This unit allows HDMI signals to be sent between devices at distances of up to 60m using a single shielded
network cable. The Extender kit works using a single cat5e or cat6 (recommended) cable instead of HDMI
cable to transmit high definition signals over a long distance, vastly reducing your costs but without reducing
your picture quality.
Technical Specifications and Features
HDMI Version
Max. Range
Video Format
Audio Format
Operating Temperature Range
Power Adaptor
Max. Bandwidth
Max. Baud Rate
Max. Working Current
Dimensions
Weight
Connection Instructions
HDMI Extender Over Single Network Cable Kit (60m)
1.4a
60m
Supports up to 1080p/60Hz, 3D and 12bit deep colour video formats
Supports DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD audio formats
-15 to +55°C
Input: AC (50Hz, 60Hz) 100-240V, Output: DC5V/1A
148.5 MHz
1.5Gbps
510mA (TX) and 100mA (RX)
81 x 43 x 22(mm)
100g (TX) and 120g (RX)
Item ref: 128.819UK
User Manual
128.819UK User Manual
Advertisement
Related Manuals for AV Link 128.819UK
Summary of Contents for AV Link 128.819UK
-
Page 1: Connection Instructions
HDMI Extender Over Single Network Cable Kit (60m) Item ref: 128.819UK User Manual This unit allows HDMI signals to be sent between devices at distances of up to 60m using a single shielded network cable. The Extender kit works using a single cat5e or cat6 (recommended) cable instead of HDMI cable to transmit high definition signals over a long distance, vastly reducing your costs but without reducing your picture quality. - Page 2 This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful life. The goods must be disposed of according to your local council guidelines. Errors and omissions excepted. Copyright© 2016. AVSL Group Ltd. 128.819UK User Manual...
