Chapter 2

Device Icons

Devices are physical things, such as computers, cameras, headsets, etc. Devices can
be represented by icons in My Bluetooth Places.
Each type of device is represented by a different icon. The device icons have three states
as described below:
NOTE:
ME, and 2000, and those used by Windows XP and Vista.

Service Icons

Services are what a Bluetooth device can do for other Bluetooth devices, such as provide
access to a local area network, or the ability to send a fax.
Some devices, such as headsets or network access points, may provide only a single
service. Others, such as desktop and laptop computers, can potentially provide all of the
Bluetooth services.
Single-service devices often use virtually the same icon for the service as that used for
the device. For example, the headset service icon is identical to the headset device icon.
Multiservice devices use a different icon for each service that they provide. Service icons
have three states as described below:
16 HP bt500 Bluetooth USB 2.0 Wireless Printer Adapter
Normal: Devices that are present in the vicinity are represented by a
plain icon. For example, this icon represents a desktop computer in a
normal state.
Connected: Devices that are connected to this computer are
represented by an icon with a green tint and / or a small butting arrows
box added to them. For example, this icon represents a cellular
telephone that is connected via Bluetooth to this computer.
Paired: Devices that are paired with this computer are represented
by a normal icon with a small check box added to it. For example, this
icon represents a Personal Digital Assistant (PDA) that is paired with
this computer.
There are some differences between the device icons used by Windows 9x,
Normal: This plain icon indicates that a specific service is potentially
available from the selected device. For example, this icon indicates
that the Bluetooth serial port service may be available.
Connected: This type of icon indicates that this computer is
connected to this service. The icon has a green tint and / or a small
butting arrows box added to it. For example, this icon indicates that
this computer is connected to the PIM item transfer service of the
remote device.
Not Available: This icon indicates that the service that it represents
is not available. Services that are not available are represented by a
normal icon with a small X box added to it . For example, this icon
indicates that the Bluetooth faxing service is not currently available.
