
Page 29: Integrated Audio Interface
2.11 <Integrated Audio Interface> The board integrates onboard audio interface with REALTEK ALC880 codec, with Intel next generation of audio standard as High Definition Audio, it offers more vivid sound and other advantages than former AC97 audio compliance. The main specifications of ALC880 are: High-performance DACs with 100dB S/N ratio 8 DAC channels support 16/20/24-bit PCM format for 7.1 audio solution 16/20/24-bit S/PDIF-OUT supports 44.1K/48K/96kHz sample rate... - Page 30 Connector: CN_AUDIO Type: 10-pin (2 x 5) 1.27mm x 2.54mm-pitch header Description Description MIC_L Ground MIC_R Ground Speaker_R MIC Detect SENSE Speaker_L Speaker Detect Connector: CDIN Type: 4-pin header (pitch = 2.54mm) Description CD – Left Ground Ground CD – Right Connector: SPDIF Type: 4-pin header (pitch = 2.54mm) Description...
-
Page 31: Gpio Interface
2.12 <GPIO Interface> The board provides a programmable 8-bit digital I/O interface; you can use this general purpose I/O port for system control like POS or KIOSK. Connector: CN_DIO Type: 12-pin (6 x 2) 1.27mm x 2.54mm-pitch header Description Description Ground Ground GP10... -
Page 32: Power Supply
2.13 <Power Supply> 2.13.1 <Power Input> The board requires DC 12V input with 4-pin mini DIN connector on rear I/O panel, or onboard 4-pin ATX2.0 12V connector, the input voltage range is from 10.5V to 13V, for the input current, please take a reference of the power consumption report on appendix. Connector: PWRIN Type: 4-pin standard ATX2.0 +12V power connector Description... -
Page 33: Power Output
2.13.2 <Power Output> The board provides one 4-pin AT connector for +5V/+12V output for powering your HDD, CDROM or other devices. Connector: CN_BPWR Type: 4-pin P-type connector for +5V/+12V output Description Description Description Description Ground Ground +12V Note: Maximum output voltage: 12V/5A & 5V/3A CN_BPWR... -
Page 34: Switch And Indicator
2.14 <Switch and Indicator> The JFRNT provides front control panel of the board, such as power button, reset and beeper, etc. Please check well before you connecting the cables on the chassis. Connector: JFRNT Type: onboard 14-pin (2 x 7) 2.54-pitch header Function Signal Signal... -
Page 35: Chapter 3
Chapter 3 <System Setup> 3.1 <Video Memory Setup> Based on Intel® 915GME chipset with GMA (Graphic Media Accelerator) 900, the board supports Intel® DVMT (Dynamic Video Memory Technology) 3.0, which would allow the video memory to be allocated up to 128MB. To support DVMT, you need to install the Intel GMA 900 Driver with supported OS. - Page 36 Fixed + DVMT Memory Size: You can select the fixed amount and the DVMT amount at the same time for a guaranteed video memory and additional dynamic video memory, please check the table below for available setting. On-Chip Fixed DVMT Total System Frame...
- Page 37 (This Page is Left for Blank)
- Page 38 (This Page is Left for Blank)
-
Page 39: Appendix A
Appendix A <I/O Port Pin Assignment> A.1 <IDE Port> Connector: IDE1 Type: 44-pin (22 x 2) box header Description Description Reset Ground Ground Ground -IOW Ground -IOR Ground IORDY Ground DACK Ground IDEIRQ IDE32 P66DET -CS1 -CS3 -HD LED1 Ground Ground Ground... -
Page 40: A.2
A.2 <Serial ATA Port> Connector: SATA1/2 Type: 7-pin wafer connector GND RSATA_TXP1 RSATA_TXN1 GND RSATA_RXN1 RSATA_RXP1 GND A.3 <Floppy Port> Connector: FDD Type: 26-pin connector Description Description INDEX DRV0 DSKCHG DRV1 MTR1 MTR0 STEP Ground WRITE DATA Ground WRITE GATE TRACK 0 WRPTR Ground... -
Page 41: A.5
A.5 <Serial Port> Connector: COM1/COM2 Type: 9-pin D-sub male connector on bracket Description Description Ground Connector: CN_COM34 Type: 20-pin (10 x 2) 1.27mm x 2.54mm-pitch header Description Description... -
Page 42: A.6
A.6 <VGA Port> Connector: VGA Type: 15-pin D-sub female connector on bracket Description Description Description Ground GREEN Ground BLUE Ground HSYNC VSYNC Ground Ground 5VCLK A.7 <LAN Port> Connector: RJ451/2 Type: RJ45 connector with LED on bracket Description TRD0+ TRD0- TRD1+ TRD1- Description NC TRD2+ TRD2- TRD3+ TRD3- A.8 <... -
Page 43: Appendix B
Appendix B <Flash BIOS> B.1 <Flash Tool> The board is based on Award BIOS and can be updated easily by the BIOS auto flash tool. You can download the tool online at the address below: http://www.phoenix.com/en/home/ File name of the tool is “awdflash.exe”, it’s the utility that can write the data into the BIOS flash ship and update the BIOS. -
Page 44: Appendix C
Appendix C <System Resources> C1.<I/O Port Address Map>... - Page 46 C2.<Memory Address Map>...
- Page 47 C3.<System IRQ & DMA Resources> DMA: IRQ:...
- Page 48 The GPIO’can be programmed with the MSDOS debug program using simple IN/OUT commands.The following lines show an example how to do this. GPIO0…..GPIO7 bit0……bit7 -o 4E 87 ;enter configuration -o 4E 87 -o 4E 29 -o 4E 40 ;enale GPIO function -o 4E 07 -o 4E 07 ;enable GPIO configuration...
- Page 49 We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free U.S. Only (800) 833-8999 (603) 886-3900 FAX: (603) 886-4545 Website: http://www.globalamericaninc.com Support: Technical Support at Global American...
