AV Link WCV-LJN Features & Specifications

Composite
Video
EXTENDER
WCV-LJN / WCV-RJN
U M
SER ANUAL
WCV-EJN
Package Contents-
WCV-LJN Local Unit
WCV-RJN Remote Unit
1 user manual
4 M4*10mm screws
4 P6*14mm screws
Anything missed, please contact with your vendor.

Features

The extension of video and audio signal up to 30 meter
away by using the VIDEO/AUDIO Extender and CAT.5
cable.
No external power required.
One gang size.

Specifications

Function
Video In/Out Connector
Audio In/Out Connector
Cable Connector
Cable Distance
Housing
Weight
Dimensions (LxWxH)
LOCAL / REMOTE FRONT VIEW
1. RCA L Female Audio
2. RCA R Female Audio
3. Composite Video RCA Female
LOCAL / REMOTE REAR VIEW
V1.0
1. CAT.5

Installation

1. Turn off the TV and DVD player.
2. Connect WCV-EJN extender Local Unit RCA input
3. Connect WCV-EJN extender Local Unit RCA R/L audio
4. Connect the WCV-EJN extender Local and Remote Unit
5. Connect WCV-EJN extender Remote Unit RCA
WCV-LJN WCV-RJN
1x RCA Female
6. Connect WCV-EJN extender Remote Unit RCA R/L
1 Set RCA(R/L) Female
1x RJ-45
30 m (Max.)
7. Turn on the TV and DVD player and audio amplifier.
Metal
150 g 150 g
105x42x38 mm
-1-
connector with RCA male to male cable from DVD
player.
input connector with audio cable from DVD player
with CAT.5 cable.
connector with RCA male to male cable from TV.
audio output connector with audio cable from TV/audio
amplifier.
-2-
